IP CAMERA IMOU DAHUA IPC-HFW1230T-ZS-2812-S5

Product Details

Reference WLONONWCRCPZM

In stock 5 Items

Data sheet

Type

IP security camera

Height

244.1 mm

Connectivity technology

Wired

Weight

860 g

Package weight

1.12 kg

Power source type

DC, PoE

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Mounting type

Ceiling/Wall/Pole

Form factor

Bullet

Bluetooth

No

Bit rate

H.264: 32 kbps–6144 kbps, H.265: 12 kbps–6144 kbps

Noise reduction

Yes

Sensor type

CMOS

Wi-Fi

No

Internal memory

128 MB

Compatible memory cards

MicroSD (TransFlash)

Maximum memory card size

256 GB

Maximum operating distance

50 m

Power consumption (max)

4.3 W

Power consumption (typical)

1.8 W

Maximum resolution

1920 x 1080 pixels

Placement supported

Outdoor

Card reader integrated

Yes

Ethernet LAN (RJ-45) ports

1

Ethernet LAN

Yes

Focus

Motorized/Manual

Supported graphics resolutions

1280 x 720 (HD 720)

Diameter

9.04 cm

International Protection (IP) code

IP67

Ethernet interface type

Fast Ethernet

Supported video modes

720p

Number of Users

6 user(s)

Supported network protocols

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast; DDNS

Normal focusing range

1.2 m

Frame Rate

30 fps

Product colour

White

Tilt angle range

0 - 90°

Focal length range

2.8 – 12

LED type

IR

Night vision

Yes

Total megapixels

2 MP

Optical sensor size

25.4 / 2.8 mm (1 / 2.8")

White balance

Auto

Minimum illumination

0.0005 lx

Pan range

0 - 360°

Video compression formats

H.264+

Angle of rotation

360°

DC output voltage

12

Number of cameras

1

Camera pan control

Yes

Camera tilt control

Yes

Night vision distance

50 m

Number of lenses

1

Day/night mode

Yes

Auto pan mode

Yes

Built-in HDD

No

Noise reduction technology

3D noise reduction

Smart IR

Yes

Digital Wide Dynamic Range (DWDR)

Yes

Region of Interest (ROI) encoding

Yes

Wide Dynamic Range (WDR)

Yes

Back Light Compensation (BLC)

Yes

Video streaming

Yes

ROM capacity

16 MB

Camera shutter speed

1/3 s–1/100,000

Adjustment shutter speed

Auto/Manual

Bit rate control

Constant Bit Rate (CBR), Variable Bit Rate (VBR)

Gain control type

Auto/Manual

Privacy masking

Yes

Highlight Compensation (HLC)

Yes

Number of illumination LEDs

2

Power consumption (Power over Ethernet (PoE))

5.5 W

Identify distance (wide)

5 m

Recognize distance (wide)

10 m

Observe distance (wide)

19 m

Closest focusing distance

1.2 m

Identify distance

13 m

Detect distance (wide)

48 m

Identify distance (tele)

13 m

Recognize distance (tele)

26 m

Detect distance (tele)

131 m

Observe distance (tele)

52 m

Warnings

Avoid direct contact with water to prevent electrical damage.
