Product Details
Data sheet
- Type
- IP security camera
- Width
- 140 mm
- Height
- 236.1 mm
- Depth
- 142.6 mm
- Connectivity technology
- Wired
- Weight
- 1.5 kg
- Package weight
- 2.1 kg
- Power source type
- DC, PoE
- Operating temperature (T-T)
- -30 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Mounting type
- Ceiling/wall
- Form factor
- Turret
- Bluetooth
- No
- Noise reduction
- Yes
- Mobile operating systems supported
- iOS
- Sensor type
- CMOS
- Wi-Fi
- No
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 512 GB
- Signal-to-Noise Ratio (SNR)
- 55 dB
- Power consumption (max)
- 15 W
- Power consumption (typical)
- 4.5 W
- Maximum resolution
- 2560 x 1440 pixels
- Placement supported
- Indoor & outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Audio output channels
- 1.0 channels
- Ethernet LAN
- Yes
- Focus
- Motorized/Manual
- Supported graphics resolutions
- 2560 x 1440
- Zoom capability
- Yes
- International Protection (IP) code
- IP66
- Digital zoom
- 16x
- Auto focus
- Yes
- Optical Zoom
- 5x
- Number of Users
- 20 user(s)
- Frame Rate
- 30 fps
- Product colour
- White
- Tilt angle range
- -15 - 90°
- Focal length range
- 2.7 - 13.5 mm
- RAM capacity
- 512 MB
- Voice codecs
- G.711a
- Image stabilizer
- Yes
- Night vision
- Yes
- Total megapixels
- 4 MP
- PTZ control
- Yes
- Optical sensor size
- 25.4 / 2.8 mm (1 / 2.8")
- White balance
- Outdoor
- Minimum illumination
- 0.0005 lx
- Pan range
- 0 - 355°
- Video compression formats
- H.265
- DC output voltage
- 12
- Video motion detection
- Yes
- Number of cameras
- 1
- Night vision distance
- 50 m
- Number of lenses
- 1
- Preset points
- Yes
- Auto-tracking
- Yes
- Built-in HDD
- No
- Noise reduction technology
- 2D noise reduction, 3D noise reduction
- Region of Interest (ROI) encoding
- Yes
- Maximum aperture number
- 3
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- Back Light Compensation (BLC)
- Yes
- Video streaming
- Yes
- Active tampering alarm
- Yes
- Intelligent Video Surveillance (IVS) system features
- Face detection
- ROM capacity
- 128 MB
- Camera shutter speed
- 1/1 - 1/30000 s
- Bit rate control
- Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Gain control type
- Auto/Manual
- Highlight Compensation (HLC)
- Yes
- Number of illumination LEDs
- 6
- Streaming method
- Unicast
- Pan speed
- 36 °/sec
- Audio input channels
- 1.0 channels
- Management software
- DMSS;DSS Pro
- Closest focusing distance
- 1.5 m
- Detect distance
- 270 m
- Observe distance
- 106.6 m
- Recognize distance
- 54 m
- Identify distance
- 27 m
- Tilt speed
- 25.8 °/sec
- Minimum aperture number
- 1.6
- Pan preset speed
- 35.7 °/sec
- Tilt preset speed
- 27.1 °/sec
- Alarm output channels
- 1
- Alarm input channels
- 1
- Warnings
- Avoid direct contact with water to prevent electrical damage.
