Product Details
Data sheet
- Type
- IP security camera
- Height
- 122 mm
- Connectivity technology
- Wireless
- Weight
- 496 g
- Power source type
- Battery, Solar, USB
- Operating temperature (T-T)
- -10 - 55 °C
- Mounting type
- Wall
- Form factor
- Dome
- USB port
- Yes
- Built-in microphone
- Yes
- Bluetooth
- No
- Battery capacity
- 6000 mAh
- Protection features
- Waterproof
- Sensor type
- CMOS
- Wi-Fi
- No
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 128 GB
- Audio system
- 2-way
- Maximum resolution
- 3840 x 2160 pixels
- Built-in speaker(s)
- Yes
- Placement supported
- Indoor & outdoor
- Card reader integrated
- Yes
- Ethernet LAN
- No
- Zoom capability
- Yes
- Diameter
- 9.8 cm
- International Protection (IP) code
- IP64
- Digital zoom
- 16x
- Rechargeable battery
- Yes
- Colour Temperature
- 6500 K
- Frame Rate
- 15 fps
- Product colour
- White
- Tilt angle range
- 0 - 140°
- Mobile network connection
- Yes
- Video recording
- Yes
- Virtual assistant
- Google Assistant
- Mobile network generation
- 4G
- 4G standard
- LTE-TDD & LTE-FDD
- 3G standards
- WCDMA
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 8 MP
- Motion sensor
- Yes
- PTZ control
- Yes
- Fixed focus
- Yes
- Optical sensor size
- 25.4 / 2.7 mm (1 / 2.7")
- Pan range
- 0 - 355°
- Lens viewing angle, diagonal
- 110°
- Video compression formats
- H.265
- Video motion detection
- Yes
- Number of cameras
- 1
- Night vision distance
- 10 m
- Motion sensor technology
- Passive infrared (PIR) sensor
- Built-in HDD
- No
- Lens viewing angle, vertical
- 47°
- Lens viewing angle, horizontal
- 90°
- Number of sensors
- 1
- Infra-red wavelength
- 850 nm
- Alert notification type
- E-mail, Push notification
- Weatherproof
- Yes
- Intelligent Video Surveillance (IVS) system features
- Vehicle detection
- Number of illumination LEDs
- 2
- Built-in light
- Yes
- Warnings
- The product contains electronic components; do not dispose of with the normal household waste.
