Pinhole Network Camera HUM4231SP-L5-S3
    DAHUA TECHNOLOGY CO., LTD

    Pinhole Network Camera HUM4231SP-L5-S3

    €107.28
    Tax included
    Quantity

    Add to favorites Add to compare
    Camera
    Image Sensor 1/3" CMOS
    Max. Resolution 1920 (H) × 1080 (V)
    ROM 128 MB
    RAM 128 MB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    Min. Illumination 0.01 lux@F1.6 (Color, 30 IRE)
    0.001 lux@F1.6 (B/W, 30 IRE)
    S/N Ratio >56 dB
    Lens
    Lens Type Fixed-focal
    Lens Mount M12
    Focal Length 2.8 mm
    Max. Aperture F1.6
    Field of View L5-2.8 mm: Horizontal: 95°; Vertical: 52°; Diagonal: 114°
    Iris Control Fixed
    Close Focus Distance L5-2.8 mm: 1.1 m (3.61 ft)
    DORI Distance Lens Detect Observe Recognize Identify
    2.8 mm 63.6 m
    (208.66 ft)         		25.4 m
    (83.33 ft)         		12.7 m
    (41.67 ft)         		6.4 m
    (23.00 ft)



    Smart Event
    IVS Intrusion; tripwire
    Video
    Video Compression H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)
    Smart Codec Smart H.265+; Smart H.264+
    Video Frame Rate Main stream:1920 × 1080 @(1–25/30 fps )
    sub stream: 704 × 576 @ (1–25 fps)/704 × 480 @(1–30 fps)
    *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
    Stream Capability 2 streams
    Resolution 1080p (1920 × 1080); 1.3M (1920 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF(352 ×288/352 × 240)
    Bit Rate Control CBR/VBR
    Video Bit Rate H.264: 3 kbps–6144 kbps
    H.265: 3 kbps–6144 kbps
    Day/Night Color/B/W
    BLC Yes
    HLC Yes
    WDR 120 dB
    White Balance Auto; natural; street lamp; outdoor; manual; regional custom
    Gain Control Auto; manual
    Noise Reduction 3D NR
    Motion Detection OFF/ON (4 areas, rectangular)
    Region of Interest (RoI) Yes (4 areas)
    Image Rotation 0°/90°/180°/270° (Support 90°/270° with 1080P resolution and lower)
    Mirror Yes
    Privacy Masking 4 areas
    Audio
    Built-in MIC Yes
    Audio Compression G.711a; G.711Mu; PCM; G.726
    Alarm
    Alarm Event Network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; security exception
    Network
    Network Port RJ-45 (10/100 Base-T)
    SDK and API Yes
    Cyber Security Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
    Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
    Interoperability ONVIF (Profile S/Profile T); CGI; P2P; Milestone
    User/Host 20 (Total bandwidth: 48 M)
    Storage FTP; SFTP; NAS
    Browser IE
    Chrome
    Firefox
    Management Software Smart PSS; DSS; DMSS
    Mobile Client iOS; Android
    Certification
    Certifications CE-LVD: EN62368-1;
    CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
    FCC:47 CFR FCC Part 15, Subpart B
    Port
    Audio Input 1 channel (RCA port)
    Audio Output 1 channel (RCA port)
    Power
    Power Supply 12 VDC
    Power Consumption Basic: 1.2 W (12 VDC)
    Max. (H.265 + intelligence on + WDR): 1.56 W (12 VDC)
    Environment
    Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)
    Operating Humidity ?95%
    Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
    Structure
    Casing Metal
    Product Dimensions 31.0 mm × 31.0 mm × 37.1 mm (1.22" × 1.22" × 1.46") (L × W × H)
    Net Weight 81 g (0.18 lb)
    Gross Weight 138 g (0.30 lb)


    Product Details
