4K IP network camera 12M, IR, HDBW81230EP-ZH-S2

Features:• 1/1.7” 12Megapixel progressive scanExmor R CMOS• Support H.265&H.264dualencoding• Max 20fps@12MP(4000× 3000),25/30fps@4K(3840x2160)• DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS• 4.1mm ~16.4mm motorizedlens• Max. IR LEDs Length 50m• IP67,IK10,PoETechnical Specifications:Camera• Image Sensor 1/1.7”12Megapixel progressive scan Exmor RCMOS• Effective Pixels 4000(H) x 3000(V)• Scanning System Progressive• Electronic Shutter Speed Auto/Manual, 1/3(4)~1/100000s• Min. Illumination 0.02Lux/F1.53(Color);0Lux/F1.53(IR on)• S/N Ratio More than 50dB• Video Output 1 portCamera Features• Max. IR LEDs Length 50m• Day/Night Auto(ICR)/Color/B/W• Backlight Compensation BLC / HLC /DWDR/SSA• White Balance Auto/Natural/Street Lamp/Outdoor/Manual• Gain Control Auto/Manual• Noise Reduction 3D• Privacy Masking Up to 4 areas• EIS Support• Ultra Defog Support• Smart focus Auto focusLens• Focal Length 4.1mm~16.4mm• Max Aperture F1.53• Focus Control Motorized• Angle of View H: 112 ?~35?V:79 ? ~28 ?• Lens Type Motorized/ Auto Iris(DC)• Mount Type Board-in TypeVideo• Compression H.265/ H.264• Resolution 12M(4000× 3000)/8M(3840× 2160)/6M(3072× 2048)/5M(2560× 1920)/3M(2048× 1536)/3M(2304x1296)1080P(1920× 1080)/1.3M(1280× 960)/720P(1280× 720)/D1(704× 576/704x480) /VGA(640x480)/CIF(352×288/342x240)Frame Rate• Main Stream 12M(1~20fps)/8M(1~25/30fps)• Sub Stream D1/VGA/CIF(1 ~ 25/30fps)• Third Stream 1080P/720P/D1(1 ~ 25/30fps)• Bit Rate H.265: 19 ~ 9984 Kbps• H.264: 32 ~ 16384 Kbps• ROI Up to 4 areasAudio• Compression G.711a/ G.711Mu/G.726/AAC• Interface 1/1 channel In/OutSmart Function(Optional)• Smart detection• Tripwire• Intrusion• Object Abandoned• ObjectMissing• Audio detect• Defocus detect• Face detect• Intelligent function• People Counting• Heat MapNetwork• Ethernet RJ-45 (100/1000Base-T)• Wi-Fi N/A• Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP,RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x,ONVIF Profile S&G, PSIA, CGI• Max. User Access 20users• Smart Phone iPhone, iPad, Android PhoneAuxiliary Interface• Memory Slot Micro SD, Max 128GB• RS485 N/A• Alarm 1/1 channel In/OutGeneral• Power Supply DC12V/AC24V, PoE (802.3at)• Power Consumption <18W (with IR on, motorized lens working)• Working Environment -40°C~+60°C, Less than 95% RH• Ingress Protection IP67• Vandal Resistance IK10• Dimensions 159mm× 117.9mm• Weight 0.96kg(1.75kg with packaging)
