Hikvision

    HIKVISION IP CAMERA DS-2CD2543G2-IS (2.8MM)

    €197.97
    Tax included
    Quantity

    Add to favorites Add to compare

    Product Details

    WLONONWCRFRAF
    7 Items

    Data sheet

    Type
    IP security camera
    Height
    57.4 mm
    Connectivity technology
    Wired
    Weight
    380 g
    Package depth
    134 mm
    Package height
    108 mm
    Package width
    134 mm
    Package weight
    615 g
    Power source type
    DC, PoE
    Storage relative humidity (H-H)
    0 - 95%
    Operating temperature (T-T)
    -30 - 60 °C
    Operating relative humidity (H-H)
    0 - 95%
    Storage temperature (T-T)
    -30 - 60 °C
    Mounting type
    Ceiling/wall
    Form factor
    Dome
    Built-in microphone
    Yes
    Bluetooth
    No
    Bit rate
    32 Kbps - 8 Mbps
    Noise reduction
    Yes
    Sensor type
    CMOS
    Wi-Fi
    No
    Compatible memory cards
    MicroSD (TransFlash)
    Maximum memory card size
    256 GB
    Audio formats supported
    MP3
    Signal-to-Noise Ratio (SNR)
    52 dB
    Power consumption (max)
    5.5 W
    Maximum resolution
    2688 x 1520 pixels
    Placement supported
    Outdoor
    Card reader integrated
    Yes
    Ethernet LAN (RJ-45) ports
    1
    Number of languages
    33
    Audio output channels
    1.0 channels
    Ethernet LAN
    Yes
    Supported graphics resolutions
    1280 x 720 (HD 720)
    Diameter
    11 cm
    International Protection (IP) code
    IP67
    Ethernet interface type
    Fast Ethernet
    Number of Users
    32 user(s)
    Web-based management
    Yes
    Quality of Service (QoS) support
    Yes
    Reset button
    Yes
    Password protection
    Yes
    Languages support
    Multi
    Frame Rate
    30 fps
    Product colour
    Black
    Tilt angle range
    0 - 75°
    Fixed focal length
    2.8 mm
    Voice codecs
    G.711ulaw
    LED type
    IR
    Night vision
    Yes
    Total megapixels
    4 MP
    Optical sensor size
    25.4 / 3 mm (1 / 3")
    Minimum illumination
    0 lx
    Pan range
    -30 - 30°
    Dynamic range
    120 dB
    Lens viewing angle, diagonal
    123.8°
    Video compression formats
    H.264+
    Angle of rotation
    360°
    DC output current
    0.45 A
    DC output voltage
    12
    Video motion detection
    Yes
    Number of cameras
    1
    Camera pan control
    Yes
    Camera tilt control
    Yes
    Night vision distance
    30 m
    Number of lenses
    1
    Day/night mode
    Yes
    Infrared (IR) cut-off filter
    Yes
    Built-in HDD
    No
    Lens viewing angle, vertical
    55.9°
    Noise reduction technology
    3D noise reduction
    Region of Interest (ROI) encoding
    Yes
    Maximum aperture number
    1.6
    Lens viewing angle, horizontal
    104.3°
    Number of sensors
    1
    Infra-red wavelength
    850 nm
    Wide Dynamic Range (WDR)
    Yes
    Progressive scan
    Yes
    Heartbeat
    Yes
    Anti-flicker
    Yes
    Back Light Compensation (BLC)
    Yes
    Video streaming
    Yes
    Active tampering alarm
    Yes
    Alarm input/output
    Yes
    IP address filtering
    Yes
    Intelligent Video Surveillance (IVS) system features
    Face detection
    Camera shutter speed
    1/3 - 1/100000 s
    Bit rate control
    Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
    Gain control type
    Auto
    Highlight Compensation (HLC)
    Yes
    Live view
    Yes
    Power consumption (Power over Ethernet (PoE))
    7 W
    HTTPS encryption
    Yes
    Behavior analysis
    Intrusion detection, Line crossing detection
    Image quality adjustment
    Contrast
    IK code
    IK08
    Lens mount interface
    M12
    Password reset via email
    Yes
    Iris
    Yes
    Number of simultaneous live view channels
    6 channels
    User access level
    Administrator, Operator, User
    Audio input channels
    1.0 channels
    Detect distance
    64 m
    Identify distance
    6 m
    Pixel counter
    Yes
    Client interoperability
    iVMS-4200, Hik-Connect, Hik-Central
    Bit rate range
    8 - 320 Kbit/s
    Alarm output channels
    1
    Alarm input channels
    1
    Sample rates
    8 - 48 kHz
    Automatic Network Replenishment (ANR)
    Yes
    Audit log
    Yes

    Quick Compare

    Product
    		 DS-2CD2366G2-IU(2.8mm)(C)(BLACK) HIKVISION IP CAMERA DS-2CD2366G2H-IU(2.8mm)/BLACK IP Camera HIKVISION DS-2CD2066G2H-IU(2.8mm)(eF)(O-STD)/BLACK Camera DS-2CD2066G2H-I2U/SL(2.8mm)
    Availability
    Price
    €186.60
    €187.04
    €187.04
    €187.04
    Description
    Type
    		 IP security camera IP security camera IP security camera IP security camera
    Height
    		 115.4 mm
    Depth
    		 179.2 mm
    Connectivity technology
    		 Wired Wired Wired Wired
    Weight
    		 740 g 770 g 505 g 505 g
    Package depth
    		 170 mm 170 mm 120 mm 120 mm
    Package height
    		 150 mm 160 mm 117 mm 117 mm
    Package width
    		 170 mm 170 mm 234 mm 234 mm
    Package weight
    		 1.07 kg 1.04 kg 815 g 830 g
    Power source type
    		 DC, PoE DC, PoE DC, PoE DC, PoE
    Storage relative humidity (H-H)
    		 0 - 95% 0 - 95% 0 - 95% 0 - 95%
    Operating temperature (T-T)
    		 -30 - 60 °C -30 - 60 °C -30 - 60 °C -30 - 60 °C
    Operating relative humidity (H-H)
    		 0 - 95% 0 - 95% 0 - 95% 0 - 95%
    Storage temperature (T-T)
    		 -30 - 60 °C -30 - 60 °C -30 - 60 °C -30 - 60 °C
    Mounting type
    		 Ceiling/wall Ceiling/wall Ceiling/wall Ceiling/wall
    Form factor
    		 Turret Turret Bullet Bullet
    Built-in microphone
    		 Yes Yes Yes Yes
    Bluetooth
    		 No No No No
    Bit rate
    		 32 Kbps - 16 Mbps 32 Kbps - 16 Mbps 32 Kbps - 16 Mbps 32 Kbps - 16 Mbps
    Noise reduction
    		 Yes Yes Yes Yes
    Protection features
    		 Dust resistant Water resistant Water resistant Dust resistant
    Length
    		 176.3 mm
    Sensor type
    		 CMOS CMOS CMOS CMOS
    Wi-Fi
    		 No No No No
    Compatible memory cards
    		 microSDHC MicroSDXC MicroSD (TransFlash) MicroSDXC
    Maximum memory card size
    		 256 GB 512 GB 512 GB
    Audio formats supported
    		 MP3 MP3
    Signal-to-Noise Ratio (SNR)
    		 52 dB 52 dB 52 dB 52 dB
    Power consumption (max)
    		 5.4 W 6.5 W 8.5 W 15 W
    Maximum resolution
    		 3200 x 1800 pixels 3200 x 1800 pixels 3200 x 1800 pixels
    Built-in speaker(s)
    		 Yes
    Placement supported
    		 Indoor & outdoor Outdoor Indoor & outdoor Outdoor
    Card reader integrated
    		 Yes Yes Yes Yes
    Ethernet LAN (RJ-45) ports
    		 1 1 1 1
    Number of languages
    		 33 33 33
    Housing material
    		 Metal Metal Metal Metal
    Networking standards
    		 IEEE 802.3af IEEE 802.3af IEEE 802.1x IEEE 802.3at
    Security algorithms
    		 TLS EAP-TLS EAP-MD5 EAP-LEAP
    Ethernet LAN
    		 Yes Yes Yes Yes
    Supported graphics resolutions
    		 640 x 360 1280 x 720 (HD 720) 1280 x 720 (HD 720) 2688 x 1520
    Diameter
    		 13.8 cm 13.8 cm 7.44 cm 7.44 cm
    International Protection (IP) code
    		 IP67 IP67 IP67 IP67
    Ethernet interface type
    		 Fast Ethernet Fast Ethernet Fast Ethernet Fast Ethernet
    Video formats supported
    		 H.264
    Number of Users
    		 32 user(s) 32 user(s) 32 user(s) 32 user(s)
    Web-based management
    		 Yes Yes
    Quality of Service (QoS) support
    		 Yes Yes Yes
    Reset button
    		 Yes Yes Yes Yes
    Browser supported
    		 IE 10, IE 11, Chrome 57.0+, Firefox 52.0+ IE 10, IE 11, Chrome 57.0+, Firefox 52.0+
    Password protection
    		 Yes Yes Yes Yes
    Languages support
    		 Multi Multi Multi Multi
    Frame Rate
    		 30 fps 30 fps 30 fps 30 fps
    Product colour
    		 Black Black Black White
    Tilt angle range
    		 0 - 75° 0 - 75° 0 - 90° 0 - 90°
    Fixed focal length
    		 2.8 mm 2.8 mm 2.8 mm 2.8 mm
    Web browser
    		 Yes
    Video recording
    		 Yes
    Voice codecs
    		 G.711alaw
    LED type
    		 IR IR IR IR
    Night vision
    		 Yes Yes Yes Yes
    Total megapixels
    		 6 MP 6 MP 6 MP 6 MP
    Optical sensor size
    		 25.4 / 2.4 mm (1 / 2.4") 25.4 / 2.4 mm (1 / 2.4") 25.4 / 2.4 mm (1 / 2.4") 25.4 / 2.4 mm (1 / 2.4")
    Minimum illumination
    		 0 lx 0 lx 0 lx
    Pan range
    		 0 - 360° 0 - 360° 0 - 360° 0 - 360°
    Dynamic range
    		 120 dB 120 dB 120 dB
    Lens viewing angle, diagonal
    		 143.5° 143.5° 144°
    Video compression formats
    		 H.265+ M-JPEG H.265+ H.265
    Angle of rotation
    		 360° 360° 360° 360°
    DC output current
    		 0.54 A 0.58 A 1.25 A
    DC output voltage
    		 12 12 12 12
    Video motion detection
    		 Yes Yes Yes Yes
    Number of cameras
    		 1 1 1 1
    Camera pan control
    		 Yes
    Camera tilt control
    		 Yes
    Night vision distance
    		 30 m 30 m 40 m 40 m
    Number of lenses
    		 1 1 1 1
    Privacy protection
    		 Yes Yes
    Day/night mode
    		 Yes Yes Yes Yes
    Infrared (IR) cut-off filter
    		 Yes Yes Yes Yes
    Built-in HDD
    		 No No No No
    Lens viewing angle, vertical
    		 53.4° 60° 60° 60°
    Noise reduction technology
    		 3D noise reduction 3D noise reduction 3D noise reduction 3D noise reduction
    Smart IR
    		 Yes Yes
    Region of Interest (ROI) encoding
    		 Yes Yes Yes Yes
    Maximum aperture number
    		 1.6 1 1 1
    Lens viewing angle, horizontal
    		 114.8° 114.8° 115°
    Number of sensors
    		 1 1 1
    Infra-red wavelength
    		 850 nm 850 nm 850 nm 850 nm
    Wide Dynamic Range (WDR)
    		 Yes Yes Yes Yes
    Progressive scan
    		 Yes Yes Yes Yes
    Mirror
    		 Yes Yes Yes Yes
    Heartbeat
    		 Yes Yes Yes Yes
    Anti-flicker
    		 Yes
    Digital watermark
    		 Yes Yes
    Back Light Compensation (BLC)
    		 Yes Yes Yes Yes
    Video streaming
    		 Yes Yes Yes
    Active tampering alarm
    		 Yes Yes Yes Yes
    IP address filtering
    		 Yes Yes Yes Yes
    Intelligent Video Surveillance (IVS) system features
    		 Scene change Face detection Human detection Face detection
    Camera shutter speed
    		 1/3 - 1/100000 s 1/3 s - 1/100000 1/3 - 1/100000 s
    Bit rate control
    		 Constant Bit Rate (CBR)/Variable Bit Rate (VBR) Constant Bit Rate (CBR)/Variable Bit Rate (VBR) Constant Bit Rate (CBR)/Variable Bit Rate (VBR) Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
    Gain control type
    		 Auto
    Privacy masking
    		 Yes Yes Yes Yes
    Highlight Compensation (HLC)
    		 Yes Yes Yes Yes
    Live view
    		 Yes Yes
    Power consumption (Power over Ethernet (PoE))
    		 6.5 W 8 W 18 W
    HTTPS encryption
    		 Yes Yes Yes Yes
    Behavior analysis
    		 Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection Intrusion detection, Line crossing detection Intrusion detection, Line crossing detection
    Image quality adjustment
    		 Contrast Sharpness Brightness Sharpness
    Lens mount interface
    		 M12 M12 M12
    Digest authentication
    		 Yes Yes Yes
    Password reset via email
    		 Yes Yes Yes
    Number of simultaneous live view channels
    		 6 channels 6 channels 6 channels
    User access level
    		 Administrator, Operator, User Administrator, Operator, User Administrator, Operator, User
    Detect distance
    		 64 m 64 m 64 m
    Observe distance
    		 25 m 25 m 25 m
    Recognize distance
    		 12 m 12 m 12 m
    Identify distance
    		 6 m 6 m 6 m
    Pixel counter
    		 Yes Yes Yes
    Human and vehicle targets classification
    		 Yes Yes
    Client interoperability
    		 iVMS-4200, Hik-Connect, Hik-Central iVMS-4200, Hik-Connect, Hik-Central
    Audio codecs
    		 G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
    Bit rate range
    		 8 - 320 Kbit/s 8 - 320 Kbit/s 8 - 320 Kbit/s
    Compliance certificates
    		 UL WEEE UL
    Number of Privacy masking areas
    		 4 4 4
    Sample rates
    		 8 - 48 kHz 8 - 48 kHz 8 - 48 kHz
    Automatic Network Replenishment (ANR)
    		 Yes Yes
    Network access storage (NAS)
    		 Yes Yes
    Warnings
    		 The product contains electronic components; do not dispose of with the normal household waste. Avoid direct contact with water to prevent electrical damage.
    Audit log
    		 Yes Yes Yes
    Flash log
    		 Yes
