Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | 1/2.7" CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Resolution | 3840 (H) × 2160 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM | 128 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM | 256 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination | 0.008 Lux@F1.6 (Color, 30 IRE) 0.0008 Lux@F1.6 (B/W, 30 IRE) 0 lux (Illuminator on) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
S/N Ratio | >56 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illumination Distance | up to 60 m (195.85 ft) (IR); up to 50 m (164.04 ft) (Warm light) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator On/Off Control | Auto; Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator Number | 2 (IR LED); 2 (Warm light) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt/Rotation Range | Pan: 0°–360° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type | Fixed-focal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Mount | M12 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length | 3.6 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture | F1.6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View | 3.6 mm: H: 87°; V: 49°; D: 100°
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Control | Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance | 3.6 mm: 1.9 m (6.23 ft)
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance | Lens | Detect | Observe | Recognize | Identify | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
3.6 mm | 98.7 m (350.07 ft) | 39.5 m (129.59 ft) | 19.7 m (64.63 ft) | 9.9 m (32.48 ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligence | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec | Smart H.265+; Smart H.264+ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Frame Rate | Main stream: 3840 × 2160@(1–20 fps )/2688×1520@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Stream Capability | 2 streams | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2880 × 1620 (2880 × 1620); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 ×480); VGA (640 ×480); CIF (352 × 288/352 × 240) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control | CBR/VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate | H.264: 32 kbps–8192 kbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night | Auto(ICR)/Color/B/W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR | 120 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control | Auto; Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction | 3D NR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection | OFF/ON (4 areas, rectangular) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest (RoI) | Yes (4 areas) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Illumination | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirror | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking | 4 areas | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Built-in MIC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | G.711a; G.711Mu; G.726; PCM | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception; external alarm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Port | RJ-45 (10/100 Base-T) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SDK and API | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Boujour; P2P | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF (Profile S/Profile T/Profile G); CGI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User/Host | 20 (Total bandwidth: 48 M) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage | FTP; SFTP; Micro SD card (support max. 256 GB) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software | SmartPSS Lite;DSS;DMSS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser | IE; Chrome; Firefox | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Client | iOS; Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications | CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input | 1 channel (RCA port) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output | 1 channel (RCA port) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input | 1 channel in: 5 mA 3–5 VDC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output | 1 channel out: 300 mA 12 VDC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 12 VDC/PoE (802.3af) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | Basic: 2.6 W (12 VDC); 3.4 W (PoE) Max. (H.265+ max. resolution + max. stream+ WDR + illuminator intensity + IVS): 7 W (12 VDC); 8.3 W (PoE) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | ?95% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Humidity | ?95% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection | IP67; IK10 (optional) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Anti-corrosion Level | Low | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing Material | Metal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions | 238.5 mm × 90.7 mm × 90.7 mm (9.39" × 3.57" × 3.57") (L × W × H) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 0.72 kg (1.59 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 0.97 kg (2.14 lb) |
Quick Compare
Product |
Kamera IP Hikvision DS-2DE2A404IW-DE3(C0)(S6)(C) | KAMERA IP HIKVISION DS-2DE2A404IW-DE3 (S6) | KAMERA IP PTZ HIKVISION DS-2DE2A204IW-DE3/W(S6)(C) | KAMERA IP HIKVISION DS-2CD2047G2-LU (2.8mm) (C) |
Availability |
|
|
|
|
Price |
€204.75
|
€204.76
|
€204.76
|
€206.44
|
Description |
||||
Type |
IP security camera | IP security camera | IP security camera | IP security camera |
Width |
78.8 mm | |||
Height |
101.7 mm | 101.7 mm | 101.7 mm | |
Depth |
78.6 mm | |||
Connectivity technology |
Wired | Wired | Wired | Wired |
Weight |
530 g | 530 g | 530 g | 695 g |
Package depth |
137 mm | |||
Package height |
141 mm | |||
Package width |
315 mm | |||
Package weight |
1.09 kg | |||
Power source type |
DC, PoC | DC, PoE | DC, PoE | DC, PoE |
Storage relative humidity (H-H) |
0 - 95% | |||
Operating temperature (T-T) |
-20 - 60 °C | -20 - 60 °C | -20 - 60 °C | -30 - 60 °C |
Operating relative humidity (H-H) |
0 - 90% | 0 - 90% | 0 - 90% | 0 - 95% |
Storage temperature (T-T) |
-30 - 60 °C | |||
Mounting type |
Ceiling | Ceiling | Ceiling | Ceiling/wall |
Form factor |
Dome | Dome | Dome | Bullet |
Built-in microphone |
Yes | Yes | Yes | |
Bluetooth |
No | No | No | No |
Sample rate |
48 kHz | |||
Bit rate |
32 Kbps - 8 Mbps | |||
Noise reduction |
Yes | Yes | Yes | Yes |
Microphone in |
Yes | |||
Protection features |
Water resistant | Water resistant | ||
Length |
21.5 cm | |||
Sensor type |
CMOS | CMOS | CMOS | CMOS |
Wi-Fi |
No | No | Yes | No |
Compatible memory cards |
MicroSD (TransFlash) | MicroSD (TransFlash) | MicroSDXC | microSDHC |
Wi-Fi standards |
802.11g | |||
Maximum memory card size |
256 GB | 256 GB | 256 GB | 256 GB |
Audio formats supported |
G.722.1 | MP3 | ||
Signal-to-Noise Ratio (SNR) |
52 dB | 52 dB | 52 dB | |
Power consumption |
60 mA | |||
Power consumption (max) |
9.2 W | 9.2 W | 11.2 W | 6 W |
Maximum resolution |
2560 x 1440 pixels | 2560 x 1440 pixels | 1920 x 1080 pixels | 2688 x 1520 pixels |
Placement supported |
Indoor & outdoor | Indoor & outdoor | Indoor & outdoor | Outdoor |
Card reader integrated |
Yes | Yes | Yes | Yes |
Ethernet LAN (RJ-45) ports |
1 | 1 | 1 | 1 |
Number of languages |
33 | |||
Audio output channels |
1 channels | 1 channels | ||
Networking standards |
IEEE 802.3af | IEEE 802.3af | IEEE 802.1x | |
Security algorithms |
TLS | EAP-MD5 | HTTPS | |
Ethernet LAN |
Yes | Yes | Yes | Yes |
Focus |
Manual | Manual | ||
Supported graphics resolutions |
704 x 576 | 352 x 288 | 352 x 240 | 1280 x 720 (HD 720) |
Zoom capability |
Yes | Yes | ||
Diameter |
13.1 cm | 13.1 cm | 13.1 cm | |
International Protection (IP) code |
IP65 | IP65 | IP66 | IP67 |
Digital zoom |
16x | 16x | 16x | |
Wi-Fi data rate (max) |
54 Mbit/s | |||
Auto focus |
Yes | Yes | ||
Ethernet interface type |
Fast Ethernet | Fast Ethernet | Fast Ethernet | |
Optical Zoom |
4x | 4x | 4x | |
Number of Users |
32 user(s) | 32 user(s) | 32 user(s) | 32 user(s) |
Web-based management |
Yes | Yes | ||
Quality of Service (QoS) support |
Yes | Yes | Yes | |
Reset button |
Yes | Yes | Yes | Yes |
Password protection |
Yes | Yes | Yes | Yes |
Languages support |
German | |||
Frame Rate |
30 fps | 30 fps | 30 fps | |
Product colour |
Black | White | Black | White |
Tilt angle range |
0 - 90° | 0 - 90° | 0 - 90° | 0 - 90° |
Sustainability certificates |
CE | |||
Focal length range |
2.8 - 12 mm | 2.8 - 12 mm | 2.8 - 12 mm | |
Fixed focal length |
2.8 mm | |||
Web browser |
Yes | Yes | Yes | |
Voice codecs |
G.711alaw | G.722.1 | G.711ulaw | |
LED type |
IR | IR | IR | |
Night vision |
Yes | Yes | Yes | Yes |
Total megapixels |
4 MP | 4 MP | 2 MP | 4 MP |
PTZ control |
Yes | Yes | ||
Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") | 25.4 / 2.8 mm (1 / 2.8") | 25.4 / 2.8 mm (1 / 2.8") | 25.4 / 1.8 mm (1 / 1.8") |
Minimum illumination |
0.005 lx | |||
Pan range |
0 - 355° | 0 - 355° | 0 - 355° | 0 - 360° |
Dynamic range |
120 dB | 120 dB | ||
Video compression formats |
H.264+ | H.265 | H.264+ | H.264 |
Angle of rotation |
360° | |||
DC output current |
0.5 A | |||
DC output voltage |
12 | 12 | 12 | 12 |
Video motion detection |
Yes | Yes | Yes | Yes |
Number of cameras |
1 | 1 | 1 | 1 |
Camera pan control |
Yes | Yes | Yes | |
Camera tilt control |
Yes | Yes | Yes | |
Night vision distance |
20 m | 20 m | 20 m | 40 m |
Number of lenses |
1 | 1 | 1 | |
Day/night mode |
Yes | Yes | Yes | Yes |
Infrared (IR) cut-off filter |
Yes | Yes | Yes | |
Built-in HDD |
No | No | No | No |
Lens viewing angle, vertical |
61° | |||
Noise reduction technology |
3D noise reduction | 3D noise reduction | 3D noise reduction | 3D noise reduction |
Region of Interest (ROI) encoding |
Yes | Yes | Yes | |
Maximum aperture number |
1.5 | 1.5 | 1.5 | 1 |
Channel bandwidth |
40 MHz | |||
Lens viewing angle, horizontal |
112° | |||
Number of sensors |
1 | 1 | 1 | 1 |
Infra-red wavelength |
850 nm | 850 nm | 850 nm | |
Alert notification type |
||||
Wide Dynamic Range (WDR) |
Yes | Yes | Yes | Yes |
Progressive scan |
Yes | Yes | Yes | |
Mirror |
Yes | Yes | Yes | Yes |
Heartbeat |
Yes | |||
Anti-flicker |
Yes | |||
Digital watermark |
Yes | Yes | ||
Back Light Compensation (BLC) |
Yes | Yes | Yes | Yes |
Video streaming |
Yes | Yes | Yes | |
Active tampering alarm |
Yes | Yes | Yes | |
IP address filtering |
Yes | Yes | Yes | |
Intelligent Video Surveillance (IVS) system features |
Face detection | Face detection | Face detection | Scene change |
Camera shutter speed |
1/3 - 1/100000 s | 1/1 - 1/30000 s | 1/1 - 1/30000 s | 1/3 - 1/100000 s |
Gain control type |
Auto | Auto | ||
Privacy masking |
Yes | Yes | Yes | Yes |
Highlight Compensation (HLC) |
Yes | Yes | Yes | Yes |
Live view |
Yes | Yes | ||
Power consumption (Power over Ethernet (PoE)) |
7.5 W | |||
HTTPS encryption |
Yes | Yes | Yes | |
Behavior analysis |
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection | |||
Image quality adjustment |
Saturation | Saturation | Contrast | Sharpness |
IK code |
IK10 | IK10 | IK10 | |
Number of simultaneous live view channels |
6 channels | |||
User access level |
Administrator, Operator, User | Administrator, Operator, User | Administrator, Operator, User | |
Identify distance (wide) |
2 m | |||
Recognize distance (wide) |
11 m | |||
Pan speed |
100 °/sec | 100 °/sec | 100 °/sec | |
Audio input channels |
1 channels | 1 channels | ||
Observe distance (wide) |
23 m | |||
Closest focusing distance |
2.5 m | |||
Detect distance (wide) |
58 m | |||
Identify distance (tele) |
18 m | |||
Tilt speed |
100 °/sec | 100 °/sec | 100 °/sec | |
Pan preset speed |
100 °/sec | 100 °/sec | ||
Tilt preset speed |
100 °/sec | 100 °/sec | ||
Preset programs quantity |
300 | |||
