IP Network Camera 2MP HDW1230DT-STW 2.8mm
    DAHUA TECHNOLOGY CO., LTD

    IP Network Camera 2MP HDW1230DT-STW 2.8mm

    €93.84
    Tax included
    Quantity

    Add to favorites Add to compare
    Camera
    Image Sensor 1/3" CMOS
    Max. Resolution 1920 (H) × 1080 (V)
    ROM 16 MB
    RAM 64 MB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    Min. Illumination 0.025 lux@F2.0 (Color, 30 IRE) 0.0025 lux@F2.0 (B/W, 30 IRE) 0 lux (Illuminator on)
    S/N Ratio > 56 dB
    Illumination Distance 30 m (98.43 ft)
    Illuminator On/Off Control Auto; Manual
    Illuminator Number 1 (IR LED)
    Pan/Tilt/Rotation Range Pan: 0°–360°
    Tilt: 0°–78°
    Rotation: 0°–360°
    Lens
    Lens Type Fixed-focal
    Lens Mount M12
    Focal Length 2.8 mm
    Max. Aperture F2.0
    Field of View 2.8 mm:
    Horizontal: 100°; Vertical: 53°; Diagonal: 120°
    Iris Control Fixed
    Close Focus Distance 2.8 mm: 0.6 m (1.97 ft)
    DORI Distance Lens Detect Observe Recognize Identify
    2.8 mm 46.9 m (153.87 ft) 18.8 m (61.68 ft) 9.4 m (30.84 ft) 4.7 m (15.42 ft)
    Video
    Video Compression H.264B; H.264; H.264H; H.265
    Smart Codec Smart H.265+; Smart H.264+
    Video Frame Rate Main stream:
    1920 × 1080 (1–25/30 fps)
    Sub stream:
    704 × 576 (1–25 fps)
    704 × 480 (1–30 fps)
    *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
    Stream Capability 2 streams
    Resolution 1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720)
    Bit Rate Control CBR/VBR
    Video Bit Rate H264: 24 kbps–4096 kbps H265: 9 kbps–4096 kbps
    Day/Night Auto (ICR)/Color/B/W
    BLC Yes
    WDR DWDR
    White Balance Auto; natural; street lamp; outdoor; manual; regional custom
    Gain Control Auto
    Noise Reduction 3D NR
    Motion Detection OFF/ON (4 areas, rectangular)
    Smart Illumination Yes
    Image Rotation 0°/180°
    Mirror Yes
    Audio
    Built-in MIC Yes
    Built-in Speaker Yes
    Audio Compression G.711a; G.711Mu
    Alarm
    Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; intensity change; SMD (human)
    Network
    Network Port RJ-45 (10/100 Base-T)
    Wi-Fi IEEE802.11b/g/n 2.4–2.4835 GHz; 2.4 G
    Wireless Range Up to 120m(The performance varies based on actual environment)
    SDK and API Yes
    Cyber Security Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
    Network Protocol IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast; RTMP
    Interoperability ONVIF (Profile S/Profile T); CGI; P2P
    User/Host 6 (Total bandwidth: 36 M)
    Storage Micro SD card (support max. 256 GB)
    Browser IE
    Chrome
    Firefox
    Management Software Smart PSS; DSS; DMSS
    Mobile Client iOS; Android
    Certification
    Certifications CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; CE-RED: Radio Equipment Directive 2014/53/EU; FCC: 47 CFR FCC Part 15, Subpart B; FCC ID: FCC PART 15C
    Power
    Power Supply 12 VDC
    Power Consumption Basic: 1.9 W (12 VDC) Max. (H.265+IR intensity): 6.1 W (12 VDC)
    Environment
    Operating Temperature –30 °C to +60 °C (–22 °F to +140 °F)
    Operating Humidity ? 95%
    Storage Temperature –30 °C to +60 °C (–22 °F to +140 °F)
    Protection IP67
    Structure
    Casing Inner core: Metal + Plastic Cover: Plastic
    Product Dimensions Ø109.9 mm × 102.2 mm (Ø4.33" × 4.02")
    Net Weight 352 g (0.77 lb)
    Gross Weight 530 g (1.17 lb)

    Product Details
