With 5MP/3K live monitoring and 0~355° pan & -5~50°tilt features, Ranger Mini 5MP ensures every corner of your home completely covered. The Integrated-Bracket design allows easy installation either Ceiling Mounting or Wall Mounting. Human Detection quickly finds human targets in images and immediately sends a notification to you. Privacy Mode helps protect your personal privacy when you are home, and Smart Tracking function lets the camera follows moving objects when it detects motion.
Product Details
Data sheet
- Garantija
- 24
- Category Code
- NCI
- Unit Box Height
- 0.105
- Unit Box Length
- 0.13
- Unit Box Width
- 0.12
- Vendor Homepage
- https://www.imou.com/na/product/detail/ranger-mini
- Model name
- Ranger Mini 5MP
- MODEL
- IPC-K2MP-5H1WE
- Units per Shipping Box
- 1
- Unit Calculated Weight
- 0.38 kg
- Unit Calculated Volume
- 0.001638 cubm
- Summary
- Imou Ranger Mini 5MP (3K). Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired & Wireless. Mounting type: Ceiling/wall, Product colour: White, Form factor: Dome. Lens viewing angle, horizontal: 87 , Lens viewing angle, ve
- Weight & dimensions (Weight)
- 200 g
- Weight & dimensions (Width)
- 95 mm
- Weight & dimensions (Depth)
- 96 mm
- Weight & dimensions (Height)
- 109.2 mm
- Network (Ethernet LAN)
- Yes
- Network (Wi-Fi)
- Yes
- Design (Product colour)
- White
- Network (Wi-Fi standards)
- 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 6 (802.11ax)
- Power (Power consumption (max))
- 4.2 W
- Audio (Audio system)
- 2-way
- Operational conditions (Operating temperature (T-T))
- -10 - 45 C
- Design (Form factor)
- Dome
- System requirements (Mobile operating systems supported)
- Android/iOS
- Sustainability (Compliance certificates)
- CE
- Storage (Card reader integrated)
- Yes
- Storage (Compatible memory cards)
- MicroSD (TransFlash)
- Storage (Maximum memory card size)
- 512 GB
- Audio (Built-in speaker(s))
- Yes
- Network (Ethernet interface type)
- Fast Ethernet
- Packaging content (Screws included)
- Yes
- Power (Power source type)
- DC
- Audio (Built-in microphone)
- Yes
- Performance (Type)
- IP security camera
- Performance (Connectivity technology)
- Wired & Wireless
- Performance (Placement supported)
- Indoor
- Design (Mounting type)
- Ceiling/wall
- Camera (Lens viewing angle, diagonal)
- 108
- Camera (Lens viewing angle, horizontal)
- 87
- Camera (Lens viewing angle, vertical)
- 48
- Image sensor (Number of sensors)
- 1
- Image sensor (Optical sensor size)
- 1/3 "
- Image sensor (Progressive scan)
- Yes
- Image sensor (Sensor type)
- CMOS
- Lens system (Digital zoom)
- 8 x
- Lens system (Fixed focal length)
- 3.6 mm
- Lens system (Number of lenses)
- 1
- Lens system (Zoom capability)
- Yes
- Night vision (Night vision)
- Yes
- Night vision (Night vision distance)
- 10 m
- Video (Frame rate)
- 20 fps
- Video (Maximum resolution)
- 2688 x 1664 pixels
- Video (Total megapixels)
- 5 MP
- Video (Video compression formats)
- H.264/H.265
- Storage (Built-in HDD)
- No
- Security (Video motion detection)
- Yes
- Management features (Reset button)
- Yes
- Power (DC output current)
- 1 A
- Power (DC output voltage)
- 5
- Packaging content (Number of cameras)
- 1
- Camera (Pan range)
- 0 - 355
- Camera (Tilt angle range)
- -5 - 50
- Performance (Auto-tracking)
- Yes
- Security (Privacy protection)
- Yes
- Management features (Cloud-managed)
- Yes
- Packaging content (Mounting brackets included)
- Yes
