KAMERA IP HIKVISION DS-2CD1043G2-LIUF/SL 2.8MM PL

Product Details

Reference CIPHIKKAM0824

In stock 7 Items

Data sheet

Type

IP security camera

Width

179 mm

Height

69.1 mm

Depth

67.4 mm

Connectivity technology

Wired

Weight

315 g

Package depth

121 mm

Package height

118 mm

Package width

216 mm

Package weight

520 g

Power source type

DC, PoE

Storage relative humidity (H-H)

0 - 95%

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-30 - 60 °C

Mounting type

Wall

Bluetooth

No

Bit rate

32 Kbps - 8 Mbps

Noise reduction

Yes

Sensor type

CMOS

Wi-Fi

No

Compatible memory cards

microSDHC

Maximum memory card size

512 GB

Power consumption (max)

7.5 W

Maximum resolution

2560 x 1440 pixels

Placement supported

Outdoor

Card reader integrated

Yes

Ethernet LAN (RJ-45) ports

1

Housing material

Metal, Plastic

Networking standards

IEEE 802.3af

Ethernet LAN

Yes

Supported graphics resolutions

640 x 480 (VGA)

International Protection (IP) code

IP67

Ethernet interface type

Fast Ethernet

Number of Users

32 user(s)

Quality of Service (QoS) support

Yes

Password protection

Yes

Frame Rate

25 fps

Product colour

White

Tilt angle range

0 - 90°

Fixed focal length

2.8 mm

LED type

IR/White

Night vision

Yes

Total megapixels

4 MP

Optical sensor size

25.4 / 3 mm (1 / 3")

Pan range

0 - 360°

Lens viewing angle, diagonal

114°

Video compression formats

M-JPEG

Angle of rotation

360°

DC output current

0.62 A

DC output voltage

12

Video motion detection

Yes

Number of cameras

1

Night vision distance

30 m

Day/night mode

Yes

Infrared (IR) cut-off filter

Yes

Lens viewing angle, vertical

54°

Region of Interest (ROI) encoding

Yes

Maximum aperture number

1.6

Lens viewing angle, horizontal

98°

Infra-red wavelength

850 nm

Wide Dynamic Range (WDR)

120 dB

Progressive scan

Yes

Mirror

Yes

Heartbeat

Yes

Camera shutter speed

1/3 - 1/100000 s

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Privacy masking

Yes

Highlight Compensation (HLC)

Yes

Power consumption (Power over Ethernet (PoE))

9 W

Identify distance (wide)

6 m

Recognize distance (wide)

12 m

Observe distance (wide)

25 m

Detect distance (wide)

63 m

Warnings

Do not expose the device to moisture or extreme temperatures.
