KAMERA IP HIKVISION DS-2CD1643G2-LIZU 2.8-12mm PL

Product Details

Reference CIPHIKKAM0802

In stock 12 Items

Data sheet

Type

IP security camera

Connectivity technology

Wired

Weight

585 g

Package depth

137 mm

Package height

141 mm

Package width

315 mm

Package weight

910 g

Power source type

DC, PoE

Storage relative humidity (H-H)

0 - 95%

Manual

Yes

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-30 - 60 °C

Mounting type

Wall

Form factor

Bullet

Built-in microphone

Yes

Bluetooth

No

Bit rate

32 Kbps - 16 Mbps

Noise reduction

Yes

Protection features

Dust resistant

Length

252 mm

Sensor type

CMOS

Wi-Fi

No

Compatible memory cards

microSDHC

Maximum memory card size

512 GB

Audio formats supported

G.722.1

Signal-to-Noise Ratio (SNR)

52 dB

Power consumption (max)

10.5 W

Maximum resolution

1920 x 1080 pixels

Placement supported

Indoor & outdoor

Card reader integrated

Yes

Ethernet LAN (RJ-45) ports

1

Number of languages

2

Housing material

Plastic

Networking standards

IEEE 802.3af

Ethernet LAN

Yes

Focus

Motorized

Supported graphics resolutions

640 x 480 (VGA)

Diameter

10.5 cm

International Protection (IP) code

IP67

Ethernet interface type

Fast Ethernet

Supported video modes

480p

Video formats supported

H.264+

Number of Users

32 user(s)

Web-based management

Yes

Quality of Service (QoS) support

Yes

Supported network protocols

TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP

Reset button

Yes

Password protection

Yes

Languages support

Ukrainian

Frame Rate

30 fps

Product colour

White

Tilt angle range

0 - 90°

Focal length range

2.8 - 12 mm

Video recording

Yes

LED type

IR/White

Night vision

Yes

Total megapixels

2 MP

Optical sensor size

25.4 / 3 mm (1 / 3")

Minimum illumination

0 lx

Pan range

0 - 360°

Dynamic range

120 dB

Lens viewing angle, diagonal

114.3 - 34°

Video compression formats

H.264

Angle of rotation

360°

DC output current

0.88 A

DC output voltage

12

Video motion detection

Yes

Number of cameras

1

Night vision distance

50 m

Number of lenses

1

Privacy protection

Yes

Day/night mode

Yes

Infrared (IR) cut-off filter

Yes

Built-in HDD

No

Lens viewing angle, vertical

51.7 - 16.7°

Noise reduction technology

3D noise reduction

Region of Interest (ROI) encoding

Yes

Maximum aperture number

1.6

Lens viewing angle, horizontal

96.7 - 29.7°

Number of sensors

1

Infra-red wavelength

850 nm

Wide Dynamic Range (WDR)

Yes

Progressive scan

Yes

Mirror

Yes

Heartbeat

Yes

Digital watermark

Yes

Back Light Compensation (BLC)

Yes

Video streaming

Yes

Active tampering alarm

Yes

Camera shutter speed

1/3 - 1/100000 s

Bit rate control

Constant Bit Rate (CBR), Variable Bit Rate (VBR)

Privacy masking

Yes

Highlight Compensation (HLC)

Yes

Live view

Yes

Power consumption (Power over Ethernet (PoE))

12 W

HTTPS encryption

Yes

Image quality adjustment

Sharpness

Digest authentication

Yes

Password reset via email

Yes

Number of simultaneous live view channels

6 channels

User access level

Administrator, Operator, User

Identify distance (wide)

6.4 m

Recognize distance (wide)

12.8 m

Built-in light

Yes

Observe distance (wide)

25.4 m

Detect distance (wide)

64 m

Identify distance (tele)

19.8 m

Client interoperability

iVMS-4200, Hik-Connect

Recognize distance (tele)

39.6 m

Detect distance (tele)

198 m

Observe distance (tele)

78.6 m

Bit rate range

16 - 160 Kbit/s

Compliance certificates

Electromagnetic Compatibility (EMC)

Number of Privacy masking areas

4

Sample rates

8 - 16 kHz

Audit log

Yes
