KAMERA IP HIKVISION DS-2CD1183G2-LIUF 2.8mm PL

Product Details

Reference CIPHIKKAM0786

In stock 10 Items

Data sheet

Type

IP security camera

Height

97.6 mm

Connectivity technology

Wired

Weight

550 g

Package depth

150 mm

Package height

141 mm

Package width

150 mm

Package weight

800 g

Power source type

DC, PoE

Storage relative humidity (H-H)

0 - 95%

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-30 - 60 °C

Mounting type

Ceiling

Form factor

Dome

Built-in microphone

Yes

Bluetooth

No

Bit rate

32 Kbps - 16 Mbps

Noise reduction

Yes

Sensor type

CMOS

Wi-Fi

No

Compatible memory cards

MicroSDXC

Maximum memory card size

512 GB

Audio formats supported

G.711 A-law

Signal-to-Noise Ratio (SNR)

52 dB

Power consumption (max)

6 W

Maximum resolution

3840 x 2160 pixels

Placement supported

Indoor & outdoor

Card reader integrated

Yes

Ethernet LAN (RJ-45) ports

1

Number of languages

2

Housing material

Plastic

Ethernet LAN

Yes

Supported graphics resolutions

640 x 360

Diameter

12.2 cm

International Protection (IP) code

IP67

Number of Users

32 user(s)

Web-based management

Yes

Quality of Service (QoS) support

Yes

Supported network protocols

TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP

Password protection

Yes

Frame Rate

15 fps

Product colour

White

Tilt angle range

0 - 75°

Fixed focal length

2.8 mm

Video recording

Yes

LED type

IR

Night vision

Yes

Total megapixels

8 MP

Optical sensor size

25.4 / 2.7 mm (1 / 2.7")

Minimum illumination

0 lx

Pan range

0 - 355°

Dynamic range

120 dB

Lens viewing angle, diagonal

134°

Video compression formats

M-JPEG

Angle of rotation

355°

DC output current

0.5 A

DC output voltage

12

Video motion detection

Yes

Number of cameras

1

Night vision distance

30 m

Number of lenses

1

Day/night mode

Yes

Infrared (IR) cut-off filter

Yes

Built-in HDD

No

Lens viewing angle, vertical

62°

Noise reduction technology

3D noise reduction

Region of Interest (ROI) encoding

Yes

Maximum aperture number

2

Lens viewing angle, horizontal

113°

Number of sensors

1

Infra-red wavelength

850 nm

Wide Dynamic Range (WDR)

Yes

Progressive scan

Yes

Mirror

Yes

Heartbeat

Yes

Digital watermark

Yes

Back Light Compensation (BLC)

Yes

Weatherproof

Yes

Active tampering alarm

Yes

Camera shutter speed

1/3 - 1/100000 s

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Privacy masking

Yes

Highlight Compensation (HLC)

Yes

Live view

Yes

Power consumption (Power over Ethernet (PoE))

7.5 W

Image quality adjustment

Saturation

IK code

IK08

Lens mount interface

M12

Password reset via email

Yes

Iris

Yes

Number of simultaneous live view channels

6 channels

User access level

Administrator, Operator, User

Detect distance

79 m

Observe distance

31 m

Recognize distance

15 m

Identify distance

7 m

Client interoperability

iVMS-4200, Hik-Connect

Bit rate range

16 - 160 Kbit/s

Compliance certificates

Federal Communications Commission (FCC)

Sample rates

8 - 16 kHz
