TP-Link IP Camera InSight S245(2 8mm)

Product Details

Reference WLONONWCRMOE1

In stock 19 Items

Data sheet

Type

IP security camera

Width

122 mm

Height

89 mm

Depth

122 mm

Connectivity technology

Wired

Weight

620 g

Power source type

DC, PoE

Storage relative humidity (H-H)

0 - 95%

Manual

Yes

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-40 - 60 °C

Mounting type

Ceiling

Form factor

Dome

Built-in microphone

Yes

Bluetooth

No

Sample rate

8 kHz

Bit rate

Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264

Protection features

Waterproof

Sensor type

CMOS

Wi-Fi

No

Compatible memory cards

MicroSD (TransFlash)

Maximum memory card size

512 GB

Audio system

2-way

Audio formats supported

G.711 A-law

Maximum operating distance

64 m

Maximum resolution

2688 x 1520 pixels

Built-in speaker(s)

Yes

Placement supported

Outdoor

Ethernet LAN (RJ-45) ports

1

Audio output channels

1.0 channels

DC-in jack

Yes

Housing material

Metal

Networking standards

IEEE 802.3at

Ethernet LAN

Yes

Supported graphics resolutions

2688 x 1520

International Protection (IP) code

IP67

Web-based management

Yes

Supported network protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP

Reset button

Yes

Password protection

Yes

Product colour

White

Tilt angle range

0 - 75°

Fixed focal length

2.8 mm

Web browser

Yes

Number of microphones

1

Video recording

Yes

LED type

IR/White

Night vision

Yes

Total megapixels

4 MP

Motion sensor

Yes

Optical sensor size

25.4 / 2.7 mm (1 / 2.7")

Minimum illumination

0 lx

Dynamic range

120 dB

Lens viewing angle, diagonal

133.5°

Video compression formats

H.265+

DC output voltage

12

Video motion detection

Yes

Number of cameras

1

Camera pan control

Yes

Camera tilt control

Yes

Detection distance

64 m

Day/night mode

Yes

Infrared (IR) cut-off filter

Yes

Remote viewing

Yes

Lens viewing angle, vertical

58.1°

Digital Wide Dynamic Range (DWDR)

Yes

Maximum aperture number

1.6

Lens viewing angle, horizontal

110°

Built-in siren

Yes

Alert notification type

Push notification

Wide Dynamic Range (WDR)

Yes

Progressive scan

Yes

Mirror

Yes

Back Light Compensation (BLC)

Yes

Weatherproof

Yes

IP address filtering

Yes

Intelligent Video Surveillance (IVS) system features

Crossing line

Camera shutter speed

1/3 to 1/10000

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Highlight Compensation (HLC)

Yes

Live view

Yes

Cloud-managed

Yes

Power consumption (Power over Ethernet (PoE))

12.52 W

HTTPS encryption

Yes

Image quality adjustment

Saturation

IK code

IK10

Digest authentication

Yes

Audio input channels

1.0 channels

Detect distance

64 m

Observe distance

27 m

Recognize distance

13 m

Identify distance

6 m

Human and vehicle targets classification

Yes

Bit rate range

0 - 64 Kbit/s
