Product Details
Data sheet
- Type
- IP security camera
- Width
- 102 mm
- Height
- 99 mm
- Depth
- 236 mm
- Connectivity technology
- Wired
- Power source type
- DC
- Storage relative humidity (H-H)
- 0 - 95%
- Operating temperature (T-T)
- -30 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage temperature (T-T)
- -40 - 60 °C
- Mounting type
- Wall
- Form factor
- Bullet
- Built-in microphone
- Yes
- Sample rate
- 8 kHz
- Bit rate
- 4 Mbps
- Noise reduction
- Yes
- Sensor type
- CMOS
- Signal-to-Noise Ratio (SNR)
- 52 dB
- Power consumption (max)
- 10.1 W
- Maximum resolution
- 2688 x 1520 pixels
- Built-in speaker(s)
- Yes
- Placement supported
- Outdoor
- Ethernet LAN (RJ-45) ports
- 1
- Housing material
- Plastic
- Ethernet LAN
- Yes
- Supported graphics resolutions
- 2688 x 1520
- International Protection (IP) code
- IP67
- Ethernet interface type
- Fast Ethernet
- Supported network protocols
- TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
- Password protection
- Yes
- Luminous flux
- 0.0005 lm
- Frame Rate
- 60 fps
- Product colour
- White
- Tilt angle range
- -90 - 90°
- Focal length range
- 4 mm
- Fixed focal length
- 4 mm
- LED type
- White
- Night vision
- Yes
- Total megapixels
- 4 MP
- Optical sensor size
- 25.4 / 1.8 mm (1 / 1.8")
- Minimum illumination
- 0.0005 lx
- Pan range
- -90 - 90°
- Dynamic range
- 120 dB
- Lens viewing angle, diagonal
- 114.7°
- Video compression formats
- H.265
- DC output voltage
- 12
- Number of cameras
- 1
- Night vision distance
- 30 m
- Number of lenses
- 1
- Privacy protection
- Yes
- Day/night mode
- Yes
- Lens viewing angle, vertical
- 50.6°
- Noise reduction technology
- 3D noise reduction
- Region of Interest (ROI) encoding
- Yes
- Maximum aperture number
- 1
- Lens viewing angle, horizontal
- 95.2°
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- IP address filtering
- Yes
- Camera shutter speed
- 1/10000 s
- Privacy masking
- Yes
- Number of illumination LEDs
- 4
- Digest authentication
- Yes
- Detect distance
- 70 m
- Observe distance
- 29 m
- Recognize distance
- 14 m
- Identify distance
- 7 m
- Minimum aperture number
- 1
- Bit rate range
- 64 - 64 Kbit/s
- Number of Privacy masking areas
- 4
