Product Details
Data sheet
- Type
- IP security camera
- Height
- 107 mm
- Connectivity technology
- Wired
- Weight
- 900 g
- Power source type
- PoE
- Storage relative humidity (H-H)
- 5 - 95%
- Manual
- Yes
- Operating temperature (T-T)
- -40 - 50 °C
- Operating relative humidity (H-H)
- 10 - 100%
- Storage temperature (T-T)
- -40 - 65 °C
- Mounting type
- Ceiling/wall
- Form factor
- Dome
- Bluetooth
- No
- Sensor type
- CMOS
- Wi-Fi
- No
- Internal memory
- 2048 MB
- Compatible memory cards
- MicroSD (TransFlash)
- Power consumption (max)
- 11.2 W
- Power consumption (typical)
- 5.5 W
- Maximum resolution
- 3840 x 2160 pixels
- Placement supported
- Outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Number of languages
- 12
- Housing material
- Polycarbonate (PC)
- Networking standards
- IEEE 802.1x
- Ethernet LAN
- Yes
- Zoom capability
- Yes
- Diameter
- 14.9 cm
- International Protection (IP) code
- IP66
- Flash memory
- 8192 MB
- Quality of Service (QoS) support
- Yes
- Password protection
- Yes
- Normal focusing range
- 0.5 m
- Languages support
- Spanish
- Frame Rate
- 30 fps
- Product colour
- White
- Tilt angle range
- -10 - 80°
- Focal length range
- 4.3–8.6
- Video recording
- Yes
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 8 MP
- Optical sensor size
- 25.4 / 1.8 mm (1 / 1.8")
- Minimum illumination
- 0.14 lx
- Pan range
- -190 - 190°
- Video compression formats
- H.264
- Angle of rotation
- 190°
- Video motion detection
- Yes
- Number of cameras
- 1
- Camera pan control
- Yes
- Camera tilt control
- Yes
- Night vision distance
- 40 m
- Number of lenses
- 1
- Day/night mode
- Yes
- Infrared (IR) cut-off filter
- Yes
- Built-in HDD
- No
- Smart IR
- Yes
- Number of sensors
- 1
- Infra-red wavelength
- 850 nm
- Alert notification type
- Audio detection
- Yes
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- Video streaming
- Yes
- Active tampering alarm
- Yes
- Terminal block port
- Yes
- IP address filtering
- Yes
- Camera shutter speed
- 1/8500 - 1/5 s
- Bit rate control
- Variable Bit Rate (VBR)
- Gain control type
- Auto
- Privacy masking
- Yes
- Flip & mirror
- Yes
- HTTPS encryption
- Yes
- Image quality adjustment
- Sharpness
- IK code
- IK10
- Drilling template included
- Yes
- PTZ modes
- Digital PTZ
- Text caption overlay
- Yes
Quick Compare
Product |
IP PTZ kam. 8MP SD5A825-HNR-YA
|
Axis 02100-001 security camera Dome IP security camera Indoor & outdoor 2880 x 2880 pixels Ceiling/wall
|
Axis M5526-E 50 Hz Dome IP security camera Indoor & outdoor 2688 x 1512 pixels Ceiling
|
|
Availability |
|
|
|
|
Price |
€1,182.93
|
€1,188.47
|
€1,191.64
|
€1,201.44
|
Description |
||||
Type |
IP security camera | IP security camera | ||
Width |
165 mm | |||
Height |
69 mm | 150 mm | ||
Depth |
165 mm | |||
Connectivity technology |
Wired | Wired | ||
Weight |
850 g | 1 kg | ||
Power source type |
PoE | PoE | ||
Storage relative humidity (H-H) |
5 - 95% | 5 - 95% | ||
Manual |
Yes | Yes | ||
Operating temperature (T-T) |
-40 - 50 °C | -20 - 50 °C | ||
Operating relative humidity (H-H) |
10 - 100% | 15 - 100% | ||
Storage temperature (T-T) |
-40 - 65 °C | -40 - 65 °C | ||
Mounting type |
Ceiling/wall | Ceiling | ||
Form factor |
Dome | Dome | ||
Built-in microphone |
Yes | |||
LED indicators |
Yes | |||
Bluetooth |
No | |||
Sample rate |
48 kHz | |||
Noise reduction |
Yes | |||
Microphone in |
Yes | |||
Protection features |
Water resistant | |||
Sensor type |
CMOS | CMOS | ||
Wi-Fi |
No | |||
Internal memory |
2000 MB | |||
Compatible memory cards |
microSDHC | MicroSD (TransFlash) | ||
Audio system |
2-way | |||
Audio formats supported |
G.711 | LPCM | ||
Signal-to-Noise Ratio (SNR) |
55 dB | |||
Power consumption |
3.8 mA | |||
Power consumption (max) |
15.5 W | 11.7 W | ||
Power consumption (typical) |
7.9 W | 4.2 W | ||
Maximum resolution |
2880 x 2880 pixels | 2688 x 1512 pixels | ||
Placement supported |
Indoor & outdoor | Indoor & outdoor | ||
Card reader integrated |
Yes | |||
Ethernet LAN (RJ-45) ports |
1 | 1 | ||
Number of languages |
12 | |||
DC-in jack |
Yes | |||
Housing material |
Aluminium | Plastic | ||
Networking standards |
IEEE 802.3at | IEEE 802.3at | ||
Security algorithms |
HTTPS | HTTPS | ||
Ethernet LAN |
Yes | Yes | ||
Supported graphics resolutions |
320 x 180 | |||
Zoom capability |
Yes | Yes | ||
Diameter |
14.9 cm | |||
International Protection (IP) code |
IP66 | IP66 | ||
Flash memory |
1000 MB | 8192 MB | ||
Digital zoom |
12x | |||
Auto focus |
No | Yes | ||
Ethernet interface type |
Fast Ethernet | |||
Video formats supported |
H.265 | |||
Optical Zoom |
10x | |||
Quality of Service (QoS) support |
Yes | Yes | ||
Languages support |
Korean | |||
Frame Rate |
30 fps | 60 fps | ||
Mounting kit |
Yes | |||
Product colour |
White | Black | ||
Tilt angle range |
0 - 90° | |||
Harmonized System (HS) code |
85258900 | |||
Doesn't contain |
PVC/BFR | |||
Focal length range |
1.3 mm | 4.7 - 47 mm | ||
Video recording |
Yes | |||
LED type |
IR | |||
Night vision |
Yes | |||
Total megapixels |
12 MP | 4 MP | ||
PTZ control |
Yes | |||
Fixed focus |
Yes | |||
Optical sensor size |
25.4 / 1.7 mm (1 / 1.7") | 25.4 / 3 mm (1 / 3") | ||
Field of view (FOV) angle |
183° | |||
Minimum illumination |
0.04 lx | 0.01 lx | ||
Pan range |
0 - 360° | |||
Video motion detection |
Yes | |||
Number of cameras |
1 | 1 | ||
Camera pan control |
Yes | Yes | ||
Camera tilt control |
Yes | Yes | ||
Number of lenses |
1 | 1 | ||
Day/night mode |
Yes | Yes | ||
Preset points |
Yes | |||
Infrared (IR) cut-off filter |
Yes | Yes | ||
Audio system full duplex |
Yes | |||
Built-in HDD |
No | |||
Lens viewing angle, vertical |
35 - 3.67° | |||
Noise reduction technology |
2D noise reduction, 3D noise reduction | |||
Maximum aperture number |
3 | |||
Lens viewing angle, horizontal |
183° | 59.1 - 6.5° | ||
Number of sensors |
1 | 1 | ||
Alert notification type |
E-mail, Text alert message | |||
Audio detection |
Yes | Yes | ||
Wide Dynamic Range (WDR) |
Yes | Yes | ||
Progressive scan |
Yes | |||
Video streaming |
Yes | Yes | ||
Active tampering alarm |
Yes | Yes | ||
Alarm input/output |
Yes | |||
Terminal block port |
Yes | |||
IP address filtering |
Yes | |||
Intelligent Video Surveillance (IVS) system features |
Line crossing detection | |||
ROM capacity |
1024 MB | |||
Camera shutter speed |
1/22000 - 1 s | 1/27000 - 0.2 s | ||
Gain control type |
Auto | |||
Privacy masking |
Yes | Yes | ||
Power consumption (Power over Ethernet (PoE)) |
12.95 W | |||
HTTPS encryption |
Yes | |||
Image quality adjustment |
Contrast | Contrast | ||
IK code |
IK10 | IK09 | ||
Mounting brackets included |
Yes | |||
Digest authentication |
Yes | |||
Streaming method |
Multicast | |||
Identify distance (wide) |
10 m | |||
Recognize distance (wide) |
19 m | |||
Pan speed |
150 °/sec | |||
Observe distance (wide) |
38 m | |||
Detect distance (wide) |
96 m | |||
Identify distance (tele) |
93 m | |||
Pixel counter |
Yes | Yes | ||
Human and vehicle targets classification |
Yes | |||
Drilling template included |
Yes | |||
Tilt speed |
150 °/sec | |||
Minimum aperture number |
1.6 | |||
Recognize distance (tele) |
186 m | |||
Detect distance (tele) |
938 m | |||
Observe distance (tele) |
373 m | |||
PTZ modes |
Digital PTZ | |||
Text caption overlay |
Yes | |||
Compliance certificates |
REACH | |||
Camera pixel size |
1.998 µm | |||
License plate recognition |
Yes | |||
