Prekė detaliau
Charakteristikos
- Width
- 240 mm
- Height
- 90 mm
- Depth
- 162 mm
- Weight
- 4.32 kg
- Package height
- 176 mm
- Package width
- 330 mm
- Storage relative humidity (H-H)
- 0 - 95%
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage temperature (T-T)
- -15 - 45 °C
- Form factor
- Tower
- LED indicators
- Power
- Battery technology
- Sealed Lead Acid (VRLA)
- Output power
- 420 W
- Input frequency
- 50/60 Hz
- Display type
- LCD
- Input operation voltage (min)
- 170 V
- AC outlets quantity
- 1 AC outlet(s)
- Output power capacity
- 0.6 kVA
- Output operation voltage (max)
- 230 V
- Waveform
- Sine
- Input operation voltage (max)
- 270 V
- Output operation voltage (min)
- 220 V
- Surge protection
- Yes
- Operating altitude
- 0 - 3000 m
- Power plug
- C14 coupler
- Non-operating altitude
- 0 - 15000 m
- Product colour
- Yellow
- Sustainability certificates
- RoHS
- Number of input phases
- 1
- Number of output phases
- 1
Greitas palyginimas
Prekė |
Ever ECO PRO 700 Line-Interactive 0.7 kVA 420 W 2 AC outlet(s) | PowerWalker VI 2200 LCD/FR 2.2 kVA 1200 W 4 AC outlet(s) | PowerWalker VI 500 R1U Line-Interactive 0.5 kVA 300 W 4 AC outlet(s) | Eaton UPS 5E Gen2 1600UI IEC 1600 VA, 900 W, Tower, Line-Interactive |
Prieinamumas |
|
|
|
|
Kaina |
164,79 €
|
165,29 €
|
165,47 €
|
167,40 €
|
Aprašymas |
Eaton UPS 5E Gen2 1600UI IEC 1600 VA, 900 W, Tower, Line-Interactive | |||
Colour of product |
Black | |||
Warranty |
24 month(s) | |||
Producer product name |
5E Gen2 1600UI IEC | |||
Net weight |
9.30 kg | |||
Gross weight |
9.84 kg | |||
WEEE tax |
Yes | |||
Packing quantity |
1.00 pc(s) | |||
Volume (m3) |
0.01 m | |||
Tare weight (kg) |
0.54 kg | |||
Gross depth (mm) |
347.00 mm | |||
Gross width (mm) |
230.00 mm | |||
Gross height (mm) |
138.00 mm | |||
WEE classification |
CL109:5:2017-04-01 | |||
Paper/Pasteboard |
500.00 g | |||
Embeeded battery |
Yes | |||
TI weight (kg) |
5.30 kg | |||
Width |
90 mm | 139 mm | 433 mm | |
Height |
150 mm | 195 mm | 44 mm | |
Depth |
350 mm | 365 mm | 216 mm | |
Plastic (No PET) |
40.00 g | |||
Composition of battery |
CL127:KT:2016-12-09 | |||
Classification of battery |
CL126:NE:2016-12-09 | |||
Type of battery |
Accumulator | |||
Weight |
6.55 kg | 10.4 kg | 7.6 kg | |
Producer product family |
UPS | |||
Package height |
185 mm | 292 mm | 150 mm | |
Package width |
130 mm | 230 mm | 537 mm | |
Number of batteries supported |
2 | 2 | ||
Cables included |
USB cable | |||
Storage relative humidity (H-H) |
20 - 95% | |||
Manual |
Yes | |||
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | 0 - 40 °C | |
Operating relative humidity (H-H) |
20 - 80% | 0 - 90% | 0 - 95% | |
Storage temperature (T-T) |
0 - 40 °C | |||
Form factor |
Tower | Tower | Rackmount | Tower |
USB port |
Yes | Yes | ||
LED indicators |
Yes | |||
Battery technology |
Sealed Lead Acid (VRLA) | |||
Battery capacity |
7 Ah | 9 Ah | 7 Ah | |
Capacity |
900 W | |||
Palette Qty |
102 pc(s) | |||
Battery recharge time |
6 h | 8 h | ||
Output power |
420 W | 1200 W | 300 W | |
Input frequency |
50 Hz | 50 Hz | 45/55 Hz | |
USB 2.0 ports quantity |
1 | 1 | ||
Display type |
LCD | |||
Ethernet LAN (RJ-45) ports |
1 | |||
Input operation voltage (min) |
168 V | 170 V | 165 V | |
Power protection features |
Overload | Overcharge | Overload | |
Cold start |
Yes | |||
AC outlets quantity |
2 AC outlet(s) | 4 AC outlet(s) | 4 AC outlet(s) | |
Output power capacity |
0.7 kVA | 2.2 kVA | 0.5 kVA | |
Output operation voltage (max) |
264 V | 230 V | 230 V | |
Waveform |
Sine | Sine | Sine | |
AC outlet types |
Type E | C13 coupler | ||
Input operation voltage (max) |
264 V | 180 V | 290 V | |
Audible alarm(s) |
Yes | |||
Battery voltage |
12 V | 12 V | 6 V | |
Output operation voltage (min) |
184 V | 230 V | 230 V | |
UPS topology |
Line-Interactive | Line-Interactive | Line-Interactive | Line-Interactive |
Modem (RJ-11) ports |
1 | |||
Typical backup time at full load |
0.8 min | |||
Automatic Voltage Regulation (AVR) |
Yes | |||
Typical backup time at half load |
10.3 min | |||
Surge protection |
Yes | |||
Output frequency regulation |
0.5 Hz | |||
Output voltage regulation |
10% | |||
RS-232 ports |
1 | |||
International Protection (IP) code |
IP20 | |||
Output frequency |
50 Hz | |||
Product colour |
White | Black | Black | |
Harmonized System (HS) code |
85078000 | 85078000 | ||
USB port type |
USB Type-B | |||
Surge protection features |
Network | |||
Rack capacity |
1U | |||
EMI/RFI noise filtering |
Yes | |||
Output power factor |
0.6 | |||
Emergency Power Off (EPO) connector |
Yes | |||
Number of input phases |
1 | |||
Number of output phases |
1 | |||
