Prekė detaliau
Charakteristikos
- Width
- 100 mm
- Height
- 143 mm
- Depth
- 279 mm
- Weight
- 5 kg
- Package depth
- 330 mm
- Package height
- 223 mm
- Package width
- 140 mm
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 0 - 90%
- Form factor
- Mini tower
- LED indicators
- Yes
- Battery capacity
- 9 Ah
- Output power
- 480 W
- USB 2.0 ports quantity
- 1
- Input operation voltage (min)
- 170 V
- Power protection features
- Overcharge
- Cold start
- Yes
- AC outlets quantity
- 2 AC outlet(s)
- Output power capacity
- 0.85 kVA
- Output operation voltage (max)
- 240 V
- AC outlet types
- Type F
- Input operation voltage (max)
- 280 V
- Audible alarm(s)
- Yes
- Battery voltage
- 12 V
- Output operation voltage (min)
- 220 V
- UPS topology
- Line-Interactive
- Modem (RJ-11) ports
- 2
- Surge protection
- Yes
- Product colour
- Black
- Harmonized System (HS) code
- 85078000
- Surge protection features
- Telephone
- Number of type F outputs
- 2
Greitas palyginimas
Prekė |
Qoltec Monolith uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 600 W 2 AC outlet(s)
|
UPS|TECNOWARE|840 Watts|1200 VA|Wave form type Modified sinewave|LineInteractive|Phase 1 phase|FGCERAPL1202SCH
|
Rebel Nanopower Plus 850 UPS | Off-line | Sinusoida| 850VA | 480W | LCD | USB
|
UPS ERA PLUS DC POE 24VDC/FGCERAPLDC252 TECNOWARE
|
Prieinamumas |
|
|
|
|
Kaina |
60,10 €
|
61,08 €
|
61,15 €
|
61,56 €
|
Aprašymas |
840 Watts | 1200 VA | Typical runtime at full load 2 min | Typical runtime at half load 10 min | Wave form type Modified sinewave | Topology LineInteractive | Phase 1phase | Input ports Hard Wire 3 wire (1PH+N+G) | Output power connector type Hard Wire 3-wire (1PH + N + G) | Colour Black | Included Accessories AC Input cable - DC output cable with 5,5x2,5 mm 2 connectors - 8 connectors | ||
Package type |
Box | |||
Colour |
Black | |||
Width |
100 mm | 142 mm | ||
Height |
144 mm | 101 mm | ||
Depth |
286 mm | 297 mm | ||
Weight |
4.8 kg | 4.9 kg | ||
Package depth |
323 mm | |||
Package height |
222 mm | |||
Package width |
142 mm | |||
Package weight |
5.1 kg | |||
Number of batteries supported |
1 | |||
Operating temperature (T-T) |
0 - 40 °C | |||
Form factor |
Compact | |||
USB port |
Yes | |||
LED indicators |
Yes | |||
Battery technology |
Gel battery (VRLA) | |||
Battery capacity |
9 Ah | 9 Ah | ||
Control type |
Buttons | |||
Battery recharge time |
6 h | |||
Cooling type |
Passive | |||
Output power |
600 W | 480 W | ||
Input frequency |
50/60 Hz | 50/60 Hz | ||
USB 2.0 ports quantity |
1 | |||
Display type |
LCD | |||
Ethernet LAN (RJ-45) ports |
2 | |||
Garantija |
24/12L | 24 | ||
Category Code |
UPW | UPW | ||
Unit Box Height |
0.22 | 0.055 | ||
Unit Box Length |
0.34 | 0.205 | ||
Unit Box Width |
0.185 | 0.17 | ||
Vendor Homepage |
www.tecnoware.com/en-US/Dettaglio/Articolo/55 | www.tecnoware.com/en-US/Dettaglio/Articolo/644 | ||
Included Accessories |
AC Input cable - DC output cable with 5,5x2,5 mm 2 connectors - 8 connectors | |||
Dimensions |
10.1x14.2x27.9 cm | 16x2,8x10,5cm | ||
Input operation voltage (min) |
140 V | 140 V | ||
Power protection features |
Short circuit | |||
AC outlets quantity |
2 AC outlet(s) | |||
Output power capacity |
1 kVA | 850 kVA | ||
Output operation voltage (max) |
230 V | 220 V | ||
Waveform |
Pure sine | |||
AC outlet types |
Type F | |||
Input operation voltage (max) |
300 V | 300 V | ||
Audible alarm(s) |
Yes | |||
Battery voltage |
12 V | 12 V | ||
Output operation voltage (min) |
220 V | 230 V | ||
UPS topology |
Double-conversion (Online) | |||
Output frequency regulation |
0.05 Hz | |||
Output voltage regulation |
5% | |||
Serial interface type |
RJ-45 | |||
MODEL |
FGCERAPLDC252 | |||
Short circuit protection |
Yes | |||
Output frequency |
50/60 Hz | |||
Noise Level |
40 dB | |||
Product colour |
Black | Black | ||
Serial interface |
Yes | |||
USB port type |
USB Type-B | |||
Audible alarm modes |
Fault | |||
Overload protection |
Yes | |||
Overcharge protection |
Y | |||
Built-in fan |
Yes | |||
Units per Shipping Box |
1 | 1 | ||
Product Net Weight |
4.5 kg | 0.5 kg | ||
Unit Calculated Weight |
4.75 kg | 0.61 kg | ||
Unit Calculated Volume |
0.01384 cubm | 0.001917 cubm | ||
Output power capacity, W |
840 Watts | |||
Output power capacity, VA |
1200 VA | |||
Typical runtime at full load |
2 min | |||
Typical runtime at half load |
10 min | |||
Wave form type |
Modified sinewave | |||
Topology |
LineInteractive | |||
Phase |
1phase | |||
Input ports |
Hard Wire 3 wire (1PH+N+G) | |||
Output power connector type |
Hard Wire 3-wire (1PH + N + G) | |||
Communication ports (RJ45) |
2 | |||
Communication ports (USB) |
1 | |||
Buttons: (On/Off) |
YES | |||
