Prekė detaliau
Charakteristikos
- Width
- 100 mm
- Height
- 143 mm
- Depth
- 290 mm
- Weight
- 4.4 kg
- Package depth
- 330 mm
- Package height
- 223 mm
- Package width
- 140 mm
- Number of batteries supported
- 1
- Cables included
- USB cable
- Manual
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 0 - 90%
- Form factor
- Mini tower
- USB port
- Yes
- LED indicators
- Yes
- Battery capacity
- 7 Ah
- Output power
- 360 W
- Input frequency
- 50/60 Hz
- USB 2.0 ports quantity
- 1
- Efficiency
- 95%
- Input operation voltage (min)
- 170 V
- AC outlets quantity
- 2 AC outlet(s)
- Output power capacity
- 0.65 kVA
- Output operation voltage (max)
- 230 V
- AC outlet types
- Type E
- Input operation voltage (max)
- 280 V
- Battery voltage
- 12 V
- UPS topology
- Line-Interactive
- Typical backup time at full load
- 0.1 min
- Automatic Voltage Regulation (AVR)
- Yes
- Typical backup time at half load
- 6 min
- Output voltage regulation
- 10%
- Product colour
- Black
- Harmonized System (HS) code
- 85078000
- Products per pallet
- 128 pc(s)
- Software CD
- Yes
- Products per master (outer) case
- 4 pc(s)
- Master (outer) case height
- 250 mm
- Master (outer) case length
- 598 mm
- Master (outer) case width
- 380 mm
- Output power factor
- 0.55
- Battery recharge time (90%)
- 4 h
Greitas palyginimas
Prekė |
Išpardavimas!
EnerGenie | UPS UPS-PC-652A with AVR | 650 VA | 220 V | 220 V
|
Qoltec 53773 uninterruptible power supply (UPS) Line-Interactive 0.85 kVA 480 W 1 AC outlet(s)
|
Armac O/650E/LCD uninterruptible power supply (UPS) Line-Interactive 0.65 kVA 390 W 2 AC outlet(s)
|
CyberPower UT650EG-FR uninterruptible power supply (UPS) Line-Interactive 0.65 kVA 360 W 3 AC outlet(s)
|
Prieinamumas |
|
|
|
|
Kaina |
55,58 €
43,77 €
|
53,51 €
|
53,60 €
|
54,12 €
|
Aprašymas |
EnerGenie | UPS UPS-PC-652A with AVR | 650 VA | 220 V | 220 V | |||
Colour of product |
Black | |||
Warranty |
24 month(s) | |||
Producer product name |
UPS UPS-PC-652A with AVR | |||
Net weight |
4.4 kg | |||
Gross weight |
5.4 kg | |||
WEEE tax |
Yes | |||
Packing quantity |
3.00 pc(s) | |||
Gross depth master carton |
450 mm | |||
Gross width master carton |
390 mm | |||
Gross height master carton |
240 mm | |||
Net weight master carton |
16.2 kg | |||
Tare weight master carton |
0.716 kg | |||
Volume (m3) |
0.01250625 m | |||
Tare weight (kg) |
1.00 kg | |||
Gross depth (mm) |
375 mm | |||
Gross width (mm) |
145 mm | |||
Gross height (mm) |
230 mm | |||
WEE classification |
CL109:5:2017-04-01 | |||
Embeeded battery |
Yes | |||
TI weight (kg) |
3.64 kg | |||
Cable length |
1.2 m | |||
Width |
16 cm | 92 mm | 85 mm | 84 mm |
Height |
9.5 cm | 140 mm | 141 mm | 174 mm |
Depth |
32 cm | 275 mm | 305 mm | 280 mm |
Plastic (No PET) |
1000.00 g | |||
Composition of battery |
CL127:KT:2016-12-09 | |||
Classification of battery |
CL126:PE:2016-12-09 | |||
Type of battery |
Accumulator | |||
Weight |
5.8 g | 4.8 kg | 4.6 kg | 3.8 kg |
Product type |
UPS | |||
Package depth |
37.5 cm | |||
Package height |
23 cm | 221 mm | ||
Package width |
14.5 cm | 325 mm | ||
Number of batteries supported |
1 | |||
Power source type |
AC | |||
Storage relative humidity (H-H) |
0 - 90% | 0 - 90% | ||
Manual |
Yes | Yes | ||
Operating temperature (T-T) |
0 - 40 C | 0 - 40 °C | 0 - 45 °C | 0 - 40 °C |
Operating relative humidity (H-H) |
0 - 90 % | 10 - 90% | 0 - 90% | |
Storage temperature (T-T) |
-15 - 45 °C | -20 - 50 °C | ||
Form factor |
Tower | Tower | ||
USB port |
Yes | |||
RoHS compliance |
Yes | |||
LED indicators |
Power | Yes | ||
Battery technology |
Sealed Lead Acid (VR | Sealed Lead Acid (VRLA) | ||
Battery capacity |
7 Ah | 7 Ah | 9 Ah | |
Capacity |
650 VA | |||
Palette Qty |
123 pc(s) | |||
Battery recharge time |
12 h | 6 h | 6 h | 6 h |
Output power |
390 W | 480 W | 390 W | 360 W |
Input frequency |
50/60 Hz | 50/60 Hz | ||
USB 2.0 ports quantity |
1 | |||
Response time |
10 ms | 4 ms | ||
Display type |
LCD | |||
Ethernet LAN (RJ-45) ports |
1 | |||
Power supply input frequency |
50/60 Hz | |||
Input operation voltage (min) |
220 V | 140 V | 145 V | 165 V |
Power protection features |
Short circuit | Short circuit | Overload | |
Cold start |
Yes | |||
AC outlets quantity |
3 | 1 AC outlet(s) | 2 AC outlet(s) | 3 AC outlet(s) |
Output power capacity |
650 VA | 0.85 kVA | 0.65 kVA | 0.65 kVA |
Output operation voltage (max) |
220 V | 230 V | 255 V | 230 V |
Waveform |
Sine | Sine | Sine | |
AC outlet types |
C13 coupler, C14 cou | Type E | Type E | Type E |
Input operation voltage (max) |
220 V | 300 V | 290 V | 290 V |
Audible alarm(s) |
Yes | |||
Battery voltage |
12 V | 12 V | 12 V | |
Output operation voltage (min) |
220 V | 220 V | 195 V | |
UPS topology |
Line-Interactive | Line-Interactive | Line-Interactive | Line-Interactive |
Modem (RJ-11) ports |
1 | |||
Typical backup time at full load |
20 min | 14 min | 3 min | |
Automatic Voltage Regulation (AVR) |
Yes | Yes | Yes | |
Housing material |
Plastic | |||
Operating altitude |
0 - 3000 m | |||
Output frequency |
50/60 Hz | 50 Hz | ||
Noise Level |
40 dB | 45 dB | ||
Non-operating altitude |
0 - 3000 m | |||
Product colour |
Black | Black | Black | |
Battery weight |
4.7 kg | |||
Overvoltage protection |
Y | |||
Producer |
EnerGenie | |||
Compliance certificates |
RoHS | |||
Audible alarm modes |
Alarm when on battery, Fault, Low battery alarm, Overload alarm | |||
Power factor |
0.6 | |||
EMI/RFI noise filtering |
Yes | |||
Warnings |
Use the appliance in well-ventilated areas to avoid overheating. | |||
