Prekė detaliau
Charakteristikos
- Width
- 433 mm
- Height
- 86 mm
- Depth
- 274 mm
- Weight
- 20.5 kg
- Number of batteries supported
- 1
- Power source type
- AC
- Battery type
- RBP0166
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Form factor
- Rackmount
- USB port
- Yes
- LED indicators
- Yes
- Battery technology
- Sealed Lead Acid (VRLA)
- Control type
- Buttons
- Cooling type
- Active
- Output power
- 1000 W
- Input frequency
- 50/60 Hz
- USB 2.0 ports quantity
- 1
- Display type
- LCD
- Ethernet LAN (RJ-45) ports
- 2
- Input operation voltage (min)
- 169 V
- Power protection features
- Over voltage
- AC outlets quantity
- 8 AC outlet(s)
- Output power capacity
- 1.6 kVA
- Waveform
- Pure sine
- AC outlet types
- C13 coupler
- Input operation voltage (max)
- 271 V
- UPS topology
- Line-Interactive
- Typical backup time at full load
- 2.5 min
- Automatic Voltage Regulation (AVR)
- Yes
- Housing material
- Metal
- Typical backup time at half load
- 10.4 min
- Surge protection
- Yes
- Output frequency regulation
- 1 Hz
- RS-232 ports
- 1
- Serial interface type
- RS-232
- Output frequency
- 50/60 Hz
- Serial ports quantity
- 1
- Power plug
- C14 coupler
- Product colour
- Black
- Heat dissipation
- 20.5 BTU/h
- Serial interface
- Yes
- ECO mode
- Yes
- USB port type
- USB Type-B
- Hot-swap battery
- Yes
- Power Factor Correction (PFC) type
- Active
- Compliance certificates
- RoHS
- Power factor
- 0.625
- Rack capacity
- 2U
- EMI/RFI noise filtering
- Yes
- Built-in fan
- Yes
- Detachable power cord
- Yes
Greitas palyginimas
Prekė |
UPS Online Rack 19" LCD 2000VA/2000W, Digitus
|
PowerWalker VFI 1500 ICR IoT Double-conversion (Online) 1.5 kVA 1500 W 8 AC outlet(s)
|
Schneider Electric APC Smart-UPS | SMT750IC | 750 VA | 500 W
|
APC Back-UPS Pro BGM2200B-GR - 2200VA/1320W, 4x Schuko & 2x C13 outlets, 3x USB charger, USB dataport
|
Prieinamumas |
|
|
|
|
Kaina |
475,60 €
|
487,15 €
|
489,03 €
|
489,04 €
|
Aprašymas |
Schneider Electric APC Smart-UPS | SMT750IC | 750 VA | 500 W | |||
Warranty |
24 month(s) | |||
Producer product name |
SMT750IC | |||
Net weight |
11.80 kg | |||
Gross weight |
14.20 kg | |||
WEEE tax |
Yes | |||
Packing quantity |
1.00 pc(s) | |||
Volume (m3) |
0.04 m | |||
Tare weight (kg) |
2.40 kg | |||
Gross depth (mm) |
499.10 mm | |||
Gross width (mm) |
301.00 mm | |||
Gross height (mm) |
278.10 mm | |||
WEE classification |
CL109:5:2017-04-01 | |||
Paper/Pasteboard |
1920.00 g | |||
Embeeded battery |
Yes | |||
TI weight (kg) |
5.00 kg | |||
Cable length |
1.52 m | |||
Width |
440 mm | 438 mm | 104.1 mm | |
Height |
86.5 mm | 85.5 mm | 292.1 mm | |
Depth |
460 mm | 445 mm | 408.9 mm | |
Plastic (No PET) |
480.00 g | |||
Composition of battery |
CL127:KT:2016-12-09 | |||
Classification of battery |
CL126:NE:2016-12-09 | |||
Type of battery |
Accumulator | |||
Weight |
19.5 kg | 15.8 kg | 12.3 kg | |
Special features |
Automatic voltage regulation helps to adjust the electrical voltage Cloud-based remote power monitoring via SmartConnect Ethernet port Ideal for servers, storage, network cabinets, business VoIP and desktops, retail POS | |||
Producer product family |
APC Smart-UPS | |||
Package depth |
587 mm | |||
Package height |
200 mm | 240 mm | 155 mm | |
Package width |
555 mm | 498 mm | 355 mm | |
Package weight |
19 kg | |||
Number of batteries supported |
4 | 3 | 1 | |
Power source type |
AC | |||
Cables included |
RS-232, USB cable | Input power cable, Output power cable, USB cable | USB cable | |
Storage relative humidity (H-H) |
20 - 90% | 0 - 95% | ||
Manual |
Yes | Yes | Yes | |
Operating temperature (T-T) |
0 - 40 °C | 0 - 45 °C | 0 - 40 °C | |
Operating relative humidity (H-H) |
20 - 90% | 0 - 95% | 0 - 95% | |
Storage temperature (T-T) |
-25 - 55 °C | -15 - 40 °C | ||
Form factor |
Rackmount | Rackmount/Tower | Tower | |
USB port |
Yes | Yes | Yes | |
LED indicators |
Yes | |||
Battery technology |
Sealed Lead Acid (VRLA) | |||
Battery life (max) |
5 year(s) | |||
Battery capacity |
9 Ah | 9 Ah | ||
Capacity |
750 VA | |||
Palette Qty |
41 pc(s) | |||
Battery recharge time |
3 h | 16 h | ||
Cooling type |
Active | |||
Output power |
2000 W | 1500 W | 1320 W | |
Input frequency |
40/70 Hz | 50/60 Hz | ||
USB 2.0 ports quantity |
1 | |||
Response time |
0 ms | 8 ms | ||
Display type |
LCD | LCD | LCD | |
Ethernet LAN (RJ-45) ports |
2 | |||
Efficiency |
93% | 89% | ||
Input operation voltage (min) |
208 V | 110 V | 168 V | |
Cold start |
Yes | |||
AC outlets quantity |
8 AC outlet(s) | 8 AC outlet(s) | 6 AC outlet(s) | |
Output power capacity |
1.5 kVA | 1.5 kVA | 2.2 kVA | |
Output operation voltage (max) |
240 V | 230 V | ||
Waveform |
Sine | Sine | ||
AC outlet types |
C13 coupler | C13 coupler | Type F | |
Input operation voltage (max) |
240 V | 300 V | 302 V | |
Audible alarm(s) |
Yes | |||
Battery voltage |
12 V | 12 V | 24 V | |
Output operation voltage (min) |
200 V | |||
UPS topology |
Double-conversion (Online) | Double-conversion (Online) | Line-Interactive | Line-Interactive |
Cabling technology |
10/100/1000Base-T(X) | |||
Automatic Voltage Regulation (AVR) |
Yes | |||
Automatic battery test |
Yes | |||
Surge protection |
Yes | |||
Output voltage regulation |
1% | |||
Operating altitude |
0 - 1500 m | 0 - 3048 m | ||
International Protection (IP) code |
IP20 | |||
Serial interface type |
RS-232 | RS-232 | RJ-45 | |
Output frequency |
60 Hz | |||
Noise Level |
45 dB | 45 dB | ||
Serial ports quantity |
1 | 1 | ||
Maximum current |
10 A | 12 A | ||
Surge energy rating |
1080 J | |||
Power plug |
C20 coupler | C14 coupler | Type F | |
Non-operating altitude |
0 - 3048 m | |||
Product colour |
Black | Black | ||
Harmonized System (HS) code |
85078000 | |||
Sustainability certificates |
Green Premium | |||
Serial interface |
Yes | |||
ECO mode |
Yes | |||
Package volume |
66705.5 cm³ | |||
USB port type |
USB Type-B | |||
Charging current |
1.5 A | |||
Output voltage Total Harmonic Distortion (THD) |
1% | |||
Hot-swap battery |
Yes | |||
UK Trade Tariff code |
85044085 | |||
Producer |
Schneider Electric | |||
Size (imperial) |
48.3 cm (19") | |||
Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm | |||
Power factor |
1 | |||
Surge protection features |
Network | |||
SmartSlot |
No | |||
Crest factor |
3:1 | |||
Emergency Power Off (EPO) |
Yes | |||
Rack capacity |
0U | |||
Rack mount kit |
Yes | |||
EMI/RFI noise filtering |
Yes | |||
Output power factor |
1 | |||
Emergency Power Off (EPO) connector |
Yes | Yes | ||
Built-in fan |
Yes | |||
Battery recharge time (90%) |
4 h | |||
Efficiency (ECO mode) |
98% | |||
Input current Total Harmonic Distortion (THD) |
5% | |||
Management card included |
No | |||
Detachable power cord |
Yes | |||
Warnings |
Use the appliance in well-ventilated areas to avoid overheating. | Keep away from sources of fire and water. | ||
SmartConnect port |
No | |||
