Prekė detaliau
Charakteristikos
- Width
- 196 mm
- Height
- 342 mm
- Depth
- 416 mm
- Weight
- 25.4 kg
- Package depth
- 512 mm
- Package height
- 458 mm
- Package width
- 294 mm
- Package weight
- 27.1 kg
- Number of batteries supported
- 6
- Cables included
- RS-232, USB cable
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 20 - 90%
- Form factor
- Tower
- USB port
- Yes
- Battery capacity
- 9 Ah
- Battery recharge time
- 4 h
- Output power
- 2700 W
- Input frequency
- 40 - 70 Hz
- USB 2.0 ports quantity
- 1
- Response time
- 0 ms
- Display type
- LCD
- Efficiency
- 91%
- Input operation voltage (min)
- 80 V
- AC outlets quantity
- 4 AC outlet(s)
- Output power capacity
- 3 kVA
- Output operation voltage (max)
- 240 V
- Waveform
- Pure sine
- AC outlet types
- Type E
- Input operation voltage (max)
- 300 V
- Battery voltage
- 12 V
- Output operation voltage (min)
- 208 V
- UPS topology
- Double-conversion (Online)
- Typical backup time at full load
- 3.5 min
- Typical backup time at half load
- 11 min
- Output frequency regulation
- ±0.5 Hz
- Output voltage regulation
- ±1%
- RS-232 ports
- 1
- Power plug
- C20 coupler
- Product colour
- Black
- Harmonized System (HS) code
- 85078000
- USB port type
- USB Type-B
- Output voltage Total Harmonic Distortion (THD)
- 5%
- Crest factor
- 3:1
- Output power factor
- 0.9
- Input power factor
- 0.99
- Built-in fan
- Yes
- Warnings
- Use the appliance in well-ventilated areas to avoid overheating.
