Prekė detaliau
Charakteristikos
- Width
- 196 mm
- Height
- 342 mm
- Depth
- 416 mm
- Weight
- 25.4 kg
- Package depth
- 512 mm
- Package height
- 458 mm
- Package width
- 294 mm
- Package weight
- 27.1 kg
- Number of batteries supported
- 6
- Cables included
- RS-232, USB cable
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 20 - 90%
- Form factor
- Tower
- USB port
- Yes
- Battery capacity
- 9 Ah
- Battery recharge time
- 4 h
- Output power
- 2700 W
- Input frequency
- 40 - 70 Hz
- USB 2.0 ports quantity
- 1
- Response time
- 0 ms
- Display type
- LCD
- Efficiency
- 91%
- Input operation voltage (min)
- 80 V
- AC outlets quantity
- 4 AC outlet(s)
- Output power capacity
- 3 kVA
- Output operation voltage (max)
- 240 V
- Waveform
- Pure sine
- AC outlet types
- Type E
- Input operation voltage (max)
- 300 V
- Battery voltage
- 12 V
- Output operation voltage (min)
- 208 V
- UPS topology
- Double-conversion (Online)
- Typical backup time at full load
- 3.5 min
- Typical backup time at half load
- 11 min
- Output frequency regulation
- ±0.5 Hz
- Output voltage regulation
- ±1%
- RS-232 ports
- 1
- Power plug
- C20 coupler
- Product colour
- Black
- Harmonized System (HS) code
- 85078000
- USB port type
- USB Type-B
- Output voltage Total Harmonic Distortion (THD)
- 5%
- Crest factor
- 3:1
- Output power factor
- 0.9
- Input power factor
- 0.99
- Built-in fan
- Yes
- Warnings
- Keep away from sources of fire and water.
Greitas palyginimas
Prekė |
UPS Online Rack 19" LCD 2000VA/2000W, Digitus
|
PowerWalker VFI 1000 RMG PF1 uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 1000 W
|
PowerWalker 3000 CW uninterruptible power supply (UPS) Line-Interactive 30 kVA 2100 W
|
CyberPower PR1000ELCD uninterruptible power supply (UPS) Line-Interactive 1 kVA 900 W 8 AC outlet(s)
|
Prieinamumas |
|
|
|
|
Kaina |
460,22 €
|
466,77 €
|
467,41 €
|
470,61 €
|
Aprašymas |
||||
Package type |
Box | |||
Width |
440 mm | 438 mm | 145 mm | 170 mm |
Height |
86.5 mm | 88 mm | 220 mm | 221 mm |
Depth |
460 mm | 410 mm | 455 mm | 432 mm |
Weight |
19.5 kg | 14.1 kg | 2.3 kg | 18.9 kg |
Package depth |
560 mm | 540 mm | ||
Package height |
200 mm | 180 mm | 325 mm | 360 mm |
Package width |
555 mm | 500 mm | 235 mm | 316 mm |
Package weight |
17.6 kg | 22.3 kg | ||
Number of batteries supported |
4 | 3 | 1 | |
Power source type |
AC | |||
Cables included |
RS-232, USB cable | Input power cable, Output power cable, USB cable | USB cable | |
Storage relative humidity (H-H) |
20 - 90% | 0 - 95% | ||
Manual |
Yes | Yes | Yes | |
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C |
Operating relative humidity (H-H) |
20 - 90% | 20 - 95% | 20 - 90% | 0 - 95% |
Storage temperature (T-T) |
-25 - 55 °C | -15 - 45 °C | ||
Form factor |
Rackmount | Rackmount | Tower | Tower |
USB port |
Yes | Yes | Yes | |
LED indicators |
Yes | Operation | ||
Battery technology |
Sealed Lead Acid (VRLA) | |||
Battery capacity |
9 Ah | 7 Ah | 9 Ah | |
Battery recharge time |
3 h | 4 h | 8 h | |
Cooling type |
Active | |||
Output power |
2000 W | 1000 W | 2100 W | 900 W |
Input frequency |
40/70 Hz | 50/60 Hz | 50/60 Hz | |
USB 2.0 ports quantity |
1 | 1 | ||
Response time |
6 ms | 4 ms | ||
Display type |
LCD | LCD | LCD | LCD |
Ethernet LAN (RJ-45) ports |
2 | 1 | ||
Number of battery cells |
4 | |||
Efficiency |
93% | 90% | ||
Input operation voltage (min) |
208 V | 110 V | 162 V | 151 V |
Power protection features |
Overload | |||
AC outlets quantity |
8 AC outlet(s) | 8 AC outlet(s) | ||
Output power capacity |
1.5 kVA | 1 kVA | 30 kVA | 1 kVA |
Output operation voltage (max) |
240 V | 240 V | 230 V | |
Waveform |
Sine | Sine | Pure sine | |
AC outlet types |
C13 coupler | C13 coupler | C20 coupler | C13 coupler |
Input operation voltage (max) |
240 V | 300 V | 290 V | 301 V |
Audible alarm(s) |
Yes | |||
Battery voltage |
12 V | 12 V | 12 V | |
Output operation voltage (min) |
200 V | 208 V | 230 V | |
UPS topology |
Double-conversion (Online) | Double-conversion (Online) | Line-Interactive | Line-Interactive |
Modem (RJ-11) ports |
1 | |||
Typical backup time at full load |
4.5 min | 2.3 min | 4 min | |
Warranty card |
Yes | |||
Automatic Voltage Regulation (AVR) |
Yes | Yes | ||
Housing material |
Metal | |||
Typical backup time at half load |
12.9 min | 9 min | 16 min | |
Surge protection |
Yes | Yes | ||
Output voltage regulation |
1% | +1.5 - 1.5% | ||
RS-232 ports |
1 | 1 | ||
Operating altitude |
0 - 1500 m | 0 - 3000 m | ||
Serial interface type |
RS-232 | RS-232 | ||
Output frequency |
50/60 Hz | |||
Noise Level |
50 dB | 45 dB | ||
Serial ports quantity |
1 | 1 | ||
Maximum current |
10 A | |||
Surge energy rating |
405 J | |||
Power plug |
C20 coupler | C14 coupler | C20 coupler | C14 coupler |
Non-operating altitude |
0 - 15000 m | |||
Product colour |
Black | Black | Black | Black |
Harmonized System (HS) code |
85078000 | 85078000 | 8504408590 | |
Products per pallet |
1 pc(s) | |||
Serial interface |
Yes | |||
Package volume |
66705.5 cm³ | |||
USB port type |
USB Type-B | |||
Output voltage Total Harmonic Distortion (THD) |
2% | |||
Hot-swap battery |
Yes | |||
UK Trade Tariff code |
85044085 | |||
Size (imperial) |
48.3 cm (19") | |||
Overload protection |
Yes | |||
Power factor |
1 | 0.99 | 0.9 | |
Surge protection features |
Fax | |||
Number of output IEC jumpers |
1 | |||
Crest factor |
3:1 | |||
Emergency Power Off (EPO) |
Yes | |||
Rack capacity |
2U | |||
Resource CD |
Yes | |||
Rack mount kit |
Yes | |||
Number of type F outputs |
8 | 3 | ||
EMI/RFI noise filtering |
Yes | |||
Emergency Power Off (EPO) connector |
Yes | Yes | Yes | |
Built-in fan |
Yes | |||
Battery recharge time (90%) |
4 h | |||
Efficiency (On-line mode) |
96% | |||
Efficiency (ECO mode) |
98% | |||
Input current Total Harmonic Distortion (THD) |
1.6% | |||
Detachable power cord |
Yes | |||
Warnings |
Do not disassemble the unit housing, there may be a risk of electric shock. | |||
