Qoltec

Qoltec 52285 uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 1000 W 2 AC outlet(s)

259,24 €

Su mokesčiais

Prekė detaliau
Greitas palyginimas

Prekė detaliau

Prekės ženklas Qoltec

Kodas WLONONWCROFIC

Yra sandėlyje 27 Prekės

Charakteristikos

Width: 385 mm
Height: 88 mm
Depth: 438 mm
Weight: 10 kg
Package depth: 470 mm
Package height: 180 mm
Package width: 550 mm
Package weight: 11 kg
Number of batteries supported: 2
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 60 °C
Form factor: Rackmount
USB port: Yes
LED indicators: Yes
Battery capacity: 7 Ah
Control type: Buttons
Cooling type: Active
Output power: 1000 W
Display type: LCD
Input operation voltage (min): 110 V
Power protection features: Short circuit
AC outlets quantity: 2 AC outlet(s)
Output power capacity: 1 kVA
Output operation voltage (max): 230 V
Waveform: Pure sine
AC outlet types: Type F
Input operation voltage (max): 300 V
Battery voltage: 24 V
UPS topology: Double-conversion (Online)
Output frequency regulation: 0.05 Hz
Output voltage regulation: 5%
RS-232 ports: 1
Serial interface type: RS-232
Output frequency: 50/60 Hz
Noise Level: 50 dB
Product colour: Black
Serial interface: Yes
Built-in fan: Yes
