Prekė detaliau
Charakteristikos
- Width
- 100 mm
- Height
- 143 mm
- Depth
- 290 mm
- Weight
- 5.2 kg
- Package height
- 226 mm
- Package width
- 139 mm
- Number of batteries supported
- 1
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 0 - 90%
- Form factor
- Mini tower
- Battery capacity
- 9 Ah
- Battery recharge time
- 6 h
- Output power
- 480 W
- Input frequency
- 50/60 Hz
- USB 2.0 ports quantity
- 1
- Display type
- LCD
- Ethernet LAN (RJ-45) ports
- 1
- Input operation voltage (min)
- 170 V
- Cold start
- Yes
- AC outlets quantity
- 4 AC outlet(s)
- Output power capacity
- 0.85 kVA
- Output operation voltage (max)
- 230 V
- Waveform
- Sine
- Input operation voltage (max)
- 280 V
- Battery voltage
- 12 V
- Output operation voltage (min)
- 230 V
- UPS topology
- Line-Interactive
- Modem (RJ-11) ports
- 1
- Output voltage regulation
- 10%
- Product colour
- Black
- Harmonized System (HS) code
- 85078000
Greitas palyginimas
Prekė |
Green Cell UPS06 uninterruptible power supply (UPS) Line-Interactive 600 VA 360 W 6 AC outlet(s) | PowerWalker VI 650 SH FR uninterruptible power supply (UPS) Line-Interactive 0.65 kVA 360 W 2 AC outlet(s) | Eaton 5E Gen2 550 uninterruptible power supply (UPS) Line-Interactive 0.55 kVA 300 W 4 AC outlet(s) | All-in-One USV, 600VA/360W,LED |
Prieinamumas |
|
|
|
|
Kaina |
70,26 €
|
70,42 €
|
70,58 €
|
70,84 €
|
Aprašymas |
||||
Width |
270 mm | 100 mm | 100 mm | 202 mm |
Height |
90 mm | 143 mm | 148 mm | 90 mm |
Depth |
190 mm | 290 mm | 288 mm | 285 mm |
Weight |
3.55 kg | 4.4 kg | 3.8 kg | 5.4 kg |
Package height |
223 mm | |||
Package width |
140 mm | 238 mm | ||
Number of batteries supported |
1 | |||
Power source type |
AC | |||
Cables included |
USB cable | |||
Manual |
Yes | Yes | ||
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | 0 - 40 °C | |
Operating relative humidity (H-H) |
0 - 90% | 0 - 90% | ||
Form factor |
Mini tower | Tower | Compact | |
USB port |
Yes | Yes | Yes | |
LED indicators |
Yes | Yes | ||
Battery capacity |
7 Ah | 7 Ah | 7 Ah | |
Control type |
Buttons | |||
Battery recharge time |
8 h | 8 h | ||
Display |
LCD | |||
Output power |
360 W | 360 W | 300 W | 360 W |
Input frequency |
50/60 Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz |
USB 2.0 ports quantity |
2 | 1 | 2 | |
Response time |
2 ms | |||
Ethernet LAN (RJ-45) ports |
2 | 2 | ||
Efficiency |
95% | |||
Input operation voltage (min) |
220 V | 170 V | 220 V | 162 V |
Power protection features |
Short circuit | Over voltage | Overdischarge | |
Cold start |
Yes | Yes | ||
AC outlets quantity |
6 AC outlet(s) | 2 AC outlet(s) | 4 AC outlet(s) | 7 AC outlet(s) |
Output power capacity |
600 VA | 0.65 kVA | 0.55 kVA | 0.6 kVA |
Output operation voltage (max) |
230 V | 230 V | 240 V | |
Waveform |
Approximate sine wave | Sine | ||
Auto-restart |
Yes | Yes | ||
AC outlet types |
Type E | C13 coupler | C13 coupler | |
Input operation voltage (max) |
240 V | 280 V | 240 V | 290 V |
Audible alarm(s) |
Yes | Yes | ||
Battery voltage |
12 V | 12 V | 12 V | |
Output operation voltage (min) |
230 V | 220 V | ||
UPS topology |
Line-Interactive | Line-Interactive | Line-Interactive | Line-Interactive |
Typical backup time at full load |
0.1 min | |||
Automatic Voltage Regulation (AVR) |
Yes | Yes | ||
Automatic battery test |
Yes | |||
Typical backup time at half load |
6 min | |||
Surge protection |
Yes | |||
Output voltage regulation |
10% | 10% | ||
Output frequency |
50/60 Hz | |||
Noise Level |
25 dB | 40 dB | ||
Power plug |
C14 coupler | |||
Product colour |
Black | Black | Black | Black |
Harmonized System (HS) code |
85078000 | 85078000 | ||
Sustainability certificates |
RoHS | |||
Sustainability compliance |
Yes | |||
Products per master (outer) case |
4 pc(s) | |||
Master (outer) case height |
250 mm | |||
Master (outer) case length |
598 mm | |||
Master (outer) case width |
380 mm | |||
Package volume |
10555.8 cm³ | |||
Charging current |
2 A | |||
UK Trade Tariff code |
85044085 | |||
Audible alarm modes |
Battery replacement | Alarm when on battery, Fault, Low battery alarm, Overload alarm | ||
Surge protection features |
Network | |||
Output power factor |
0.55 | |||
Battery recharge time (90%) |
4 h | |||
Input connection type |
4 x CEE 7/7, 3 x IEC C13 | |||
