Prekė |
UPS|EATON|2200 Watts|2200 VA|OnLine DoubleConvertion|Rack|9PX2200IRTN
|
Eaton 9PX2200IRTN uninterruptible power supply (UPS) Double-conversion (Online) 2.2 kVA 2200 W 10 AC outlet(s)
|
Eaton 9SX uninterruptible power supply (UPS) Double-conversion (Online) 3 kVA 2700 W 9 AC outlet(s)
|
Prieinamumas |
|
|
|
Kaina |
2 336,77 €
|
2 338,66 €
|
2 346,69 €
|
Aprašymas |
2200 Watts | 2200 VA | Topology OnLine DoubleConvertion | Input ports Single, IEC320 C20 | Output power connector type IEC 320 C13, IEC 320 C19 | ||
Width |
440 mm | 214 mm | |
Height |
86.5 mm | 346 mm | |
Depth |
605 mm | 412 mm | |
Weight |
25 kg | 33.4 kg | |
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | |
Form factor |
Rackmount/Tower | Tower | |
USB port |
Yes | Yes | |
LED indicators |
Yes | ||
Battery technology |
Sealed Lead Acid (VRLA) | Sealed Lead Acid (VRLA) | |
Output power |
2200 W | 2700 W | |
Input frequency |
40/70 Hz | 40/70 Hz | |
USB 2.0 ports quantity |
1 | 1 | |
Display type |
LCD | LCD | |
Garantija |
24 | ||
Category Code |
UPW | ||
Unit Box Height |
0.23 | ||
Unit Box Length |
0.77 | ||
Unit Box Width |
0.58 | ||
Vendor Homepage |
powerquality.eaton.com/9PX2200IRTN.aspx?cx 171 | ||
Dimensions |
86.5 x 440 x 605mm | ||
Efficiency |
93.5% | ||
Input operation voltage (min) |
176 V | 200 V | |
AC outlets quantity |
10 AC outlet(s) | 9 AC outlet(s) | |
Output power capacity |
2.2 kVA | 3 kVA | |
Output operation voltage (max) |
240 V | 240 V | |
Waveform |
Pure sine | Pure sine | |
AC outlet types |
C13 coupler | C19 coupler | |
Input operation voltage (max) |
276 V | 276 V | |
Output operation voltage (min) |
200 V | 200 V | |
UPS topology |
Double-conversion (Online) | Double-conversion (Online) | |
Automatic battery test |
Yes | Yes | |
Typical backup time at half load |
10 min | 15.5 min | |
Nominal input voltage |
230 V | 230 V | |
Nominal output voltage |
230 V | 230 V | |
RS-232 ports |
1 | 1 | |
Serial interface type |
RS-232 | ||
Output frequency |
50/60 Hz | 50/60 Hz | |
Noise Level |
40 dB | 45 dB | |
Power plug |
C20 coupler | C20 coupler | |
Product colour |
Black | Black | |
Harmonized System (HS) code |
85078000 | 85078000 | |
Sustainability certificates |
ENERGY STAR | ||
Safety |
IEC/EN 62040-1, UL 1778, CSA 22.2 | IEC/EN 62040-1, UL 1778, CSA 22.2 | |
Serial interface |
Yes | ||
ECO mode |
No | ||
Mounting Type (Rack) |
Yes | ||
Hot-swap battery |
Yes | Yes | |
Power factor |
1 | 0.9 | |
Rack capacity |
2U | ||
Rack mount kit |
Yes | ||
Number of input phases |
1 | 1 | |
Number of output phases |
1 | ||
Input connection type |
IEC C20 | ||
Management card included |
Yes | No | |
Units per Shipping Box |
1 | ||
Product Net Weight |
25 kg | ||
Unit Calculated Weight |
31 kg | ||
Unit Calculated Volume |
0.1027 cubm | ||
Output power capacity, W |
2200 Watts | ||
Output power capacity, VA |
2200 VA | ||
Topology |
OnLine DoubleConvertion | ||
Input ports |
Single, IEC320 C20 | ||
Output power connector type |
IEC 320 C13, IEC 320 C19 | ||
Communication ports (USB) |
1 | ||
Communication ports (RS232) |
1 | ||
