Prekė detaliau
Charakteristikos
- Width
- 438 mm
- Height
- 85.5 mm
- Depth
- 445 mm
- Weight
- 14.3 kg
- Package height
- 240 mm
- Package width
- 498 mm
- Number of batteries supported
- 3
- Cables included
- Input power cable, Output power cable, USB cable
- Manual
- Yes
- Operating temperature (T-T)
- 0 - 45 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Form factor
- Rackmount/Tower
- USB port
- Yes
- LED indicators
- Yes
- Battery capacity
- 7 Ah
- Battery recharge time
- 3 h
- Cooling type
- Active
- Output power
- 1000 W
- Input frequency
- 40/70 Hz
- Display type
- LCD
- Input operation voltage (min)
- 160 V
- Power protection features
- Overload
- AC outlets quantity
- 8 AC outlet(s)
- Output power capacity
- 1 kVA
- Output operation voltage (max)
- 240 V
- Waveform
- Pure sine
- AC outlet types
- C13 coupler
- Input operation voltage (max)
- 300 V
- Battery voltage
- 12 V
- Output operation voltage (min)
- 200 V
- UPS topology
- Double-conversion (Online)
- Output voltage regulation
- 1%
- Serial interface type
- RS-232
- Noise Level
- 45 dB
- Serial ports quantity
- 1
- Power plug
- C14 coupler
- Product colour
- Black
- Serial interface
- Yes
- ECO mode
- Yes
- Charging current
- 1.5 A
- Output voltage Total Harmonic Distortion (THD)
- 1%
- Crest factor
- 3:1
- Emergency Power Off (EPO)
- Yes
- Rack capacity
- 2U
- Rack mount kit
- Yes
- Output power factor
- 1
- Emergency Power Off (EPO) connector
- Yes
- Input power factor
- 0.99
- Built-in fan
- Yes
- Efficiency (On-line mode)
- 89%
- Input current Total Harmonic Distortion (THD)
- 5%
- Warnings
- Do not disassemble the unit housing, there may be a risk of electric shock.
