Product Details
Data sheet
- Width
- 438 mm
- Height
- 88 mm
- Depth
- 310 mm
- Weight
- 13 kg
- Number of batteries supported
- 2
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 20 - 90%
- Form factor
- Rackmount/Tower
- Battery capacity
- 9 Ah
- Battery recharge time
- 4 h
- Cooling type
- Active
- Output power
- 800 W
- Input frequency
- 40/70 Hz
- USB 2.0 ports quantity
- 1
- Response time
- 0 ms
- Display type
- LCD
- Efficiency
- 88%
- Input operation voltage (min)
- 110 V
- AC outlets quantity
- 3 AC outlet(s)
- Output power capacity
- 1 kVA
- Output operation voltage (max)
- 240 V
- Waveform
- Sine
- AC outlet types
- C13 coupler
- Input operation voltage (max)
- 300 V
- Audible alarm(s)
- Yes
- Battery voltage
- 12 V
- Output operation voltage (min)
- 220 V
- UPS topology
- Double-conversion (Online)
- Output frequency regulation
- 47 / 53 Hz
- Output voltage regulation
- 1%
- RS-232 ports
- 1
- Noise Level
- 50 dB
- Product colour
- Black
- Harmonized System (HS) code
- 85078000
- Input power factor
- 0.99
- Number of input phases
- 1
Quick Compare
Product |
APC Back-UPS PRO BR900G-GR - 900VA, 5x Schuko socket, USB
|
Qoltec Uninterruptible Power Supply (UPS) | 2kVA | 2000W | Power Factor 1.0 | LCD | EPO | USB | Online
|
CyberPower Smart App UPS Systems PR750ELCD 750 VA, 675 W
|
Availability |
|
|
|
Price |
€328.40
|
€330.00
|
€338.28
|
Description |
CyberPower Smart App UPS Systems PR750ELCD 750 VA, 675 W | ||
Producer product name |
PR750ELCD | ||
Net weight |
12.30 kg | ||
Gross weight |
13.28 kg | ||
WEEE tax |
Yes | ||
Packing quantity |
1.00 pc(s) | ||
Gross depth master carton |
595 mm | ||
Gross width master carton |
360 mm | ||
Gross height master carton |
246 mm | ||
Net weight master carton |
20.8 kg | ||
Tare weight master carton |
0.896 kg | ||
Volume (m3) |
0.04 m | ||
Tare weight (kg) |
0.98 kg | ||
Gross depth (mm) |
486.00 mm | ||
Gross width (mm) |
272.00 mm | ||
Gross height (mm) |
283.00 mm | ||
WEE classification |
CL109:5:2017-04-01 | ||
Paper/Pasteboard |
900.00 g | ||
Embeeded battery |
No | ||
TI weight (kg) |
3.5 kg | ||
Cable length |
1.83 m | ||
Width |
100 mm | 141 mm | |
Dimensions (WxDxH) |
136 x 349 x 162 mm | ||
Height |
382 mm | 225 mm | |
Depth |
250 mm | 395 mm | |
Other features |
Line-interactive UPS Topology Active PFC Compatible Automatic Voltage Regulation (AVR) Critical/Non-critical Load Outlets Surge and Spike Protection LCD Status Display USB Connectivity Port PowerPanel Management Software Tower Form Factor Energy Saving Te | ||
Plastic (No PET) |
80.00 g | ||
Composition of battery |
CL127:KT:2016-12-09 | ||
Classification of battery |
CL126:PE:2016-12-09 | ||
Type of battery |
Accumulator | ||
Weight |
10.7 kg | 17.1 kg | |
Producer product family |
Smart App UPS Systems | ||
Package depth |
475 mm | ||
Package height |
487 mm | 330 mm | |
Package width |
225 mm | 235 mm | |
Package weight |
18.1 kg | ||
Number of batteries supported |
4 | ||
Cables included |
Phone (RJ-11) | ||
Storage relative humidity (H-H) |
0 - 95% | ||
Manual |
Yes | ||
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | |
Operating relative humidity (H-H) |
0 - 95% | 20 - 95% | |
Storage temperature (T-T) |
-15 - 45 °C | -15 - 60 °C | |
Form factor |
Compact | Tower | |
USB port |
Yes | Yes | |
LED indicators |
Yes | ||
Battery technology |
Sealed Lead Acid (VRLA) | ||
Battery life (max) |
5 year(s) | ||
Battery capacity |
157 VAh | 9 Ah | |
Capacity |
750 VA | ||
Control type |
Buttons | ||
Palette Qty |
46 pc(s) | ||
Battery recharge time |
8 h | 8 (Typical) 3 (Quick) h | |
Cooling type |
Passive | ||
Output power |
540 W | 2000 W | |
Input frequency |
50/60 Hz | ||
USB 2.0 ports quantity |
1 | ||
Display type |
LCD | LCD | |
Ethernet LAN (RJ-45) ports |
2 | ||
Garantija |
24 | ||
Efficiency |
97.4% | ||
Input operation voltage (min) |
156 V | 110 V | |
Power protection features |
Short circuit | ||
Cold start |
Yes | ||
AC outlets quantity |
5 AC outlet(s) | 3 AC outlet(s) | |
Output power capacity |
0.9 kVA | 2 kVA | |
Output operation voltage (max) |
240 V | ||
Waveform |
Pure sine | ||
AC outlet types |
Type F | Type F | |
Input operation voltage (max) |
300 V | 300 V | |
Audible alarm(s) |
Yes | ||
Battery voltage |
48 V | ||
Output operation voltage (min) |
220 V | ||
UPS topology |
Line-Interactive | Double-conversion (Online) | Line-Interactive |
Typical backup time at full load |
4.6 min | 2.5 min | |
Warranty card |
Yes | ||
Automatic Voltage Regulation (AVR) |
Yes | ||
Automatic battery test |
Yes | ||
Typical backup time at half load |
16.3 min | 10.5 min | |
Surge protection |
Yes | ||
Nominal input voltage |
230 V | ||
Nominal output voltage |
230 V | ||
Output frequency regulation |
50/60 Hz | 0.05 Hz | |
Output voltage regulation |
5% | ||
RS-232 ports |
1 | ||
Operating altitude |
0 - 3000 m | ||
Serial interface type |
RJ-45, RS-232 | ||
Output frequency |
50/60 Hz | ||
Noise Level |
45 dB | 50 dB | |
Surge energy rating |
613 J | ||
Non-operating altitude |
0 - 15000 m | ||
Product colour |
Black | Black | |
Harmonized System (HS) code |
85078000 | ||
Sustainability certificates |
Green Premium | ||
Serial interface |
Yes | ||
USB port type |
USB Type-B | ||
Charging current |
5 A | ||
Compliance certificates |
RoHS | ||
Audible alarm modes |
Low battery alarm, Overload alarm | ||
Hold time (max) |
10 ms | ||
Hold time (min) |
8 ms | ||
Surge protection features |
Modem | ||
SmartSlot |
No | ||
Replacement battery cartridge |
APCRBC123 | ||
Number of type F outputs |
5 | ||
Built-in fan |
Yes | ||
Management card included |
No | ||
Warnings |
Do not disassemble the unit housing, there may be a risk of electric shock. | ||
SmartConnect port |
No | ||
