HP Pro 290 SFF G9 i5-12400 16GB DDR4 SSD512 UHD W11Pro 3Y OnSite

Product Details

Data sheet

Width

95 mm

Height

95 mm

Depth

303 mm

Weight

4.2 kg

Product type

PC

Package depth

498 mm

Package height

346 mm

Package width

196 mm

Package weight

6 kg

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90%

Optical drive type

DVD±RW

Bluetooth

Yes

Power supply

180 W

SSD form factor

M.2

Display included

No

Country of origin

China

Memory clock speed

3200 MHz

Internal memory type

DDR4-SDRAM

Memory slots

2x DIMM

Processor family

Intel® Core™ i5

Processor model

i5-12400

Processor threads

12

Processor cores

6

Processor boost frequency

4.4 GHz

HDMI ports quantity

1

Wi-Fi

Yes

Internal memory

16 GB

Wi-Fi standards

802.11a

Operating system installed

Windows 11 Pro

USB 2.0 ports quantity

4

VGA (D-Sub) ports quantity

1

Cable lock slot

Yes

Ethernet LAN (RJ-45) ports

1

Chassis type

SFF

Storage media

SSD

Operating system architecture

64-bit

Total storage capacity

512 GB

MOTHERBOARD CHIPSET

Intel H670

SSD Capacity

512 GB

Power supply input frequency

50 - 60 Hz

Line-in

Yes

Ethernet LAN data rates

1000 Mbit/s

Ethernet LAN

Yes

Bus type

DMI4

NVMe

Yes

Processor cache

18 MB

Number of 3.5" bays

1

Password protection

Yes

CPU configuration (max)

1

Product colour

Black

Market positioning

Proven productivity

HP segment

Business

Sustainability certificates

EPEAT

Sustainability compliance

Yes

Introduction year

2022

Sustainable technologies and materials

Mercury free

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

4

Processor manufacturer

Intel

Processor generation

12th gen Intel® Core™ i5

Processor cache type

L3

On-board graphics card

Yes

On-board graphics card model

Intel UHD Graphics 730

Discrete graphics card model

Not available

Discrete graphics card

No

Colour name

Jack black

Trusted Platform Module (TPM) version

2.0

Password protection type

Power on

Trusted Platform Module (TPM)

Yes

Mobile network connection

No

Top Wi-Fi standard

Wi-Fi 5 (802.11ac)

Embedded options available

No

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Idle States

Yes

Audio chip

Realtek ALC3867

Total SSDs capacity

512 GB

Number of SSDs installed

1

SSD interface

PCI Express

Combo headphone/mic port

Yes

On-board graphics card family

Intel® UHD Graphics

HP Support Assistant

Yes

HP JumpStart

Yes

Execute Disable Bit

Yes

Enhanced Intel SpeedStep Technology

Yes

Intel 64

Yes

On-board GPU manufacturer

Intel

HP Documentation

Yes

Number of storage drives installed

1

Power supply input voltage

100 - 240 V

PCI Express x16 (Gen 4.x) slots

1

PCI Express x1 (Gen 3.x) slots

1

Line-out

Yes

Intel® Turbo Boost Technology

Yes

HP Security tools

Padlock loop; Trusted Platform Module (TPM) 2.0; Integrated accessories cable lock; Slim cable lock

Carbon emissions, logistics (kg of CO2e)

4

Carbon emissions, end-of-life (kg of CO2e)

15

Total carbon emissions, w/o use phase (kg of CO2e)

26

Total carbon footprint (kg of CO2e)

150

Carbon emissions, manufacturing (kg of CO2e)

111

General Product Safety Regulation (GPSR) URL

https://kaas.hpcloud.hp.com/pdf-public/pdf_11069394_en-US-1.pdf
