Intel

Intel Core i5-14600K processor 24 MB Smart Cache Box

€274.72

Tax included

Product Details
Quick Compare

Product Details

Reference PROINTCI50280

In stock 15 Items

Data sheet

ECC: Yes
Processor family: Intel® Core™ i5
Processor socket: LGA 1700
Non-ECC: Yes
Processor model: i5-14600K
Processor threads: 20
Processor cores: 14
Memory types supported by processor: DDR5-SDRAM
PCI Express slots version: 4.0
Cooler included: No
Memory bandwidth (max): 89.6 GB/s
Maximum internal memory: 192 GB
Processor cache: 24 MB
Thermal solution specification: PCG 2020A
CPU configuration (max): 1
Harmonized System (HS) code: 8542310001
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Memory channels: Dual-channel
Processor manufacturer: Intel
Processor generation: Intel® Core™ i5 (14th gen)
Processor cache type: Smart Cache
On-board graphics card: Yes
On-board graphics card model: Intel UHD Graphics 770
Discrete graphics card model: Not available
Discrete graphics card: No
Embedded options available: No
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Idle States: Yes
On-board graphics card DirectX version: 12.0
On-board graphics card OpenGL version: 4.5
On-board graphics card dynamic frequency (max): 1550 MHz
On-board graphics card base frequency: 300 MHz
On-board graphics card ID: 0xA780
Execute Disable Bit: Yes
Processor codename: Raptor Lake
Maximum number of PCI Express lanes: 20
Processor operating modes: 64-bit
PCI Express configurations: 1x16+1x4
Number of execution units: 32
Intel® Quick Sync Video Technology: Yes
Intel® OS Guard: Yes
Intel® Clear Video HD Technology (Intel® CVT HD): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Enhanced Intel SpeedStep Technology: Yes
Thermal Monitoring Technologies: Yes
Processor package size: 45 x 37.5 mm
Supported instruction sets: SSE4.1
Intel 64: Yes
Intel® Secure Key: Yes
Processor ARK ID: 236799
Stepping: B0
Performance cores: 6
Performance-core base frequency: 3.5 GHz
Maximum turbo power: 181 W
Performance-core boost frequency: 5.3 GHz
Processor base power: 125 W
Efficient cores: 8
Tjunction: 100 °C
Memory bandwidth supported by processor (max): 89.6 GB/s
Maximum internal memory supported by processor: 192 GB
Number of displays supported (on-board graphics): 4
Intel® Turbo Boost Technology: 2.0
Scalability: 1S
Export Control Classification Number (ECCN): 5A992C
Launch date: Q4'23
Status: Launched
Warnings: Do not dispose of the processors in the normal rubbish bin - they require special disposal due to their potential environmental impact.
Market segment: Desktop
OpenCL version: 3.0
On-board graphics card outputs supported: HDMI 2.1
L2 cache: 20480 KB
Box: Yes
Maximum number of DMI lanes: 8
Direct Media Interface (DMI) Revision: 4.0
Use conditions: PC/Client/Tablet
Intel® Speed Shift Technology: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Thread Director: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Boot Guard: Yes
Mode-based Execute Control (MBE): Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
Intel® Volume Management Device (VMD): Yes
Intel® Standard Manageability (ISM): Yes
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 5120 x 3200 pixels
Multi-Format Codec Engines: 2
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz
On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
