Gigabyte

Mainboard|GIGABYTE|Intel B860 Express|LGA1851|Micro-ATX|Memory DDR5|Memory slots 4|2xPCI-Express 1x|1xPCI-Express 16x|2xM.2|1xHD

€140.26

Tax included

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

Hybrid 4+1+2+1 Phases 50A PPAK VRM
Dual Channel DDR5：4*DIMMs
PCIe 5.0 x16 with PCIE UD Slot & EZ-Latch
MOSFET Heatsinks & PCH Heatsink
1GbE LAN, USB 3.2 Gen1 Type-C

Product Details

Reference B860M D3HP 1.0

In stock 7 Items

Data sheet

Garantija: 36
Category Code: MBI
Unit Box Height: 0.055
Unit Box Length: 0.265
Unit Box Width: 0.265
Vendor Homepage: https://www.gigabyte.com/
MODEL: B860M D3HP
Units per Shipping Box: 10
Unit Calculated Weight: 1.05 kg
Unit Calculated Volume: 0.004588 cubm
Summary: GIGABYTE B860M D3HP Motherboard - Intel Core Ultra Series CPUs, 4+1+2+1 Phases VRM, up to 9066MHz DDR5, 2xPCIe 4.0 M.2, GbE LAN, USB 3.2 Gen 1. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core
Battery (Battery technology): Lithium-Manganese Dioxide (LiMnO2)
Weight & dimensions (Width): 244 mm
Weight & dimensions (Depth): 244 mm
Weight & dimensions (Height): 35 mm
Packaging data (Package width): 265 mm
Packaging data (Package depth): 265 mm
Packaging data (Package height): 54 mm
Network (Ethernet LAN): Yes
Network (Wi-Fi): No
Battery (Battery type): CR2032
Logistics data (Products per shipping (inner) case): 1 pc(s)
Other features (Weight): 1100 g
Packaging content (Batteries included): Yes
Logistics data (Country of origin): China
Processor (Processor manufacturer): Intel
Memory (Maximum internal memory): 256 GB
Memory (Memory channels): Dual-channel
Memory (Memory slots type): DIMM
Memory (Number of memory slots): 4
Memory (Supported memory clock speeds): 5600/6400/9066 MHz
Memory (Supported memory types): DDR5-SDRAM
Features (Component for): PC
Features (Cooling type): Passive
Battery (Battery weight): 3 g
Network (LAN controller): Realtek RTL8111H
Features (Audio chip): Realtek ALC897
Features (Audio output channels): 7.1 channels
Features (Motherboard chipset): Intel B860
Features (Motherboard chipset family): Intel
Features (Motherboard form factor): micro ATX
Features (PC health monitoring): Fan/Temperature/Voltage/Water cooling
Features (Power source type): ATX
Features (Product colour): Dark brown
Features (Windows operating systems supported): Windows 10 x64/Windows 11 x64
Processor (Compatible processor series): Intel Core Ultra (Series 2)/Intel Core Ultra (Series 1)
Processor (Processor socket): LGA 1851 (Socket V1)
Processor (Supported processor sockets): LGA 1851
Memory (ECC сompatibility): ECC & Non-ECC
Memory (Maximum internal memory per slot): 64 GB
Memory (Supported memory clock speed (max)): 9066 MHz
Memory (Unbuffered memory): Yes
Storage controllers (Number of HDDs supported): 4
Storage controllers (Number of storage drives supported): 6
Storage controllers (RAID levels): 0/1/10/5
Storage controllers (RAID support): Yes
Storage controllers (Supported storage drive interfaces): M.2,SATA III
Storage controllers (Supported storage drive types): HDD & SSD
Graphics (DirectX version): 12.0
Graphics (HDCP): Yes
Graphics (Maximum resolution): 4096 x 2160 pixels
Graphics (Parallel processing technology support): Not supported
Internal I/O (ATX Power connector (24-pin)): Yes
Internal I/O (CPU fan connector): Yes
Internal I/O (EPS power connector (8-pin)): Yes
Internal I/O (Front panel audio connector): Yes
Internal I/O (Front panel connector): Yes
Internal I/O (Number of chassis fan connectors): 2
Internal I/O (Number of CPU fan connectors): 2
Internal I/O (Number of EPS power connectors (8-pin)): 1
Internal I/O (Number of RGB LED pin headers): 3
Internal I/O (Number of SATA III connectors): 4
Internal I/O (Number of water pump connectors): 2
Internal I/O (RGB LED pin header): Yes
Internal I/O (TPM connector): Yes
Internal I/O (USB 2.0 connectors): 2
Internal I/O (USB 3.2 Gen 1 (3.1 Gen 1) connectors): 2
Rear panel I/O ports (DisplayPort version): 2.1
Rear panel I/O ports (Ethernet LAN (RJ-45) ports): 1
Rear panel I/O ports (HDMI ports quantity): 1
Rear panel I/O ports (HDMI version): 2.1
Rear panel I/O ports (Headphone outputs): 1
Rear panel I/O ports (Line-in): Yes
Network (Ethernet interface type): Gigabit Ethernet
Expansion slots (1st M.2 highest PCI Express generation): 4.0
Expansion slots (1st M.2 largest key size): 2280
Expansion slots (2nd M.2 highest PCI Express generation): 4.0
Expansion slots (2nd M.2 largest key size): 2280
Expansion slots (Number of M.2 (M) slots): 2
Expansion slots (PCI Express x16 (Gen 5.x) slots): 1
BIOS (ACPI version): 5.0
BIOS (BIOS memory size): 256 Mbit
BIOS (BIOS type): UEFI AMI
BIOS (Clear CMOS jumper): Yes
BIOS (Desktop Management Interface (DMI) version): 2.7
BIOS (System Management BIOS (SMBIOS) version): 2.7
Battery (Lithium weight per battery): 0.07 g
Battery (Number of battery cells): 1
Packaging content (Bundled software): Norton Internet Security (OEM version) LAN bandwidth management software
Packaging content (Screws included): Yes
Technical details (Warranty period): 3 year(s)
Internal I/O (Serial port headers): 1
Rear panel I/O ports (DisplayPorts quantity): 1
Rear panel I/O ports (PS/2 ports quantity): 1
Rear panel I/O ports (USB 2.0 ports quantity): 3
Rear panel I/O ports (USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity): 3
Expansion slots (PCI Express x1 (Gen 3.x) slots): 2
