Gigabyte

Mainboard|GIGABYTE|Intel H610|LGA1700|Micro-ATX|Memory DDR5|Memory slots 2|1xPCI-Express 3.0 1x|1xPCI-Express 4.0 16x|1xM.2|1x15

€74.55

Tax included

H610M S2H V2

Intel® H610 Motherboard with 4+1+1 Hybrid Phases Digital VRM Design, PCIe 4.0* Design, Gen3 x4 M.2, 2*DisplayPort / HDMI / D-Sub Ports for Multiple Display , Anti-Sulfur Resistor, Smart Fan 6

Supports Intel® Core™ 14th/ 13th /12th processors
Dual Channel Non-ECC Unbuffered DDR5, 2 DIMMs
4+1+1 Hybrid Digital VRM Design
GbE LAN with Bandwidth Management
NVMe PCIe 3.0 x4 M.2
2*DisplayPort / HDMI / D-Sub Ports for Multiple Display
High Quality Audio Capacitors and Audio Noise Guard
Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
GIGABYTE APP Center, Simple and Easy Use
Anti-Sulfur Resistors Design

Product Details

Reference H610MS2HV21.0

In stock 30 Items

Data sheet

Form factor: Micro-ATX
Memory type: DDR5
Memory slots: 2
Chipset: Intel H610
Garantija: 36
SOCKET: LGA1700
Category Code: MBI
Frequency speed: 4400/4800/5200/5600 MHz
Unit Box Height: 0.055
Unit Box Length: 0.265
Unit Box Width: 0.235
Vendor Homepage: www.gigabyte.com/Motherboard/H610M-S2H-V2-rev-10 kf
Interface (SATA): Yes
Input/Output connectors (Audio port): 3
Input/Output connectors (HDMI): 1
Integrated LAN: Gigabit
Integrated video: Depending on CPU
Expansion slots (M.2): 1
Input/Output connectors (PS/2): 1
Input/Output connectors (RJ45): 1
Interface (Serial): Yes
TPM: Header
Input/Output connectors (USB 2.0): 4
Interface (USB 2.0): Yes
Input/Output connectors (DisplayPort): 2
Expansion slots (PCI-Express 3.0 1x): 1
Expansion slots (PCI-Express 4.0 16x): 1
Input/Output connectors (USB 3.2): 2
Input/Output connectors (15pin D-sub): 1
Interface (USB 3.2): Yes
MODEL: H610M S2H V2
Units per Shipping Box: 10
Product Net Weight: 0.5 kg
Unit Calculated Weight: 0.787 kg
Unit Calculated Volume: 0.004113 cubm

Quick Compare
