Product Details
Data sheet
- Cables included
- AC
- Storage relative humidity (H-H)
- 5 - 95%
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 20 - 80%
- Storage temperature (T-T)
- -20 - 60 °C
- USB port
- Yes
- Mean time between failures (MTBF)
- 50000 h
- Processor model
- A53
- Processor cores
- 8
- HDMI ports quantity
- 2
- DisplayPorts quantity
- 1
- Display technology
- LCD
- Wi-Fi
- Yes
- Internal memory
- 4 GB
- Operating system installed
- Android
- Internal storage capacity
- 32 GB
- Display diagonal
- 190.5 cm (75")
- Operating system version
- 14
- Audio formats supported
- AAC
- USB version
- 2.0/3.2 Gen 2 (3.1 Gen 2)
- USB ports quantity
- 1
- Display brightness
- 600 cd/m²
- Response time
- 8 ms
- HD type
- Full HD
- Contrast ratio (typical)
- 1200:1
- Viewing angle, horizontal
- 178°
- Viewing angle, vertical
- 178°
- Native aspect ratio
- 16:9
- Built-in speaker(s)
- Yes
- VESA mounting
- Yes
- RMS rated power
- 20 W
- On Screen Display (OSD) languages
- Simplified Chinese
- Panel type
- VA
- HDMI version
- 2.0
- DisplayPort version
- 1.4
- Contrast ratio (dynamic)
- 500000:1
- Display number of colours
- 1.07 billion colours
- Pixel pitch
- 0.2854 x 0.2854 mm
- Display diagonal (metric)
- 125.7 cm
- Ethernet LAN (RJ-45) ports
- 1
- Ethernet LAN
- Yes
- USB connector type
- Micro-USB B
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50/60 Hz
- RS-232C
- Yes
- Number of built-in speakers
- 2
- On Screen Display (OSD)
- Yes
- Video formats supported
- AVI
- Built-in processor
- Yes
- Image formats supported
- BMP
- Product colour
- Black
- Energy efficiency class (SDR)
- F
- Display resolution
- 3840 x 2160 pixels
- Panel mounting interface
- 200 x 200 mm
- Number of OSD languages
- 18
- Bezel width (bottom)
- 1.49 cm
- Bezel width (side)
- 1.49 cm
- Bezel width (top)
- 1.49 cm
- Haze rate
- 25%
- Processor manufacturer
- ARM
- On-board graphics card model
- Mali-G52 MC3
- RS-232 interface
- Yes
- Computer system
- Yes
- Remote (IR) input
- 1
- Remote (IR) output
- 1
- Compliance certificates
- RoHS
- Display weight
- 37 kg
- Display height
- 961.7 mm
- Display width
- 1683.5 mm
- Computer system type
- System on Chip (SoC)
- Number of antenna connectors
- 1
