Product Details
Data sheet
- Plug and Play
- Yes
- Package weight
- 9.97 kg
- Cables included
- DisplayPort
- Storage relative humidity (H-H)
- 5 - 90%
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 10 - 80%
- Storage temperature (T-T)
- -20 - 60 °C
- LED indicators
- Yes
- Headphone out
- No
- Power supply type
- Internal
- Quick start guide
- Yes
- HDMI ports quantity
- 1
- DisplayPorts quantity
- 2
- Display technology
- QD-OLED
- Display diagonal
- 67.8 cm (26.7")
- Built-in camera
- No
- Power consumption (max)
- 130 W
- Power consumption (typical)
- 27.6 W
- HDCP
- Yes
- Response time
- 0.03 ms
- HD type
- Quad HD
- Viewing angle, horizontal
- 178°
- Viewing angle, vertical
- 178°
- Native aspect ratio
- 16:9
- Built-in speaker(s)
- No
- VESA mounting
- Yes
- Swivelling
- Yes
- Tilt adjustment
- Yes
- Height adjustment
- YES
- Cable lock slot
- Yes
- Horizontal scan range
- 27 - 621.32 kHz
- Vertical scan range
- 48 - 360 Hz
- Viewable size, horizontal
- 59 cm
- Viewable size, vertical
- 33.4 cm
- USB hub version
- 2.0 / 3.2 Gen 1 (3.1 Gen 1)
- Number of upstream ports
- 1
- USB Type-A downstream ports quantity
- 3
- NVIDIA G-SYNC
- No
- Swivel angle range
- -20 - 20°
- Pivot
- YES
- Pivot angle
- -90 - 90°
- Power consumption (standby)
- 0.5 W
- Width (with stand)
- 609.1 mm
- Depth (with stand)
- 243.7 mm
- Height (with stand)
- 516.2 mm
- Panel type
- OLED
- Maximum refresh rate
- 359.98 Hz
- HDMI version
- 2.1
- DisplayPort version
- 1.4
- Contrast ratio (dynamic)
- 1500000:1
- HDMI
- Yes
- Touchscreen
- No
- Display number of colours
- 1.07 billion colours
- Power consumption (off)
- 0.3 W
- Pixel pitch
- 0.2292 x 0.2292 mm
- Pixel density
- 111 ppi
- Display diagonal (metric)
- 678.2 cm
- USB Type-C downstream ports quantity
- 1
- USB upstream port type
- USB Type-B
- AC (power) in
- Yes
- AC input voltage
- 100 - 240 V
- Cable lock slot type
- Kensington
- AC input frequency
- 50/60 Hz
- Supported graphics resolutions
- 1152 x 864 (XGA+)
- Operating altitude
- 0 - 5000 m
- Cable management
- Yes
- On Screen Display (OSD)
- Yes
- Supported video modes
- 480p
- Colour Gamut
- 99.3%
- Stand included
- Yes
- Wall mountable
- Yes
- Screen shape
- Flat
- Built-in USB hub
- Yes
- Non-operating altitude
- 5000 - 12192 m
- Feet colour
- Black
- Heavy metals free
- Hg (mercury)
- Product colour
- Black
- Market positioning
- Gaming
- Energy consumption (SDR) per 1000 hours
- 28 kWh
- Energy efficiency class (SDR)
- G
- Width (without stand)
- 609.1 mm
- Weight (with stand)
- 6.3 kg
- Height (without stand)
- 359 mm
- Depth (without stand)
- 67.6 mm
- Flicker-free technology
- Yes
- AMD FreeSync
- Yes
- Low Blue Light technology
- Yes
- Display resolution
- 2560 x 1440 pixels
- Display brightness (typical)
- 250 cd/m²
- Tilt angle range
- -5 - 21°
- Panel mounting interface
- 100 x 100 mm
- Weight (without stand)
- 4.3 kg
- High Dynamic Range (HDR) supported
- Yes
- Energy efficiency scale
- A to G
- AMD FreeSync type
- FreeSync Premium Pro
- Energy efficiency class (HDR)
- G
- Energy consumption (HDR) per 1000 hours
- 28 kWh
- High Dynamic Range (HDR) technology
- DisplayHDR 400 True Black
- Smart modes
- MOBA/RTS
- HDCP version
- 1.4/2.3
- Display brightness (peak)
- 1000 cd/m²
- Front bezel colour
- Black
- Bezel width (bottom)
- 1.94 cm
- Bezel width (side)
- 9.35 mm
- Bezel width (top)
- 5.84 mm
- Doesn't contain
- PVC/BFR
- Sustainability compliance
- Yes
- Colour gamut standard
- DCI-P3
- European Product Registry for Energy Labelling (EPREL) code
- 1833147
- Compliance certificates
- RoHS
- Adjustable height (max)
- 11 cm
