Product Details
Data sheet
- Plug and Play
- Yes
- Package depth
- 124 mm
- Package height
- 370 mm
- Package width
- 610 mm
- Package weight
- 4.68 kg
- Cables included
- HDMI
- Manual
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 20 - 80%
- Storage temperature (T-T)
- -20 - 60 °C
- LED indicators
- Operation
- Power supply type
- External
- Audio output
- Yes
- Mean time between failures (MTBF)
- 50000 h
- HDMI ports quantity
- 1
- Display technology
- LCD
- Display diagonal
- 60.5 cm (23.8")
- Backlight type
- W-LED
- Built-in camera
- No
- VGA (D-Sub) ports quantity
- 1
- Power consumption (typical)
- 14.5 W
- HDCP
- Yes
- Response time
- 4 ms
- HD type
- Full HD
- Contrast ratio (typical)
- 1300:1
- Viewing angle, horizontal
- 178°
- Viewing angle, vertical
- 178°
- Native aspect ratio
- 16:9
- Built-in speaker(s)
- Yes
- VESA mounting
- Yes
- Tilt adjustment
- Yes
- Cable lock slot
- Yes
- Horizontal scan range
- 30 - 85 kHz
- Vertical scan range
- 48 - 60 Hz
- Viewable size, horizontal
- 52.7 cm
- Viewable size, vertical
- 29.6 cm
- DDC/CI
- Yes
- RMS rated power
- 4 W
- NVIDIA G-SYNC
- No
- On Screen Display (OSD) languages
- Spanish
- Power consumption (standby)
- 0.5 W
- Width (with stand)
- 542 mm
- Depth (with stand)
- 180 mm
- Height (with stand)
- 417 mm
- Panel type
- IPS
- Maximum refresh rate
- 100 Hz
- HDMI version
- 1.4
- Number of speakers
- 2
- HDMI
- Yes
- Touchscreen
- No
- Display sRGB
- Yes
- Display number of colours
- 16.7 million colours
- Power consumption (off)
- 0.3 W
- Audio input
- Yes
- Pixel pitch
- 0.2745 x 0.2745 mm
- Pixel density
- 92.56 ppi
- Display diagonal (metric)
- 60.5 cm
- AC input voltage
- 100 - 240 V
- Cable lock slot type
- Kensington
- AC input frequency
- 50/60 Hz
- Digital horizontal frequency
- 30 - 115 kHz
- Operating altitude
- 0 - 3658 m
- On Screen Display (OSD)
- Yes
- Stand included
- Yes
- Screen shape
- Flat
- Built-in USB hub
- No
- Non-operating altitude
- 3658 - 12192 m
- Feet colour
- Black
- Heavy metals free
- Hg (mercury)
- Product colour
- Black
- Market positioning
- Home
- Energy efficiency class (SDR)
- D
- Width (without stand)
- 542 mm
- Weight (with stand)
- 2.92 kg
- Height (without stand)
- 316 mm
- Depth (without stand)
- 45 mm
- Flicker-free technology
- Yes
- AMD FreeSync
- No
- Low Blue Light technology
- Yes
- Display resolution
- 1920 x 1080 pixels
- Display brightness (typical)
- 300 cd/m²
- Digital vertical frequency
- 48 - 100 Hz
- Surface hardness
- 3H
- Tilt angle range
- -5 - 20°
- Panel mounting interface
- 100 x 100 mm
- Weight (without stand)
- 2.57 kg
- Response time (fast)
- 1 ms
- Anti-glare screen
- Yes
- Energy efficiency class (HDR)
- Not available
- Dynamic contrast ratio marketing name
- Mega Infinity DCR
- Number of OSD languages
- 21
- HDCP version
- 1.4
- VESA Adaptive Sync support
- Yes
- Doesn't contain
- Mercury
- Component video sync
- Separate sync
- EasyRead mode
- Yes
- Haze rate
- 25%
- LowBlue mode
- Yes
- Picture enhancement
- SmartImage game
- Sustainability compliance
- Yes
- Colour gamut standard
- sRGB
- European Product Registry for Energy Labelling (EPREL) code
- 1868751
- Compliance certificates
- Federal Communications Commission (FCC)
- Warnings
- Unplug the monitor from the power source before cleaning.
