Power Supply|SEASONIC|SRP-CGX851-A5A32SF|850 Watts|Peak Power 850 Watts|Efficiency 80 PLUS GOLD|SRP-CGX851-A5A32SF
    SEASONIC

    Power Supply|SEASONIC|SRP-CGX851-A5A32SF|850 Watts|Peak Power 850 Watts|Efficiency 80 PLUS GOLD|SRP-CGX851-A5A32SF

    €131.67
    Tax included
    850 W | 100 - 240 V | 80 PLUS certification 80 PLUS Gold | PC | ATX | Fan diameter 120 mm | Package type Box | SRP-CGX851-A5A32SF
    Quantity

    Add to favorites Add to compare

    The updated Seasonic CORE GX ATX3 series complies with the latest ATX 3.1 and PCIe 5.1 standards and includes four output ranges from 1000 W to 650 W in both black and white colors. Catering to a broad spectrum of PC enthusiasts and system builders, these power supplies provide a fine balance between cost and performance. The 80 PLUS® Gold certified Seasonic’s Core GX line is a fully modular design equipped with black cables featuring a braided pattern. These power supplies are solid performers for a large range of applications, where a 120 mm Hydro Dynamic Bearing fan is combined with Seasonic’s Smart and Silent Fan Control to ensure the optimal cooling performance at the lowest possible noise level. These quality power supplies are backed up by Sea Sonic’s 7-year worldwide manufacturer’s warranty.

    New Seasonic OptiSink Design
    The overall quality and reliability of the new CORE GXATX 3 Series has been greatly improved by a brand-new PCB (Printed Circuit Board) layout and the implementation of automated surface mount technology during production, which minimizes human production errors.

    By using a redesigned PCB combined with smaller MOSFET and heat sink components, the internal space within the power supply was increased to enhance heat dissipation and airflow to result in better component cooling.

    Fully Modular Cables
    In Sea Sonic’s patented design feature full modularity comes hand-in-hand with the extensive use of SMD technology to increase the overall performance and reliability of this power supply. The simple and inventive layout scheme helps to attain unsurpassed quality and performance, where efficiency is further enhanced by minimized line resistance, reduced voltage drop and lower impedance. Reduced component count and better space utilization facilitate optimal air flow inside the case and promote heat dissipation, proper cooling and ultimately longer product life.

    Product Details

    SEASONIC
    SRP-CGX851-A5A32SF
    100 Items

    Data sheet

    Garantija
    84
    Category Code
    PSU
    Unit Box Height
    0.19
    Unit Box Length
    0.275
    Unit Box Width
    0.115
    Vendor Homepage
    https://seasonic.com/core-gx-atx-3-2024/
    Model name
    SRP-CGX851-A5A32SF
    Units per Shipping Box
    5
    Unit Calculated Weight
    3.24 kg
    Unit Calculated Volume
    0.00732 cubm
    CnCode
    85044095
    Summary
    Seasonic SRP-CGX851-A5A32SF. Total power: 850 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, C
    Weight & dimensions (Width)
    150 mm
    Weight & dimensions (Depth)
    140 mm
    Weight & dimensions (Height)
    86 mm
    Packaging content (Cables included)
    AC,Peripheral (Molex) to SATA 3.3,CPU,PCIe,SATA
    Design (Product colour)
    Black
    Packaging data (Package type)
    Box
    Power (AC input frequency)
    50/60 Hz
    Power (AC input voltage)
    100 - 240 V
    Certificates (Certification)
    BSMI, C-tick, CB, CCC, CE, cTUVus, EAC, FCC, TUV, UKCA
    Operational conditions (Operating temperature (T-T))
    0 - 50 C
    Power (Input current)
    9 A
    Design (Cooling type)
    Active
    Design (Number of fans)
    1 fan(s)
    Design (Fan diameter)
    120 mm
    Power (Combined power (+12V))
    840 W
    Power (Combined power (+3.3V))
    100 W
    Power (Combined power (+5Vsb))
    15 W
    Power (Combined power (-12V))
    3.6 W
    Power (Max output current (+12V))
    70 A
    Power (Max output current (+3.3V))
    20 A
    Power (Max output current (+5V))
    20 A
    Power (Max output current (+5Vsb))
    3 A
    Power (Max output current (-12V))
    0.3 A
    Power (Power protection features)
    Over current/Over power/Over total voltage/Over voltage/Short circuit/Under voltage
    Power (Total power)
    850 W
    Ports & interfaces (Cabling type)
    Fully-Modular
    Performance (80 PLUS certification)
    80 PLUS Gold
    Performance (Mean time between failures (MTBF))
    100000 h
    Performance (Power supply unit (PSU) form factor)
    ATX
    Performance (Purpose)
    PC
    Design (On/off switch)
    Yes
    Performance (ATX version)
    3.1
    Ports & interfaces (Number of PATA power connectors)
    2
