IP Network Camera 5MP HFW3549T1-AS-PV-S3 3.6mm
    DAHUA TECHNOLOGY CO., LTD

    IP Network Camera 5MP HFW3549T1-AS-PV-S3 3.6mm

    €238.79
    Tax included
    Quantity

    Add to favorites Add to compare
    Camera
    Image Sensor 1/2.7" CMOS
    Max. Resolution 2592 (H) × 1944 (V)
    ROM 128 MB
    RAM 512 MB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    Min. Illumination 0.003 lux@F1.0 (Color, 30 IRE)
    0.0003 lux@F1.0 (B/W, 30 IRE)
    0 lux (illuminator on)
    S/N Ratio ? 56 dB
    Illumination Distance 30 m (98.43 ft) (IR)
    30 m (98.43 ft) (warm light)
    Illuminator On/Off Control Auto/Manual
    Illuminator Number 2 (IR LED)
    2 (warm light)
    Pan/Tilt/Rotation Range Pan: 0°–360°
    Tilt: 0°–90°
    Rotation: 0°–360°
    Lens
    Lens Type Fixed-focal
    Mount Type M12
    Focal Length 3.6 mm
    Field of View
    3.6 mm: Horizontal: 78°× Vertical: 58°× Diagonal: 102°
    Iris Type Fixed
    Close Focus Distance
    3.6 mm: 2.2 m (7.22 ft)
    DORI Distance Lens Detect Observe Recognize Identify
    3.6 mm 78.0 m (255.91 ft) 31.2 m ( 102.36 ft) 15.6 m (51.18 ft 7.8 m (25.59 ft)
    Professional, intelligent
    IVS (Perimeter Protection) Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
    SMD 3.0 Less false alarm, longer detection distance
    Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
    Video
    Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
    Smart Codec Smart H.265+; Smart H.264+
    AI Coding AI H.265; AI H.264
    Video Frame Rate Main stream: 2592 × 1944@(1 fps–20 fps)/2688 × 1520 @(1 fps–30 fps)
    Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps)
    Third stream: 1920 × 1080@(1 fps–30 fps)
    *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
    Stream Capability 3 streams
    Resolution 5M (2592 × 1944); 4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)
    Bit Rate Control CBR/VBR
    Video Bit Rate H.264: 3 kbps–20480 kbps
    H.265: 3 kbps–20480 kbps
    Day/Night Auto (ICR)/Color/B/W
    BLC Yes
    HLC Yes
    WDR 120 dB
    Scene Self-adaptation Yes
    White Balance Auto; natural; street lamp; outdoor; manual; regional custom
    Gain Control Auto; manual
    Noise Reduction 3D NR
    Motion Detection OFF/ON (4 areas)
    Region of Interest (RoI) Yes (4 areas)
    Smart Illumination Yes
    Defog Yes
    Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
    Mirror Yes
    Privacy Masking 8 areas
    Audio
    Built-in MIC Yes
    Audio Compression PCM; G.711a; G.711Mu; G.726; G.723
    Alarm
    Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception
    Network
    Network RJ-45 (10/100 Base-T)
    SDK and API Yes
    Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
    Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
    Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
    User/Host 20 (Total bandwidth: 72 M)
    Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS
    Browser IE: IE8/9/11
    Chrome
    Firefox
    Management Software Smart PSS; DSS; DMSS
    Mobile Phone iOS; Android
    Certification
    Certification CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14;
    Port
    Audio Input 1 channel (RCA port)
    Audio Output 1 channel (RCA port)
    Alarm Input 1 channel in: 5mA 3V–5 VDC
    Alarm Output 1 channel out: 300mA 12 VDC
    Power
    Power Supply 12 VDC/PoE (802.3af)
    Power Consumption Basic: 2.4 W (12 VDC); 3.1 W (PoE)
    Max. (H.265+main stream/IR intensity+warm light on): 7.9 W (12 VDC); 9.7 W (PoE)
    Environment
    Operating Conditions –40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH
    Storage Conditions –40 °C to +60 °C (–40 °F to +140 °F)
    Protection Grade IP67
    Structure
    Casing Metal + plastic
    Dimensions 288.4 mm × 94.4 mm × 84.7 mm
    (11.4" × 3.7" × 3.3") (L × W × H)
    Net Weight 1.0 kg (2.20 lb)
    Gross Weight 1.23 kg (2.71 lb)


    Product Details

    HFW3549TS336
    10 Items

    Quick Compare

    Product
    		 IP Camera HIKVISION DS-2CD2067G2H-LIU/SL(2.8mm)(eF) IP Camera Pinhole 2MP Hikvis. Hikvision Diskret IP DS-2CD2D25G1-D/NF(3.7mm) 2MP Black DS-2CD2186G2H-ISU(2.8mm)(BLACK) Camcorder
    Availability
    Price
    €226.88
    €227.18
    €227.18
    €227.23
    Description
    Type
    		 IP security camera IP security camera IP security camera
    Package type
    		 Box
    Width
    		 31.5 mm 31.5 mm
    Height
    		 31.5 mm 31.5 mm 97.6 mm
    Depth
    		 49.6 mm 39.7 mm
    Connectivity technology
    		 Wired Wired Wired
    Weight
    		 92 g 93 g 525 g
    Package depth
    		 104 mm 104 mm 120 mm
    Package height
    		 85 mm 85 mm 117 mm
    Package width
    		 130 mm 130 mm 234 mm
    Package weight
    		 202 g 202 g 750 g
    Power source type
    		 DC DC DC, PoE
    Storage relative humidity (H-H)
    		 0 - 95% 0 - 95% 0 - 95%
    Operating temperature (T-T)
    		 -30 - 60 °C -30 - 60 °C -30 - 60 °C
    Operating relative humidity (H-H)
    		 0 - 95% 0 - 95% 0 - 95%
    Storage temperature (T-T)
    		 -30 - 60 °C -30 - 60 °C -30 - 60 °C
    Mounting type
    		 Ceiling/wall
    Form factor
    		 Bullet
    Built-in microphone
    		 Yes
    Bluetooth
    		 No No No
    Bit rate
    		 32 Kbps - 16 Mbps
    Noise reduction
    		 Yes
    Protection features
    		 Water resistant
    Sensor type
    		 CMOS CMOS CMOS
    Wi-Fi
    		 No No No
    Compatible memory cards
    		 MicroSD (TransFlash)
    Maximum memory card size
    		 512 GB
    Audio formats supported
    		 AAC AAC G.722.1
    Signal-to-Noise Ratio (SNR)
    		 52 dB
    Power consumption (max)
    		 1.5 W 1.5 W 8 W
    Maximum resolution
    		 1920 x 1080 pixels 1920 x 1080 pixels 3840 x 2160 pixels
    Placement supported
    		 Indoor Indoor Outdoor
    Card reader integrated
    		 Yes
    Ethernet LAN (RJ-45) ports
    		 1 1 1
    Number of languages
    		 18 18 33
    Audio output channels
    		 1.0 channels 1.0 channels 1.0 channels
    DC-in jack
    		 Yes Yes
    Housing material
    		 Aluminium
    Networking standards
    		 IEEE 802.1x
    Security algorithms
    		 TLS
    Ethernet LAN
    		 Yes Yes Yes
    Supported graphics resolutions
    		 342 x 240 1920 x 1080 (HD 1080) 1280 x 720 (HD 720)
    Diameter
    		 12.2 cm
    International Protection (IP) code
    		 IP67
    Ethernet interface type
    		 Fast Ethernet Fast Ethernet Fast Ethernet
    Video formats supported
    		 H.265+
    Number of Users
    		 32 user(s) 32 user(s) 32 user(s)
    Web-based management
    		 Yes Yes Yes
    Quality of Service (QoS) support
    		 Yes Yes
    Reset button
    		 Yes Yes Yes
    Browser supported
    		 IE 10+, Chrome 57.0+, Firefox 52.0 IE 10+, Chrome 57.0+, Firefox 52.0 IE 10, IE 11, Chrome 57.0+, Firefox 52.0+
    Password protection
    		 Yes Yes Yes
    Languages support
    		 Czech Multi Multi
    Frame Rate
    		 30 fps
    Product colour
    		 Black Black Black
    Tilt angle range
    		 0 - 75°
    Focal length range
    		 2.8 mm
    Fixed focal length
    		 3.7 mm 2.8 mm
    LED type
    		 IR
    Night vision
    		 Yes Yes Yes
    Total megapixels
    		 2 MP 2 MP 8 MP
    Optical sensor size
    		 25.4 / 2.8 mm (1 / 2.8") 25.4 / 2.8 mm (1 / 2.8") 25.4 / 1.8 mm (1 / 1.8")
    Minimum illumination
    		 0.002 lx 0.002 lx 0 lx
    Pan range
    		 0 - 355°
    Dynamic range
    		 120 dB 130 dB
    Lens viewing angle, diagonal
    		 126.7° 87.3° 128.2°
    Video compression formats
    		 H.265+ H.264+ H.264
    Angle of rotation
    		 355°
    DC output current
    		 0.13 A 0.13 A 0.66 A
    DC output voltage
    		 12 12 12
    Video motion detection
    		 Yes Yes Yes
    Number of cameras
    		 1 1 1
    Night vision distance
    		 30 m
    Number of lenses
    		 1 1 1
    Privacy protection
    		 Yes
    Day/night mode
    		 Yes Yes Yes
    Infrared (IR) cut-off filter
    		 Yes
    Built-in HDD
    		 No No No
    Lens viewing angle, vertical
    		 57.9° 41.6° 54.8°
    Noise reduction technology
    		 3D noise reduction 3D noise reduction 3D noise reduction
    Region of Interest (ROI) encoding
    		 Yes Yes
    Maximum aperture number
    		 2 2.5 1
    Lens viewing angle, horizontal
    		 107.8° 75.5° 105.1°
    Number of sensors
    		 1
    Infra-red wavelength
    		 850 nm
    Wide Dynamic Range (WDR)
    		 Yes Yes Yes
    Progressive scan
    		 Yes
    Mirror
    		 Yes Yes Yes
    Heartbeat
    		 Yes Yes Yes
    Digital watermark
    		 Yes Yes Yes
    Back Light Compensation (BLC)
    		 Yes Yes Yes
    Video streaming
    		 Yes
    Active tampering alarm
    		 Yes
    Alarm input/output
    		 Yes
    Terminal block port
    		 Yes
    IP address filtering
    		 Yes Yes
    Intelligent Video Surveillance (IVS) system features
    		 Face detection
    Camera shutter speed
    		 1/3 - 1/100000 s 1/3 - 1/100000 s
    Bit rate control
    		 Constant Bit Rate (CBR)/Variable Bit Rate (VBR) Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
    Privacy masking
    		 Yes Yes Yes
    Highlight Compensation (HLC)
    		 Yes Yes Yes
    Live view
    		 Yes Yes Yes
    Power consumption (Power over Ethernet (PoE))
    		 9.5 W
    HTTPS encryption
    		 Yes
    Behavior analysis
    		 Intrusion detection, Line crossing detection
    Image quality adjustment
    		 Brightness Sharpness Contrast
    IK code
    		 IK10
    Lens mount interface
    		 M12 M12
    Digest authentication
    		 Yes
    Password reset via email
    		 Yes
    Iris
    		 Yes Yes
    Number of simultaneous live view channels
    		 15 channels 15 channels 6 channels
    User access level
    		 Administrator, Operator, User Administrator, Operator, User Administrator, Operator, User
    Identify distance (wide)
    		 4.3 m
    Recognize distance (wide)
    		 8.6 m
    Audio input channels
    		 1.0 channels 1.0 channels 1.0 channels
    Observe distance (wide)
    		 17 m
    Detect distance
    		 59.3 m 89 m
    Observe distance
    		 23.5 m 35 m
    Recognize distance
    		 11.9 m 17 m
    Identify distance
    		 5.9 m 8 m
    Detect distance (wide)
    		 42.8 m
    Pixel counter
    		 Yes
    Human and vehicle targets classification
    		 Yes
    Client interoperability
    		 iVMS-4200, Hik-Connect iVMS-4200, Hik-Connect, Hik-Central
    Bit rate range
    		 16 - 64 Kbit/s 16 - 192 Kbit/s 8 - 320 Kbit/s
    Alarm output channels
    		 1
    Alarm input channels
    		 1
    Compliance certificates
    		 RoHS RoHS Low Voltage Directive (LVD)
    Number of Privacy masking areas
    		 4
    Sample rates
    		 8 - 32 kHz 8 - 32 kHz 8 - 48 kHz
    Automatic Network Replenishment (ANR)
    		 Yes
    Network access storage (NAS)
    		 Yes
    Warnings
    		 Avoid direct contact with water to prevent electrical damage. Avoid direct contact with water to prevent electrical damage.
    Audit log
    		 Yes
    Flash log
    		 Yes
