• 1/1.9” 2Megapixel progressive scan CMOS
• H.265&H.264 triple-stream encoding
• 50/60fps@1080P(1920×1080)
• WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
• Auto back focus(ABF)
• Micro SD memory, PoE
• Support face capture, face attributes, face recognition
Technical Specifications:
Camera
• Image Sensor 1/1.9” 2Megapixel progressive scan CMOS
• Effective Pixels 1920(H)x1080(V)
• RAM/ROM 2048MB/4096MB
• Scanning System Progressive
• Electronic Shutter Speed Auto/Manual, 1/3~1/100000s
Minimum Illumination
• 0.001Lux/F1.2(Color,1/3s,30IRE), 0.01Lux/F1.2(Color,1/30s,30IRE), 0.0005Lux/F1.2(B/W,1/3s,30IRE), 0.005Lux/F1.2(B/W,1/30s,30IRE)
• S/N Ratio More than 50dB
• IR Distance N/A
• IR On/Off Control N/A
• IR LEDs N/A
Lens
• Lens Type N/A
• Mount Type C/CS
• Focal Length N/A
• Max. Aperture N/A
• Angle of View N/A
• Optical Zoom N/A
• Focus Control N/A
• Close Focus Distance N/A
Pan/Tilt/Rotation
• Pan/Tilt/Rotation Range N/A
Artificial Intelligence
• Face Capture Support face image capture
Face Attributes
• Support 6 kinds of face attributes extraction: Age, Gender, Expression(Jolly, Calm, Surprise, Sad, Rage), Glasses, Mouth Mask, Moustache
• Face Recognition Support face images matching, support up to 10000 face images and 5 image libraries management;
General Intelligence
• Event Trigger
• Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly
• General Intelligence Tripwire, Intrusion, Object Abandoned/Missing, People Counting, Heat Map
Video
• Compression H.265/H.264/H.264B/H.264H/MJPEG(Sub Stream)
• Smart Codec Support H.265+/H.264+
• Streaming Capability 3 Streams
• Resolution: 1080P(1920×1080)/ 1.3M(1280x960)/720P(1280x720)/ D1(704×576/704x480)/VGA(640x480)
Frame Rate
• Main Stream: 1080P(1~50/60fps), Sub Stream: D1 (1 ~ 50/60fps), Third Stream: 1080P(1~50/60fps)
• Bit Rate Control CBR/VBR, Bit Rate H.264: 24~ 10240Kbps, H.265: 14~ 6144Kbps
• Day/Night Auto(ICR) / Color / B/W
• BLC Mode BLC / HLC / WDR(120dB)/ SSA
• White Balance Auto/Natural/Street Lamp/Outdoor/Manual
• Gain Control Auto/Manual
• Noise Reduction 3D DNR
• Motion Detection Off / On (4 Zone, Rectangle)
• Region of Interest Off / On (4 Zone)
Electronic Image Stabilization
• (EIS) Support
• Smart IR N/A
• Defog Support
• Digital Zoom 16x
• Flip 0°/90°/180°/270°
• Mirror Off / On
• Privacy Masking Off / On (4 Area, Rectangle)
Audio
• Compression G.711a/ G.711Mu/ AAC/ G.726
Network
• Ethernet RJ-45 (100/1000Base-T)
• Protocol: HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP;FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;SNMP;TLS
• Interoperability ONVIF Profile S&G, API
• Streaming Method Unicast / Multicast
• Max. User Access 10 Users/20 Users
Edge Storage
• NAS
• Local PC for instant recording
• Mirco SD card 128GB
• Web Viewer IE, Chrome, Firefox, Safari
• Management Software Smart PSS, DSS, DMSS
• Smart Phone IOS, Android
Certifications
• CE (EN 60950:2000)
• UL:UL60950-1
• FCC: FCC Part 15 Subpart B
