IP Network Camera 8MP HDW5842TM-SE-S2
    DAHUA TECHNOLOGY CO., LTD

    IP Network Camera 8MP HDW5842TM-SE-S2

    €328.76
    Tax included
    Quantity

    Add to favorites Add to compare
    Camera
    Image Sensor 1/1.8” CMOS
    Max. Resolution 3840 (H) x 2160 (V)
    ROM 128 MB
    RAM 1 GB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    Min. Illumination 0.004 lux@F1.4 (Color, 30IRE) 0.0004 lux@F1.4 (B/W, 30IRE) 0 lux (Illuminator on)
    S/N Ratio > 56 dB
    Illumination Distance 2.8 mm: 30 m (98.4 ft)

    Illuminator On/Off Control Auto; manual
    Illuminator Number 2 (IR)
    Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360°
    Lens
    Lens Type Fixed-focal
    Lens Mount M16
    Focal Length 2.8 mm
    Max. Aperture F1.4
    Field of View 2.8 mm: Horizontal 111° ; Vertical 59° ;Diagonal 131°
    ;;
    ; ;
    Iris Control Fixed
    Close Focus Distance 2.8 mm: 1.8 m (5.9 ft)

    DORI Distance Lens Detect Observe Recognize Identify
    2.8 mm 85.4 m (280.2 ft) 34.2 m (112.2 ft) 17.1 m (56.1 ft) 8.5 m (27.9 ft)
    Smart Event
    IVS Abandoned object; missing object
    Heat Map Yes
    Professional, intelligent
    IVS (Perimeter Protection) Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection
    Face Detection Face detection; track; snapshot optimization; snapshot; face enhancement; face exposure; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimized snapshot, quality priority snapshot; face angle filter; optimization time setting
    People Counting Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports. Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm. Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm.
    Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
    Audio
    Built-in MIC Yes
    Audio Compression PCM; G.711a; G.711Mu; G.726; G.723
    Video
    Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
    Smart Codec Smart H.265+/H.264+
    Video Frame Rate Main stream: 3840x 2160 (1 fps–25/30 fps)
    Sub stream: D1 (1 fps–25/30 fps)
    Third stream: 1080p (1 fps–25/30 fps)     *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
    Stream Capability 3 streams
    Resolution 3840 x 2160; 3072 x 2048; 3072 x 1728; 2592 x 1944; 2688 x 1520; 2048 x 1536; 2304 x 1296; 1080p (1920 x 1080); 1.3 M (1280 x 960); 720p (1280 x 720); D1 (704 x 576/704 x 480); VGA (640 x 480); CIF (352 x 288/352 x 240)
    Bit Rate Control CBR/VBR
    Video Bit Rate H.264: 3 kbps–20480 kbps H.265: 3 kbps–20480 kbps
    Day/Night Auto (ICR)/Color/B/W
    BLC Yes
    HLC Yes
    WDR 120 dB
    White Balance Auto; natural; street lamp; outdoor; manual; regional custom
    Gain Control Auto; manual
    Noise Reduction 3D NR
    Motion Detection OFF/ON (4 areas, rectangular)
    Region of Interest (RoI) Yes (4 areas)
    Defog Yes
    Image Rotation 0°/90°/180°/270°(Support 90°/270° with 4M resolution and lower)
    Mirror Yes
    Privacy Masking 8 areas
    Alarm
    Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; scene changing; intrusion; tripwire; abandoned object; missing object; fast moving; parking detection; loitering detection; people gathering; input abnormal detection; intensity change detection; people counting; face detection; people counting in area; stay alarm; people No. exception detection; queue management
    Network
    Network Port RJ-45 (10/100 Base-T)
    SDK and API Yes
    Cyber Security Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of x.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
    Network Protocol IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP
    Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P
    User/Host 20 (Total bandwidth: 80 M)
    Storage FTP; SFTP; Micro SD card (Support max. 256 G); NAS
    Browser IE: IE8 and later Chrome Firefox
    Management Software Smart PSS; DSS; DMSS
    Mobile Client iOS; Android
    Certification
    Certifications CE-LVD: EN62368-1
    CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
    FCC: 47 CFR FCC Part 15, Subpart B
    UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
    Power
    Power Supply 12 VDC (±30%)/PoE (802.3af)/ePoE
    Power Consumption Basic power consumption: 3.7 W (12 VDC); 4.6 W (PoE) Max. power consumption (H.265 + max. stream + intelligent function + IR LED): 6.7 W (12 VDC); 7.8W (PoE)
    Environment
    Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH
    Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
    Protection IP67
    Structure
    Casing Metal
    Product Dimensions 104.4 mm x ?121.9 mm (4.11" x ?4.80")
    Net Weight 500 g (1.1 lb)
    Gross Weight 680 g (1.5 lb)


    Product Details

    HDW5842TMSE
    15 Items

    Quick Compare

    Product
    		 IP camera Hikvision DS-2CD2H86G2-IZS(2.8-12mm)(C) Reolink TRACKMIX-LTE-W security camera Dome IP security camera Outdoor 2560 x 1440 pixels Ceiling IP network camera 8MP HFW3841T-ZAS IP network camera 8MP HFW3841T-ZAS IP KAMERA DAHUA IPC-HFW5849T1-ASE-LED-0360B
    Availability
    Price
    €319.74
    €323.95
    €327.03
    €327.60
    Description
    Mac operating systems supported
    		 Yes
    Type
    		 IP security camera IP security camera IP security camera
    Windows operating systems supported
    		 Yes
    Width
    		 228.2 mm 94.4 mm
    Height
    		 129 mm
    Depth
    		 147 mm 84.7 mm
    Connectivity technology
    		 Wired Wireless Wired
    Weight
    		 1.16 kg 1.4 kg 1.12 kg
    Package depth
    		 170 mm
    Package height
    		 205 mm
    Package width
    		 170 mm
    Package weight
    		 1.53 kg
    Power source type
    		 DC, PoE DC DC, PoE
    Storage relative humidity (H-H)
    		 0 - 95% 0 - 95%
    Operating temperature (T-T)
    		 -30 - 60 °C -10 - 55 °C -40 - 60 °C
    Operating relative humidity (H-H)
    		 0 - 95% 20 - 85% 0 - 95%
    Storage temperature (T-T)
    		 -30 - 60 °C -40 - 60 °C
    Mounting type
    		 Ceiling/wall Ceiling Ceiling/wall
    Form factor
    		 Turret Dome Bullet
    Built-in microphone
    		 Yes Yes
    Bluetooth
    		 No No
    Bit rate
    		 32 Kbps - 16 Mbps 3 Kbps - 20480 Kbps
    Noise reduction
    		 Yes Yes
    Protection features
    		 Water resistant
    Length
    		 14.6 cm 288.4 mm
    Sensor type
    		 CMOS CMOS CMOS
    Wi-Fi
    		 No No
    Internal memory
    		 1024 MB
    Compatible memory cards
    		 microSDHC MicroSD (TransFlash)
    Maximum memory card size
    		 256 GB 256 GB
    Signal-to-Noise Ratio (SNR)
    		 52 dB
    Power consumption (max)
    		 12.1 W
    Power consumption (typical)
    		 5.3 W
    Maximum resolution
    		 3840 x 2160 pixels 2560 x 1440 pixels 3840 x 2160 pixels
    Built-in speaker(s)
    		 Yes
    Placement supported
    		 Indoor & outdoor Outdoor External / Internal
    Card reader integrated
    		 Yes Yes
    Ethernet LAN (RJ-45) ports
    		 1 1
    Number of languages
    		 33
    Audio output channels
    		 1 channels 1 channels
    DC-in jack
    		 Yes
    Housing material
    		 Metal
    Networking standards
    		 IEEE 802.3af IEEE 802.3af
    Security algorithms
    		 TLS
    Ethernet LAN
    		 Yes Yes
    Supported graphics resolutions
    		 640 x 480 (VGA) 704 x 576
    Zoom capability
    		 Yes
    Diameter
    		 13.6 cm
    International Protection (IP) code
    		 IP66 IP65 IP67
    Ethernet interface type
    		 Fast Ethernet Fast Ethernet
    Colour Temperature
    		 6500 K
    Number of Users
    		 32 user(s) 20 user(s) 20 user(s)
    Web-based management
    		 Yes
    Quality of Service (QoS) support
    		 Yes Yes
    Password protection
    		 Yes
    Languages support
    		 Multi
    Luminous flux
    		 450 lm
    Frame Rate
    		 30 fps 15 fps 30 fps
    Product colour
    		 White White White
    Tilt angle range
    		 0 - 75° 0 - 90° -20 - 90°
    Focal length range
    		 2.8 - 12 mm
    Fixed focal length
    		 3.6 mm
    Web browser
    		 Yes
    Mobile network generation
    		 4G
    Voice codecs
    		 G.726 G.723
    LED type
    		 IR IR
    Night vision
    		 Yes Yes Yes
    Total megapixels
    		 8 MP 4 MP 8 MP
    SIM card slot
    		 Yes
    Optical sensor size
    		 25.4 / 1.8 mm (1 / 1.8") 25.4 / 3 mm (1 / 3") 25.4 / 1.2 mm (1 / 1.2")
    White balance
    		 Manual
    Minimum illumination
    		 0.0005 lx
    Pan range
    		 0 - 355° 0 - 355° 0 - 360°
    Lens viewing angle, diagonal
    		 106°
    Video compression formats
    		 H.265+ M-JPEG
    Angle of rotation
    		 360° 360°
    DC output current
    		 2 A
    DC output voltage
    		 12 5 12
    Video motion detection
    		 Yes Yes
    Number of cameras
    		 1 1 1
    Camera pan control
    		 Yes Yes
    Camera tilt control
    		 Yes Yes
    Night vision distance
    		 40 m 30 m 60 m
    Number of lenses
    		 1 1
    Day/night mode
    		 Yes Yes Yes
    Infrared (IR) cut-off filter
    		 Yes
    Built-in HDD
    		 No No No
    Lens viewing angle, vertical
    		 58° 50°
    Noise reduction technology
    		 3D noise reduction 3D noise reduction
    Region of Interest (ROI) encoding
    		 Yes Yes
    Maximum aperture number
    		 1.4 1
    Lens viewing angle, horizontal
    		 108° 91°
    Number of sensors
    		 1 1
    Infra-red wavelength
    		 850 nm
    Alert notification type
    		 E-mail
    Wide Dynamic Range (WDR)
    		 Yes Yes
    Progressive scan
    		 Yes Yes
    Mirror
    		 Yes Yes
    Heartbeat
    		 Yes
    Anti-flicker
    		 Yes
    Back Light Compensation (BLC)
    		 Yes Yes
    Video streaming
    		 Yes Yes
    Active tampering alarm
    		 Yes
    Alarm input/output
    		 Yes Yes
    IP address filtering
    		 Yes
    Intelligent Video Surveillance (IVS) system features
    		 Face detection Tripwire
    ROM capacity
    		 128 MB
    Camera shutter speed
    		 1/3 - 1/100000 s 1/3 - 1/100000 s
    Bit rate control
    		 Constant Bit Rate (CBR)/Variable Bit Rate (VBR) Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
    Gain control type
    		 Auto Auto/Manual
    Privacy masking
    		 Yes Yes
    Highlight Compensation (HLC)
    		 Yes Yes
    Power consumption (Power over Ethernet (PoE))
    		 12.5 W 6.2 W
    HTTPS encryption
    		 Yes
    Behavior analysis
    		 Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
    Image quality adjustment
    		 Contrast
    IK code
    		 IK10
    Built-in loudspeaker
    		 Yes
    Audio input channels
    		 1 channels 1 channels
    Observe distance (wide)
    		 34.1 m
    Closest focusing distance
    		 5.4 m
    Detect distance
    		 120.4 m
    Observe distance
    		 48.2 m
    Recognize distance
    		 24.1 m
    Identify distance
    		 12 m
    Audio RCA outputs
    		 1
    RCA input
    		 1
