IP network camera 8MP HDBW3841R-ZS
    DAHUA TECHNOLOGY CO., LTD

    IP network camera 8MP HDBW3841R-ZS

    €330.49
    Tax included
    Quantity

    Add to favorites Add to compare
    Camera
    Image Sensor 1/2.8”8Megapixel progressive CMOS
    Max. Resolution 3840 (H) × 2160 (V)
    ROM 128 MB
    RAM 512 MB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    Min. Illumination 0.007 Lux@F1.5 (Color, 30IRE) 0.0007 Lux@F1.5 (B/W, 30IRE) 0 Lux (Illuminator on)
    S/N Ratio > 56 dB
    Illumination Distance 40 m (131.2 ft)
    Illuminator On/Off Control Auto/Manual
    Illuminator Number 2 (IR LED)
    Pan/Tilt/Rotation Range Pan: 0°–355°
    Tilt: 0°–75°
    Rotation: 0°–355°
    Lens
    Lens Type Motorized vari-focal
    Mount Type ?14
    Focal Length 2.7 mm–13.5 mm
    Max. Aperture F1.5
    Field of View Horizontal: 113°–31°
    Vertical: 58°–17°
    Diagonal: 138°–36°
    Iris Type Fixed
    Close Focus Distance 0.8 m (2.6 ft)
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    DORI Distance Lens Detect Observe Recognize Identify
    W 85.3 m (279.9 ft) 34.1 m (111.9 ft) 17.0 m (55.8 ft) 8.5 m (27.9 ft)
    T 280.0 m (918.6 ft) 112.0 m (367.5 ft) 56.0 m (183.7 ft) 28.0 m (91.9 ft)
    Professional, intelligent
    Perimeter Protection Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
    Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
    Video
    Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
    Smart Codec Smart H.265+/ Smart H.264+
    Video Frame Rate Main stream: 3840 × 2160 @(1–20 fps by default) 3840 × 2160 @(1–25/30 fps when AI function disabled) sub stream: 704 × 576 @(1–25 fps)/704 × 480 @ (1–30 fps) third stream: 1920 × 1080 @(1–25/30 fps)
    Stream Capability 3 streams
    Resolution 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
    Bit Rate Control CBR/VBR
    Video Bit Rate H.264: 3 kbps–8192 kbps
    H.265: 3 kbps–8192 kbps
    Day/Night Auto (ICR)/Color/B/W
    BLC Yes
    HLC Yes
    WDR 120 dB
    Scene Self-adaptation (SSA) Yes
    White Balance Auto/natural/street lamp/outdoor/manual/regional custom
    Gain Control Auto/Manual
    Noise Reduction 3D DNR
    Motion Detection OFF/ON (4 areas, rectangular)
    Region of Interest (RoI) Yes (4 areas)
    Smart Illumination Yes
    Image Rotation 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.)
    Mirror Yes
    Privacy Masking 4 areas
    Audio
    Audio Compression G.711a; G.711Mu; G726
    Alarm
    Alarm Event - ZAS:
    No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; safety exception
    -ZS:
    No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; voltage detection; defocus detection; SMD; safety exception
    Network
    Network RJ-45 (10/100 Base-T)
    SDK and API Yes
    Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
    Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
    Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
    User/Host 20 (Total bandwidth: 72 M)
    Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS
    Browser IE: IE8; IE9; IE11
    Chrome
    Firefox
    Management Software Smart PSS; DSS; DMSS
    Mobile Phone IOS; Android
    Certification
    Certifications CE-LVD: EN62368-1
    CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
    FCC: 47 CFR FCC Part 15, Subpart B
    UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
    Port
    Audio Input 1 channel (RCA port) (Only - ZAS supports)
    Audio Output 1 channel (RCA port) (Only - ZAS supports)
    Alarm Input 1 channel in: 5mA 3V–5V DC (Only - ZAS supports)
    Alarm Output 1 channel out: 300mA 12V DC (Only - ZAS supports)
    Power
    Power Supply 12V DC/PoE (802.3af)
    Power Consumption Basic power consumption: 2.7W (12V DC); 3.3W (PoE) Max. power consumption (WDR + H.265 + IR LED intensity): 6.8W (12V DC); 8.2W (PoE)
    Environment
    Operating Conditions –30°C to +60°C (–22°F to +140°F)/Less than 95% RH
    Storage Conditions –40°C to +60°C (–40°F to +140°F)
    Protection Grade IP67; IK10
    Structure
    Casing Metal
    Dimensions 88.9 mm × ?122 mm (3.5" × ?4.8")
    Net Weight 492 g (1.1 lb)
    Gross Weight 663 g (1.5 lb)

    Product Details

    HDBW3841R-ZS
    7 Items

    Quick Compare

    Product
    		 KAMERA IP HIKVISION DS-2CD2766G2-IZS (2.8-12mm) (C) (BLACK) TP-Link TPLINK IP Camera InSight S385PI HIKVISION IP CAMERA DS-2CD2783G2-LIZS2U(2.8-12mm) IP camera Dahua IPC-HFW3849T-ZAS-IL-27135-BLACK
    Availability
    Price
    €318.82
    €319.85
    €320.04
    €320.54
    Description
    Type
    		 IP security camera IP security camera IP security camera
    Width
    		 100 mm
    Height
    		 101 mm 97.6 mm
    Connectivity technology
    		 Wired Wired Wired
    Weight
    		 1.11 kg 1.01 kg 620 g
    Package depth
    		 174 mm 150 mm
    Package height
    		 173 mm 141 mm
    Package width
    		 244 mm 150 mm
    Package weight
    		 1.73 kg 880 g
    Power source type
    		 DC, PoE DC, PoE DC, PoE
    Storage relative humidity (H-H)
    		 0 - 95% 0 - 95% 0 - 95%
    Manual
    		 Yes
    Operating temperature (T-T)
    		 -30 - 60 °C -30 - 60 °C -30 - 60 °C
    Operating relative humidity (H-H)
    		 0 - 95% 0 - 95% 0 - 95%
    Storage temperature (T-T)
    		 -30 - 60 °C -40 - 60 °C -30 - 60 °C
    Mounting type
    		 Ceiling/wall Wall Ceiling/wall
    Form factor
    		 Dome Bullet Dome
    Built-in microphone
    		 Yes Yes
    Bluetooth
    		 No No No
    Sample rate
    		 8 kHz
    Bit rate
    		 32 Kbps - 16 Mbps Main Stream: 256 Kbps to 8 Mbps, Sub-Stream: 64 Kbps to 1024 Kbps 32 Kbps - 8 Mbps
    Noise reduction
    		 Yes Yes
    Protection features
    		 Water resistant Waterproof Waterproof
    Length
    		 266 mm
    Sensor type
    		 CMOS CMOS CMOS
    Wi-Fi
    		 No No No
    Compatible memory cards
    		 MicroSD (TransFlash) MicroSD (TransFlash) MicroSD (TransFlash)
    Maximum memory card size
    		 256 GB 512 GB 512 GB
    Audio system
    		 2-way
    SIM card type
    		 MicroSIM
    Audio formats supported
    		 G.711 A-law AAC
    Signal-to-Noise Ratio (SNR)
    		 52 dB 52 dB
    Maximum operating distance
    		 44 m
    Power consumption (max)
    		 10.5 W 18 W 10.56 W
    Maximum resolution
    		 3840 x 2160 pixels 3840 x 2160 pixels
    Built-in speaker(s)
    		 Yes
    Placement supported
    		 Indoor & outdoor Outdoor Outdoor
    Card reader integrated
    		 Yes Yes
    Ethernet LAN (RJ-45) ports
    		 1 1 1
    Number of languages
    		 33 33
    Audio output channels
    		 1 channels 1.0 channels 1.0 channels
    DC-in jack
    		 Yes
    Housing material
    		 Metal Metal
    Networking standards
    		 IEEE 802.3af IEEE 802.3at IEEE 802.1x
    Security algorithms
    		 TLS
    Ethernet LAN
    		 Yes Yes Yes
    Supported graphics resolutions
    		 640 x 360 1920 x 1080 (HD 1080) 640 x 480 (VGA)
    Diameter
    		 12.2 cm
    International Protection (IP) code
    		 IP66 IP67 IP67
    Ethernet interface type
    		 Fast Ethernet Fast Ethernet
    Video formats supported
    		 M-JPEG
    Number of Users
    		 32 user(s) 32 user(s)
    Web-based management
    		 Yes Yes
    Quality of Service (QoS) support
    		 Yes Yes
    Supported network protocols
    		 TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
    Reset button
    		 Yes Yes Yes
    Password protection
    		 Yes Yes Yes
    Languages support
    		 Multi Multi
    Frame Rate
    		 30 fps 30 fps
    Mounting kit
    		 Yes
    Product colour
    		 Black White White
    Tilt angle range
    		 0 - 75° 0 - 90° 0 - 90°
    Focal length range
    		 2.8 - 12 mm 2.8-12 mm
    Fixed focal length
    		 1.65 mm
    Web browser
    		 Yes Yes Yes
    Number of microphones
    		 1
    Video recording
    		 Yes Yes
    Voice codecs
    		 AAC G.722.1
    Screws included
    		 Yes
    LED type
    		 IR IR/White IR/White
    Night vision
    		 Yes Yes Yes
    Total megapixels
    		 6 MP 8 MP 4 MP
    SIM card slot
    		 Yes
    Motion sensor
    		 Yes
    Fixed focus
    		 Yes
    Optical sensor size
    		 25.4 / 2.4 mm (1 / 2.4") 25.4 / 2.7 mm (1 / 2.7") 25.4 / 2.8 mm (1 / 2.8")
    Minimum illumination
    		 0 lx 0 lx
    Pan range
    		 0 - 355° 0 - 355°
    Dynamic range
    		 120 dB
    Lens viewing angle, diagonal
    		 117° 180° 128.5 - 34.7°
    Video compression formats
    		 H.264+ H.265 M-JPEG
    Angle of rotation
    		 355° 355°
    DC output current
    		 0.88 A
    DC output voltage
    		 12 12 12
    Video motion detection
    		 Yes Yes Yes
    Number of cameras
    		 1 1 1
    Camera pan control
    		 Yes
    Camera tilt control
    		 Yes
    Night vision distance
    		 40 m 40 m
    Number of lenses
    		 1 1
    Detection distance
    		 120 m
    Privacy protection
    		 Yes
    Day/night mode
    		 Yes Yes Yes
    Infrared (IR) cut-off filter
    		 Yes Yes Yes
    Remote viewing
    		 Yes
    Built-in HDD
    		 No No
    Lens viewing angle, vertical
    		 53° 86° 55.7 - 17°
    Noise reduction technology
    		 3D noise reduction 3D noise reduction
    Digital Wide Dynamic Range (DWDR)
    		 Yes
    Region of Interest (ROI) encoding
    		 Yes Yes
    Maximum aperture number
    		 1.4 2 1.6
    Lens viewing angle, horizontal
    		 99° 180° 106.5 - 30.2°
    Number of sensors
    		 1 1
    Infra-red wavelength
    		 850 nm 850 nm
    Built-in siren
    		 Yes
    Alert notification type
    		 E-mail Push notification
    Wide Dynamic Range (WDR)
    		 Yes Yes Yes
    Progressive scan
    		 Yes Yes Yes
    Mirror
    		 Yes Yes Yes
    Heartbeat
    		 Yes Yes
    Anti-flicker
    		 Yes
    Back Light Compensation (BLC)
    		 Yes Yes Yes
    Video streaming
    		 Yes Yes
    Weatherproof
    		 Yes
    Active tampering alarm
    		 Yes Yes
    Alarm input/output
    		 Yes Yes
    IP address filtering
    		 Yes Yes Yes
    Intelligent Video Surveillance (IVS) system features
    		 Scene change Face detection
    Camera shutter speed
    		 1/3 - 1/100000 s 1/3 to 1/10000 1/3 - 1/100000 s
    Bit rate control
    		 Constant Bit Rate (CBR)/Variable Bit Rate (VBR) Constant Bit Rate (CBR)/Variable Bit Rate (VBR) Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
    Gain control type
    		 Auto
    Privacy masking
    		 Yes
    Highlight Compensation (HLC)
    		 Yes Yes Yes
    Live view
    		 Yes Yes
    Cloud-managed
    		 Yes
    Power consumption (Power over Ethernet (PoE))
    		 12.5 W 21 W 12.5 W
    HTTPS encryption
    		 Yes Yes Yes
    Behavior analysis
    		 Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection Intrusion detection, Line crossing detection
    Image quality adjustment
    		 Saturation Saturation Sharpness
    IK code
    		 IK10 IK10
    Digest authentication
    		 Yes Yes
    Password reset via email
    		 Yes
    Number of simultaneous live view channels
    		 6 channels
    User access level
    		 Administrator, Operator, User
    Identify distance (wide)
    		 8 m 8.8 m
    Recognize distance (wide)
    		 16 m 17.7 m
    Audio input channels
    		 1 channels 1.0 channels 1.0 channels
    Observe distance (wide)
    		 35 m
    Detect distance
    		 44 m
    Observe distance
    		 18.33 m
    Recognize distance
    		 8.8 m
    Identify distance
    		 4.4 m
    Detect distance (wide)
    		 80 m 88.3 m
    Identify distance (tele)
    		 29 m
    Pixel counter
    		 Yes
    Human and vehicle targets classification
    		 Yes
    Drilling template included
    		 Yes
    Recognize distance (tele)
    		 57.9 m
    Detect distance (tele)
    		 289.7 m
    Observe distance (tele)
    		 83 m 114.9 m
    Bit rate range
    		 0 - 64 Kbit/s 8 - 320 Kbit/s
    Alarm output channels
    		 1
    Alarm input channels
    		 1
    Compliance certificates
    		 CB
    Number of Privacy masking areas
    		 8
    Sample rates
    		 8 - 48 kHz
    Automatic Network Replenishment (ANR)
    		 Yes
    Network access storage (NAS)
    		 Yes
    Warnings
    		 The product contains electronic components; do not dispose of with the normal household waste.
    Sensor type (panoramic camera)
    		 CMOS
    Audit log
    		 Yes
    Flash log
    		 Yes
