![4K IP Network Camera 8MP HDW3849H-ZAS-PV 2.7-13.5 4K IP Network Camera 8MP HDW3849H-ZAS-PV 2.7-13.5](https://ecomp.lt/2888251-large_default/4k-ip-network-camera-8mp-hdw3849h-zas-pv-27-135.jpg)
Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | 1/2.8" CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Resolution | 3840 (H) × 2160 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM | 128 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM | 512 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination | 0.003 lux@F1.0 (Color, 30 IRE) 0.0003 lux@F1.0 (B/W, 30 IRE) 0 lux (illuminator on) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
S/N Ratio | ? 56 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illumination Distance | Up to 50 m (164.04 ft) (IR) Up to 40 m (131.23 ft) (warm light) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator On/Off Control | Auto; manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator Number | 2 (IR LED) 2 (warm light) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Angle Adjustment | Pan: 0°–360° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type | Motorized vari-focal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mount Type | ?16 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length | 2.7 mm–13.5 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View | H: 108°–34° V: 56°–19° D: 130°–39° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Type | Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance | 1.5 m (4.92 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance | Lens | Detect | Observe | Recognize | Identify | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
W | 89.9 m (294.95 ft) | 36.0 m (118.11 ft) | 18.0 m (59.06 ft) | 9.0 m (29.53 ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
T | 257.4 m (844.49 ft) | 103.0 m (337.93 ft) | 51.5 m (168.96 ft) | 25.7 m (84.32 ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligent | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS (Perimeter Protection) | Tripwire; intrusion (Support the classification and accurate detection of vehicle and human) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SMD 4.0 | Less false alarm, longer detection distance | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Quick Pick | With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI SSA | Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec | Smart H.265+; Smart H.264+ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI Coding | AI H.265; AI H.264 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Frame Rate | Main stream: 3840 × 2160@(1 fps–30 fps) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Stream Capability | 3 streams | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520/2560 × 1440); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control | CBR/VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate | H.264: 32 kbps–16384 kbps H.265: 32 kbps–16384 kbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night | Auto (ICR)/Color/B/W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR | 120 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scene Self-adaptation | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control | Auto; manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction | 3D NR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection | OFF/ON (4 areas) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest (RoI) | Yes (4 areas) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Stabilization | Electronic Image Stabilization (EIS) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Illumination | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Defog | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirror | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking | 4 areas | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Built-in MIC | Yes, built-in dual Mic | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Built-in speaker | Yes, built-in speaker | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; security exception | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | RJ-45 (10/100 Base-T) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SDK and API | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User/Host | 20 (Total bandwidth: 72 M) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage | FTP; SFTP; Micro SD card (Support max. 256 G); NAS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser | IE: IE8/9/11 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software | SmartPSS Lite; DSS; DMSS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Phone | iOS; Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification | CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input | 1 channel (RCA port) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output | 1 channel (RCA port) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input | 1 channel in: wet contact, 5 mA 3 V–5 VDC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output | 1 channel out: wet contact, 300 mA 12 VDC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 12 VDC/PoE (802.3af) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | Basic: 4.8 W (12 VDC); 6 W (PoE) Max. (pulling stream+warning light+speaker+warm light on): 8.5 W (DC12 V) 11.6 W (POE) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | ?95% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Humidity | ?95% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection Grade | IP67 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing | Metal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions | 127.6 mm × ?122.0 mm (5.02" × ?4.80") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 885 g (2.0 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 1060 g (2.3 lb) |
Quick Compare
Product |
![]() |
![]() |
![]() |
Availability |
|
|
|
Price |
€430.14
|
€437.77
|
€439.36
|
Description |
|||
Type |
IP security camera | IP security camera | |
Width |
110 mm | ||
Height |
62 mm | ||
Depth |
110 mm | ||
Connectivity technology |
Wired | Wired | |
Weight |
485 g | 387 g | |
Package depth |
121 mm | ||
Package height |
118 mm | ||
Package width |
216 mm | ||
Package weight |
749 g | 502 g | |
Power source type |
DC, PoE | PoE | |
Storage relative humidity (H-H) |
0 - 95% | ||
Manual |
Yes | ||
Operating temperature (T-T) |
-30 - 60 °C | -30 - 55 °C | |
Operating relative humidity (H-H) |
0 - 95% | ||
Storage temperature (T-T) |
-30 - 60 °C | -40 - 60 °C | |
Mounting type |
Ceiling/wall | Ceiling/wall | |
Form factor |
Bullet | Dome | |
Built-in microphone |
Yes | ||
Bluetooth |
No | No | |
Sample rate |
48 kHz | ||
Bit rate |
32 Kbps - 16 Mbps | ||
Noise reduction |
Yes | Yes | |
Length |
16.2 cm | ||
Sensor type |
CMOS | CMOS | |
Wi-Fi |
No | No | |
Internal memory |
512 MB | ||
Compatible memory cards |
MicroSD (TransFlash) | ||
Maximum memory card size |
256 GB | ||
Audio formats supported |
MP3 | ||
Signal-to-Noise Ratio (SNR) |
56 dB | ||
Power consumption (max) |
6 W | ||
Maximum resolution |
3840 x 2160 pixels | 2592 x 1944 pixels | |
Placement supported |
Outdoor | Indoor & outdoor | |
Card reader integrated |
Yes | ||
Ethernet LAN (RJ-45) ports |
1 | 1 | |
Number of languages |
33 | ||
Audio output channels |
1 channels | ||
Housing material |
Metal | ||
Networking standards |
IEEE 802.1x | ||
Ethernet LAN |
Yes | Yes | |
Supported graphics resolutions |
640 x 480 (VGA) | 1600 x 1200 | |
Diameter |
7 cm | ||
International Protection (IP) code |
IP67 | IP67 | |
Ethernet interface type |
Fast Ethernet | ||
Number of Users |
32 user(s) | ||
Web-based management |
Yes | ||
Quality of Service (QoS) support |
Yes | ||
Reset button |
Yes | ||
Password protection |
Yes | ||
Languages support |
Estonian | ||
Frame Rate |
30 fps | 30 fps | |
Product colour |
White | White | |
Tilt angle range |
0 - 90° | 0 - 55° | |
Sustainability certificates |
CE | ||
Fixed focal length |
2.8 mm | 1.4 mm | |
Voice codecs |
MP2L2 | ||
LED type |
IR | ||
Night vision |
Yes | ||
Total megapixels |
8 MP | 5 MP | |
Optical sensor size |
25.4 / 1.8 mm (1 / 1.8") | 25.4 / 2.7 mm (1 / 2.7") | |
Field of view (FOV) angle |
180° | ||
Minimum illumination |
0.006 lx | ||
Pan range |
0 - 360° | 0 - 355° | |
Lens viewing angle, diagonal |
131° | ||
Video compression formats |
H.264 | H.264+ | |
Angle of rotation |
360° | 360° | |
DC output current |
0.5 A | ||
DC output voltage |
12 | 12 | |
Video motion detection |
Yes | ||
Number of cameras |
1 | 1 | |
Camera pan control |
Yes | Yes | |
Camera tilt control |
Yes | Yes | |
Night vision distance |
40 m | ||
Number of lenses |
1 | 1 | |
Day/night mode |
Yes | ||
Infrared (IR) cut-off filter |
Yes | ||
Built-in HDD |
No | No | |
Lens viewing angle, vertical |
59° | ||
Noise reduction technology |
3D noise reduction | 3D noise reduction | |
Region of Interest (ROI) encoding |
Yes | ||
Maximum aperture number |
1.6 | 2 | |
Number of sensors |
1 | 1 | |
Infra-red wavelength |
850 nm | ||
Wide Dynamic Range (WDR) |
Yes | ||
Progressive scan |
Yes | Yes | |
Mirror |
Yes | ||
Heartbeat |
Yes | ||
Anti-flicker |
Yes | ||
Back Light Compensation (BLC) |
Yes | Yes | |
Video streaming |
Yes | ||
IP address filtering |
Yes | ||
Intelligent Video Surveillance (IVS) system features |
Scene change | ||
ROM capacity |
128 MB | ||
Camera shutter speed |
1/3 - 1/100000 s | 1/100,000 s | |
Privacy masking |
Yes | Yes | |
Highlight Compensation (HLC) |
Yes | Yes | |
Power consumption (Power over Ethernet (PoE)) |
7.2 W | ||
HTTPS encryption |
Yes | ||
Behavior analysis |
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection | ||
Image quality adjustment |
Saturation | ||
IK code |
IK10 | ||
Audio input channels |
1 channels | ||
Closest focusing distance |
0.2 m | ||
Detect distance |
28 m | ||
Observe distance |
11.2 m | ||
Recognize distance |
5.6 m | ||
Identify distance |
2.8 m | ||
Alarm output channels |
1 | ||
Alarm input channels |
1 | ||
