IP PTZ kam. 4MP SD50432GB-HNR
    DAHUA TECHNOLOGY CO., LTD

    IP PTZ kam. 4MP SD50432GB-HNR

    €1,114.72
    Tax included
    Quantity

    Camera

    Image Sensor

    1/2.8" CMOS

    Pixel

    4 MP

    Max. Resolution

    2560 (H) × 1440 (V)

    ROM

    4 GB

    RAM

    1 GB

    Electronic Shutter Speed

    1/1 s–1/30,000 s

    Scanning System

    Progressive

    Min. Illumination

    Color: 0.005 lux@F1.6
    B/W: 0.0005 lux@F1.6

    Lens

    Focal Length

    4.8 mm–154 mm

    Max. Aperture

    F1.6–F4.0

    Field of View

    H: 55.8°–2.3°
    V: 31.9°–1.3°
    D: 63.7°–2.7°

    Optical Zoom

    32×

    Focus Control

    Auto; semi-auto; manual

    Close Focus Distance

    0.1 m–1.5 m

    Iris Control

    Auto; manual

    DORI Distance

    Detect

    Observe

    Recognize

    Identify

    3,080 m (10,104.99 ft)

    1216.6 m (3,991.47 ft)

    616 m (2,021.00 ft)

    308 m (1,010.50 ft)

    PTZ

    Pan/Tilt Range

    Tilt: 0° to +90°, auto flip 180

    Pan: 0° to 360° endless

    Manual Control Speed

    Pan: 0.1°/s–350°/s; Tilt: 0.1°/s–250°/s

    Preset Speed

    Pan: 500°/s; Tilt: 500°/s

    Preset

    300

    Tour

    8 (up to 32 presets per tour)

    Pattern

    5

    Scan

    5

    Power-off Memory

    Yes

    Idle Motion

    Pattern; Preset; Scan; Tour

    PTZ Protocol

    DH-SD

    Intelligence

    IVS (Perimeter Protection)

    Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking

    Face Detection

    Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions: Gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing, optimization, and quality first.

    Auto Tracking

    Yes

    SMD

    Yes

    Quick Pick

    With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events.

    Video

    Video Compression

    H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream1); Smart H.264+

    Streaming Capability

    3 streams

    Resolution

    4M (2560 × 1440); 3M (2048 × 1536); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

    Video Frame Rate

    Main stream: 4M/3M/1080p/1.3M/720p (1–25/30 fps)
    Sub stream 1: D1/VGA/CIF (1–25/30 fps)
    Sub stream 2: 1080p/1.3M/720p (1–25/30 fps)

    Bit Rate Control

    CBR/VBR

    Video Bit Rate

    H264: 96–14848 Kbps
    H265: 38–8960 Kbps

    Day/Night

    Auto (ICR)/Color/B/W

    BLC

    Yes

    WDR

    120 dB

    HLC

    Yes

    White Balance

    Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp

    Gain Control

    Auto; manual

    Noise Reduction

    2D NR; 3D NR

    Motion Detection

    Yes

    Region of Interest (RoI)

    Yes

    Image Stabilization

    Electronic(EIS)

    Defog

    Electronic

    Digital Zoom

    16×

    Image Rotation

    180°

    Privacy Masking

    Up to 24 areas can be set, with up to 8 areas in the same view

    S/N Ratio

    ?55 dB

    Audio

    Audio Compression

    PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723

    Network

    Network Port

    RJ-45 (10/100 Base-T)

    Network Protocol

    FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP

    Interoperability

    CGI; SDK; ONVIF (Profile S&G&T); P2P

    Streaming Method

    Unicast/Multicast

    User/Host

    20 (total bandwidth: 64 M)

    Storage

    Micro SD card (512 GB); FTP/SFTP; NAS

    Browser

    IE 9 and later versions
    Chrome 41 and later versions
    Firefox 50 and later versions
    iOS 10 and later versions

    Management Software

    DSS Pro; DMSS

    Mobile Client

    iOS; Android

    Certification

    Certifications

    CE: EN55032/EN55024/EN50130-4
    FCC: Part15 subpartB, ANSI C63.4-2014
    UL: UL62368-1 + CAN/CSA C22.2, No. 62368-1

    Port

    Audio Input

    1 channel (LINE IN, bare wire)

    Audio Output

    1 channel (LINE OUT,bare wire)

    Alarm Linkage

    Capture; recoding; send email; preset; tour; pattern; alarm digital output; audio

    Alarm Event

    Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection

    Alarm I/O

    2/1

    Audio I/O

    1/1

    Power

    Power Supply

    24 VDC/2.5 A ± 25% (Included)
    PoE+ (802.3at)

    Power Consumption

    Basic: 13 W
    Max.: 16 W (PTZ)

    Environment

    Operating Temperature

    –40°C to +60°C (–40°F to +140°F)

    Operating Humidity

    ? 95%

    Protection

    IP67; IK10; 6000V lightning proof; surge protection; voltage transient protection

    Structure

    Product Dimensions

    ?186 mm × 253 mm (?7.32" × 9.96")

    Net Weight

    2.5 kg (5.51 lb)

    Gross Weight

    4.5 kg (9.92 lb)

    Product Details

    SD50432GBHNR
    4 Items
