4K IP Network Camera 8MP HFW3849T1-AS-PV-S3 2.8mm
    DAHUA TECHNOLOGY CO., LTD

    4K IP Network Camera 8MP HFW3849T1-AS-PV-S3 2.8mm

    €250.90
    Tax included
    Quantity

    Add to favorites Add to compare
    Camera
    Image Sensor 1/2.8" CMOS
    Max. Resolution 3840 (H) × 2160 (V)
    ROM 128 MB
    RAM 512 MB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    Min. Illumination 0.004 lux@F1.0 (Color, 30 IRE)
    0.0004 lux@F1.0 (B/W, 30 IRE)
    0 lux (illuminator on)
    S/N Ratio ? 56 dB
    Illumination Distance 30 m (98.43 ft) (IR)
    30 m (98.43 ft) (warm light)
    Illuminator On/Off Control Auto/Manual
    Illuminator Number 2 (IR LED)
    2 (warm light)
    Pan/Tilt/Rotation Range Pan: 0°–360°
    Tilt: 0°–90°
    Rotation: 0°–360°
    Lens
    Lens Type Fixed-focal
    Mount Type M12
    Focal Length 2.8 mm
    Field of View 2.8 mm: Horizontal: 106°× Vertical: 55°× Diagonal: 125°
    Iris Type Fixed
    Close Focus Distance 2.8 mm: 2.0 m (6.56 ft)
    DORI Distance Lens Detect Observe Recognize Identify
    2.8 mm 91.0 m (298.56 ft) 36.4 m ( 119.42 ft) 18.2 m (59.71 ft) 9.1 m (29.86 ft)
    Professional, intelligent
    IVS (Perimeter Protection) Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
    SMD 3.0 Less false alarm, longer detection distance
    Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
    Video
    Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
    Smart Codec Smart H.265+; Smart H.264+
    AI Coding AI H.265; AI H.264
    Video Frame Rate Main stream: 3840 × 2160@(1 fps–30 fps)
    Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps)
    Third stream:1920 × 1080@(1 fps–30 fps)
    *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
    Stream Capability 3 streams
    Resolution 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
    Bit Rate Control CBR/VBR
    Video Bit Rate H.264: 3 kbps–20480 kbps
    H.265: 3 kbps–20480 kbps
    Day/Night Auto (ICR)/Color/B/W
    BLC Yes
    HLC Yes
    WDR 120 dB
    Scene Self-adaptation Yes
    White Balance Auto; natural; street lamp; outdoor; manual; regional custom
    Gain Control Auto; manual
    Noise Reduction 3D NR
    Motion Detection OFF/ON (4 areas)
    Region of Interest (RoI) Yes (4 areas)
    Smart Illumination Yes
    Defog Yes
    Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
    Mirror Yes
    Privacy Masking 8 areas
    Alarm
    Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception
    Network
    Network RJ-45 (10/100 Base-T)
    SDK and API Yes
    Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
    Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
    Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
    User/Host 20 (Total bandwidth: 72 M)
    Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS
    Browser IE: IE8/9/11
    Chrome
    Firefox
    Management Software Smart PSS; DSS; DMSS
    Mobile Phone iOS; Android
    Certification
    Certification CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14;
    Port
    Audio Input 1 channel (RCA port)
    Audio Output 1 channel (RCA port)
    Alarm Input 1 channel in: 5mA 3V–5 VDC
    Alarm Output 1 channel out: 300mA 12 VDC
    Power
    Power Supply 12V DC/PoE (802.3af)
    Power Consumption Basic: 3.1 W (12 VDC); 4.3 W (PoE)
    Max. (H.265+main stream/IR intensity+warm light on): 8.6 W (12 VDC); 11 W (PoE)
    Environment
    Operating Conditions –40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH
    Storage Conditions –40 °C to +60 °C (–40 °F to +140 °F)
    Protection Grade IP67
    Structure
    Casing Metal + plastic
    Dimensions 288.4 mm × 94.4 mm × 84.7 mm
    (11.4" × 3.7" × 3.3") (L × W × H)
    Net Weight 1.0 kg (2.20 lb)
    Gross Weight 1.23 kg (2.71 lb)


    Product Details

    HFW3849TS328
    2 Items

    Quick Compare

    Product
    		 IP Camera DAHUA IPC-HFW3849T1-AS-P... DS-2CD2086G2H-IU 2.8mm EF PL IP Camera HIKVISION IP network camera 4MP FULL-COLOR IPC-HFW5442T-ASE-NI 3.6mm IP network camera 4MP FULL-COLOR IPC-HFW5442T-ASE-NI 3.6mm IP CAMERA HIKVISION DS-2CD2T66G2H-4I(2.8mm)/BLACK
    Availability
    Price
    €238.98
    €239.27
    €240.52
    €240.58
    Description
    Type
    		 IP security camera IP security camera
    Width
    		 94.4 mm 93.3 mm
    Height
    		 84.7 mm 91.2 mm
    Depth
    		 286.7 mm
    Connectivity technology
    		 Wired Wired
    Weight
    		 1.12 kg
    Package depth
    		 386 mm
    Package height
    		 155 mm
    Package width
    		 156 mm
    Package weight
    		 1.8 kg
    Power source type
    		 DC, PoE DC, PoE
    Storage relative humidity (H-H)
    		 9 - 95%
    Operating temperature (T-T)
    		 -40 - 60 °C -30 - 60 °C
    Operating relative humidity (H-H)
    		 0 - 95% 0 - 95%
    Storage temperature (T-T)
    		 -40 - 60 °C -30 - 60 °C
    Mounting type
    		 Ceiling/wall Wall/Pole
    Form factor
    		 Bullet Bullet
    Built-in microphone
    		 Yes
    Bluetooth
    		 No No
    Bit rate
    		 3 kbps-20480 kbps 32kbps ~ 16Mbps
    Noise reduction
    		 Yes Yes
    Mobile operating systems supported
    		 Android
    Protection features
    		 Dust resistant
    Length
    		 288.4 mm
    Sensor type
    		 CMOS CMOS
    Wi-Fi
    		 No No
    Internal memory
    		 512 MB
    Compatible memory cards
    		 MicroSD (TransFlash) MicroSD (TransFlash)
    Maximum memory card size
    		 256 GB 512 GB
    Audio formats supported
    		 PCM
    Signal-to-Noise Ratio (SNR)
    		 56 dB 52 dB
    Power consumption (max)
    		 76 W 10 W
    Power consumption (typical)
    		 4.5 W
    Maximum resolution
    		 3840 x 2160 pixels 3200 x 1800 pixels
    Placement supported
    		 Indoor & outdoor Indoor & outdoor
    Card reader integrated
    		 Yes Yes
    Ethernet LAN (RJ-45) ports
    		 1 1
    Audio output channels
    		 1.0 channels
    Housing material
    		 Plastic Metal
    Networking standards
    		 IEEE 802.3af IEEE 802.3af
    Security algorithms
    		 EAP-MD5
    Ethernet LAN
    		 Yes Yes
    Supported graphics resolutions
    		 704 x 480 640 x 480 (VGA)
    International Protection (IP) code
    		 IP67 IP67
    Ethernet interface type
    		 Fast Ethernet Fast Ethernet
    Video formats supported
    		 H.264
    Number of Users
    		 20 user(s) 32 user(s)
    Reset button
    		 Yes
    Password protection
    		 Yes
    Languages support
    		 Multi
    Frame Rate
    		 20 fps
    Product colour
    		 Black Black
    Tilt angle range
    		 0 - 90° 0 - 90°
    Fixed focal length
    		 3.6 mm 2.8 mm
    LED type
    		 White IR
    Night vision
    		 Yes Yes
    Total megapixels
    		 8 MP 6 MP
    Optical sensor size
    		 25.4 / 1.8 mm (1 / 1.8") 25.4 / 2.4 mm (1 / 2.4")
    White balance
    		 Outdoor
    Minimum illumination
    		 0.007 lx 0 lx
    Pan range
    		 0 - 360° 0 - 360°
    Dynamic range
    		 120 dB 120 dB
    Lens viewing angle, diagonal
    		 360° 143.5°
    Video compression formats
    		 H.264B H.264+
    Angle of rotation
    		 360° 360°
    DC output voltage
    		 12 12
    Video motion detection
    		 Yes Yes
    Number of cameras
    		 1 1
    Camera pan control
    		 Yes
    Camera tilt control
    		 Yes
    Night vision distance
    		 30 m 80 m
    Number of lenses
    		 1 1
    Day/night mode
    		 Yes Yes
    Infrared (IR) cut-off filter
    		 Yes
    Built-in HDD
    		 No No
    Camera shutter type
    		 Electronic
    Lens viewing angle, vertical
    		 90° 60°
    Noise reduction technology
    		 3D noise reduction 3D noise reduction
    Smart IR
    		 Yes
    Region of Interest (ROI) encoding
    		 Yes Yes
    Maximum aperture number
    		 1
    Lens viewing angle, horizontal
    		 360° 114.8°
    Number of sensors
    		 1
    Infra-red wavelength
    		 850 nm
    Wide Dynamic Range (WDR)
    		 Yes Yes
    Progressive scan
    		 Yes Yes
    Mirror
    		 Yes
    Heartbeat
    		 Yes
    Digital watermark
    		 Yes
    Back Light Compensation (BLC)
    		 Yes Yes
    Video streaming
    		 Yes
    Active tampering alarm
    		 Yes
    Alarm input/output
    		 Yes
    IP address filtering
    		 Yes
    Intelligent Video Surveillance (IVS) system features
    		 Human detection
    ROM capacity
    		 128 MB
    Camera shutter speed
    		 1/3 - 1/100000 s 1/3 s - 1/100000
    Adjustment shutter speed
    		 Auto/Manual
    Bit rate control
    		 Constant Bit Rate (CBR)/Variable Bit Rate (VBR) Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
    Gain control type
    		 Auto/Manual
    Privacy masking
    		 Yes Yes
    Highlight Compensation (HLC)
    		 Yes Yes
    Number of illumination LEDs
    		 2
    Live view
    		 Yes
    Power consumption (Power over Ethernet (PoE))
    		 9.1 W 12.5 W
    HTTPS encryption
    		 Yes
    Image quality adjustment
    		 Contrast
    Lens mount interface
    		 M12
    Digest authentication
    		 Yes
    Password reset via email
    		 Yes
    Number of simultaneous live view channels
    		 6 channels
    User access level
    		 Administrator, Operator, User
    Audio input channels
    		 1.0 channels
    Closest focusing distance
    		 4.4 m
    Detect distance
    		 91 m 64 m
    Observe distance
    		 36.4 m 25 m
    Recognize distance
    		 18.2 m 12 m
    Identify distance
    		 9.1 m 6 m
    Pixel counter
    		 Yes
    Human and vehicle targets classification
    		 Yes
    Alarm output channels
    		 1
    Alarm input channels
    		 1
    Compliance certificates
    		 Low Voltage Directive (LVD)
    Number of Privacy masking areas
    		 4
    Warnings
    		 Avoid direct contact with water to prevent electrical damage.
    Audit log
    		 Yes
