4K IP Network Camera 8MP HFW3849T1-AS-PV-S3 2.8mm
    DAHUA TECHNOLOGY CO., LTD

    4K IP Network Camera 8MP HFW3849T1-AS-PV-S3 2.8mm

    €250.90
    Tax included
    Quantity

    Add to favorites Add to compare
    Camera
    Image Sensor 1/2.8" CMOS
    Max. Resolution 3840 (H) × 2160 (V)
    ROM 128 MB
    RAM 512 MB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    Min. Illumination 0.004 lux@F1.0 (Color, 30 IRE)
    0.0004 lux@F1.0 (B/W, 30 IRE)
    0 lux (illuminator on)
    S/N Ratio ? 56 dB
    Illumination Distance 30 m (98.43 ft) (IR)
    30 m (98.43 ft) (warm light)
    Illuminator On/Off Control Auto/Manual
    Illuminator Number 2 (IR LED)
    2 (warm light)
    Pan/Tilt/Rotation Range Pan: 0°–360°
    Tilt: 0°–90°
    Rotation: 0°–360°
    Lens
    Lens Type Fixed-focal
    Mount Type M12
    Focal Length 2.8 mm
    Field of View 2.8 mm: Horizontal: 106°× Vertical: 55°× Diagonal: 125°
    Iris Type Fixed
    Close Focus Distance 2.8 mm: 2.0 m (6.56 ft)
    DORI Distance Lens Detect Observe Recognize Identify
    2.8 mm 91.0 m (298.56 ft) 36.4 m ( 119.42 ft) 18.2 m (59.71 ft) 9.1 m (29.86 ft)
    Professional, intelligent
    IVS (Perimeter Protection) Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
    SMD 3.0 Less false alarm, longer detection distance
    Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
    Video
    Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
    Smart Codec Smart H.265+; Smart H.264+
    AI Coding AI H.265; AI H.264
    Video Frame Rate Main stream: 3840 × 2160@(1 fps–30 fps)
    Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps)
    Third stream:1920 × 1080@(1 fps–30 fps)
    *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
    Stream Capability 3 streams
    Resolution 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
    Bit Rate Control CBR/VBR
    Video Bit Rate H.264: 3 kbps–20480 kbps
    H.265: 3 kbps–20480 kbps
    Day/Night Auto (ICR)/Color/B/W
    BLC Yes
    HLC Yes
    WDR 120 dB
    Scene Self-adaptation Yes
    White Balance Auto; natural; street lamp; outdoor; manual; regional custom
    Gain Control Auto; manual
    Noise Reduction 3D NR
    Motion Detection OFF/ON (4 areas)
    Region of Interest (RoI) Yes (4 areas)
    Smart Illumination Yes
    Defog Yes
    Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
    Mirror Yes
    Privacy Masking 8 areas
    Alarm
    Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception
    Network
    Network RJ-45 (10/100 Base-T)
    SDK and API Yes
    Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
    Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
    Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
    User/Host 20 (Total bandwidth: 72 M)
    Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS
    Browser IE: IE8/9/11
    Chrome
    Firefox
    Management Software Smart PSS; DSS; DMSS
    Mobile Phone iOS; Android
    Certification
    Certification CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14;
    Port
    Audio Input 1 channel (RCA port)
    Audio Output 1 channel (RCA port)
    Alarm Input 1 channel in: 5mA 3V–5 VDC
    Alarm Output 1 channel out: 300mA 12 VDC
    Power
    Power Supply 12V DC/PoE (802.3af)
    Power Consumption Basic: 3.1 W (12 VDC); 4.3 W (PoE)
    Max. (H.265+main stream/IR intensity+warm light on): 8.6 W (12 VDC); 11 W (PoE)
    Environment
    Operating Conditions –40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH
    Storage Conditions –40 °C to +60 °C (–40 °F to +140 °F)
    Protection Grade IP67
    Structure
    Casing Metal + plastic
    Dimensions 288.4 mm × 94.4 mm × 84.7 mm
    (11.4" × 3.7" × 3.3") (L × W × H)
    Net Weight 1.0 kg (2.20 lb)
    Gross Weight 1.23 kg (2.71 lb)
