LevelOne FCS-4203 - Network Security Camera - Dome - Outdoor, Indoor - Vandal Proof / Weather Resistant - Color - 2 MP - 1920 x

Product Details

Data sheet

Type

IP security camera

Windows operating systems supported

Windows 10

Package type

Box

Width

133.1 mm

Height

153.4 mm

Depth

153.4 mm

Connectivity technology

Wired

Weight

1.29 kg

Package depth

173 mm

Package height

244 mm

Package width

174 mm

Package weight

1.82 kg

Power source type

PoE

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Interface

RJ-45

Mounting type

Ceiling/wall

Form factor

Dome

LED indicators

Power

Bluetooth

No

Data transfer rate

16 Mbit/s

Protection features

Vandal proof

Country of origin

China

Sensor type

CMOS

Wi-Fi

No

Compatible memory cards

SDHC

Maximum memory card size

128 GB

Audio system

2-way

Audio formats supported

G.711

Power consumption (max)

5.5 W

Maximum resolution

1920 x 1080 pixels

Placement supported

Indoor & outdoor

Card reader integrated

Yes

Ethernet LAN (RJ-45) ports

1

FULL HD

YES

Audio output channels

1.0 channels

Cabling technology

10/100Base-T(X)

DC-in jack

Yes

Networking standards

IEEE 802.3af

Ethernet LAN

Yes

Supported graphics resolutions

1280 x 720 (HD 720)

International Protection (IP) code

IP66

Ethernet interface type

Fast Ethernet

Video formats supported

AVI

Focus Adjustment

1.4

Optical Zoom

4.3x

Power Over Ethernet (PoE)

Yes

Number of Users

16 user(s)

Quality of Service (QoS) support

Yes

Reset button

Yes

Browser supported

Internet Explorer 9

Password protection

Yes

Frame Rate

30 fps

Product colour

White

Harmonized System (HS) code

85258900

Focal length range

2.8 - 12 mm

Web browser

Yes

Products per master (outer) case

8 pc(s)

Master (outer) case gross weight

14.6 kg

Master (outer) case height

504 mm

Master (outer) case length

372 mm

Master (outer) case width

365 mm

Voice codecs

MP2L2

Screws included

Yes

LED type

IR

Night vision

Yes

Total megapixels

2 MP

Optical sensor size

25.4 / 3 mm (1 / 3")

Field of view (FOV) angle

112°

Minimum illumination

0.014 lx

Video compression formats

M-JPEG

DC output voltage

12

Number of cameras

1

Night vision distance

30 m

Number of lenses

1

Day/night mode

Yes

Infrared (IR) cut-off filter

Yes

Built-in HDD

No

Progressive scan

Yes

Mirror

Yes

Heartbeat

Yes

Anti-flicker

Yes

Digital watermark

Yes

Terminal block port

Yes

IP address filtering

Yes

Camera shutter speed

1/3 - 1/10000 s

Privacy masking

Yes

HTTPS encryption

Yes

Image quality adjustment

Saturation

IK code

IK10

Audio input channels

1.0 channels

Compliance certificates

RoHS

Resource CD

Yes
