Product Details
Quick Compare
Product |
IP CAMERA: HIKVISION DS-2TD2628-3/QA(O-STD)
|
|
|
|
Availability |
|
|
|
|
Price |
€548.22
|
€553.70
|
€561.81
|
€569.48
|
Description |
||||
Type |
IP security camera | IP security camera | ||
Cable length |
0.3 m | |||
Width |
130 mm | |||
Height |
161 mm | 151.4 mm | ||
Depth |
302.9 mm | |||
Connectivity technology |
Wired | Wired | ||
Weight |
2.45 kg | 1.5 kg | ||
Power source type |
DC | PoE | ||
Operating temperature (T-T) |
-30 - 65 °C | -20 - 50 °C | ||
Operating relative humidity (H-H) |
0 - 90% | 10 - 90% | ||
Mounting type |
Ceiling/wall | Wall/Pole | ||
Form factor |
Dome | Bullet | ||
Built-in microphone |
Yes | |||
LED indicators |
Yes | |||
Bluetooth |
No | No | ||
Noise reduction |
Yes | Yes | ||
Mobile operating systems supported |
Android | |||
Protection features |
Weatherproof | |||
Processor model |
ARM Cortex-A53 | |||
Sensor type |
CMOS | |||
Wi-Fi |
No | No | ||
Compatible memory cards |
MicroSD (TransFlash) | MicroSD (TransFlash) | ||
Maximum memory card size |
64 GB | |||
Signal-to-Noise Ratio (SNR) |
52 dB | |||
Power consumption (max) |
24 W | 25.5 W | ||
Maximum resolution |
2560 x 1440 pixels | 3840 x 2160 pixels | ||
Placement supported |
Indoor & outdoor | Indoor & outdoor | ||
Card reader integrated |
Yes | Yes | ||
Ethernet LAN (RJ-45) ports |
1 | 1 | ||
Audio output channels |
1.0 channels | |||
Housing material |
Aluminium | |||
Networking standards |
IEEE 802.3at | |||
Ethernet LAN |
Yes | Yes | ||
Focus |
Motorized/Manual | |||
Supported graphics resolutions |
1280 x 720 (HD 720) | |||
Zoom capability |
Yes | Yes | ||
Diameter |
16.9 cm | |||
International Protection (IP) code |
IP66 | IP66 | ||
Digital zoom |
16x | |||
Auto focus |
Yes | |||
Ethernet interface type |
Fast Ethernet | Gigabit Ethernet | ||
Optical Zoom |
25x | 3x | ||
Number of Users |
32 user(s) | |||
Built-in processor |
Yes | |||
Quality of Service (QoS) support |
Yes | |||
Reset button |
Yes | Yes | ||
Password protection |
Yes | |||
Frame Rate |
30 fps | 30 fps | ||
Mounting kit |
Yes | |||
Product colour |
White | Black | ||
Tilt angle range |
-5 - 90° | |||
Focal length range |
4.8 - 120 mm | 4.1 - 12.3 mm | ||
Web browser |
Yes | |||
Screws included |
Yes | |||
LED type |
IR | IR | ||
Night vision |
Yes | Yes | ||
Total megapixels |
4 MP | 8 MP | ||
PTZ control |
Yes | |||
Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") | 25.4 / 1.8 mm (1 / 1.8") | ||
Minimum illumination |
0 lx | |||
Pan range |
0 - 360° | |||
Dynamic range |
120 dB | |||
Lens viewing angle, diagonal |
60.5° | 40, 127.7° | ||
Video compression formats |
H.264 | |||
DC output voltage |
12 | 48, 54, 57 | ||
Video motion detection |
Yes | |||
Number of cameras |
1 | 1 | ||
Camera pan control |
Yes | |||
Camera tilt control |
Yes | |||
Night vision distance |
50 m | 15 m | ||
Number of lenses |
1 | |||
Day/night mode |
Yes | Yes | ||
Infrared (IR) cut-off filter |
Yes | |||
Built-in HDD |
No | No | ||
Lens viewing angle, vertical |
30.6° | 19.8, 60° | ||
Noise reduction technology |
3D noise reduction | 2D noise reduction, 3D noise reduction | ||
Region of Interest (ROI) encoding |
Yes | |||
Maximum aperture number |
1.6 | 3.3 | ||
Lens viewing angle, horizontal |
53.3° | 35, 109.9° | ||
Number of sensors |
1 | |||
Infra-red wavelength |
850 nm | |||
Alert notification type |
||||
Wide Dynamic Range (WDR) |
Yes | |||
Progressive scan |
Yes | |||
Mirror |
Yes | |||
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | |||
Video streaming |
Yes | |||
Weatherproof |
Yes | |||
Active tampering alarm |
Yes | |||
Alarm input/output |
Yes | |||
IP address filtering |
Yes | |||
Intelligent Video Surveillance (IVS) system features |
Face detection | |||
Camera shutter speed |
1/1 - 1/30000 s | |||
Gain control type |
Auto | |||
Privacy masking |
Yes | Yes | ||
Highlight Compensation (HLC) |
Yes | |||
HTTPS encryption |
Yes | |||
Image quality adjustment |
Saturation | Sharpness | ||
IK code |
IK04 | |||
User access level |
Administrator, Operator, User | |||
Pan speed |
300 °/sec | |||
Audio input channels |
1.0 channels | |||
Tilt speed |
160 °/sec | |||
Minimum aperture number |
1.53 | |||
Audio codecs |
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM/AAC-LC | |||
Bit rate range |
16 - 64 Kbit/s | |||
Pan preset speed |
350 °/sec | |||
Tilt preset speed |
200 °/sec | |||
Text caption overlay |
Yes | |||
Alarm output channels |
2 | |||
Alarm input channels |
2 | |||
Compliance certificates |
CE | |||
Sample rates |
16 - 64 kHz | |||
License plate recognition |
Yes | |||
Audit log |
Yes | |||
Capture speed range |
0 - 90 km/h | |||
