Product Details
Data sheet
- Type
- IP security camera
- Connectivity technology
- Wired
- Weight
- 530 g
- Package depth
- 120 mm
- Package height
- 117 mm
- Package width
- 234 mm
- Package weight
- 815 g
- Power source type
- DC, PoE
- Storage relative humidity (H-H)
- 0 - 95%
- Manual
- Yes
- Operating temperature (T-T)
- -30 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage temperature (T-T)
- -30 - 60 °C
- Mounting type
- Wall
- Form factor
- Bullet
- Bluetooth
- No
- Bit rate
- 32 Kbps to 8 Mbps
- Noise reduction
- Yes
- Length
- 176.3 mm
- Sensor type
- CMOS
- Wi-Fi
- No
- Compatible memory cards
- MicroSDXC
- Maximum memory card size
- 512 GB
- Audio formats supported
- G.722.1
- Signal-to-Noise Ratio (SNR)
- 52 dB
- Power consumption (max)
- 12 W
- Maximum resolution
- 2688 x 1520 pixels
- Built-in speaker(s)
- Yes
- Placement supported
- Indoor & outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Number of languages
- 33
- Housing material
- Metal
- Ethernet LAN
- Yes
- Supported graphics resolutions
- 2688 x 1520
- Diameter
- 7.44 cm
- International Protection (IP) code
- IP67
- Supported video modes
- 1520p
- Video formats supported
- H.265
- Number of Users
- 32 user(s)
- Languages support
- Multi
- Product colour
- White
- Tilt angle range
- 0 - 90°
- Fixed focal length
- 2.8 mm
- Number of microphones
- 2
- Video recording
- Yes
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 4 MP
- Optical sensor size
- 25.4 / 1.8 mm (1 / 1.8")
- Minimum illumination
- 0 lx
- Pan range
- 0 - 360°
- Dynamic range
- 130 dB
- Lens viewing angle, diagonal
- 138.5°
- Video compression formats
- H.265
- Angle of rotation
- 360°
- DC output current
- 1 A
- DC output voltage
- 12
- Video motion detection
- Yes
- Number of cameras
- 1
- Night vision distance
- 40 m
- Number of lenses
- 1
- Privacy protection
- Yes
- Day/night mode
- Yes
- Built-in HDD
- No
- Lens viewing angle, vertical
- 57.6°
- Noise reduction technology
- 3D noise reduction
- Smart IR
- Yes
- Region of Interest (ROI) encoding
- Yes
- Maximum aperture number
- 1
- Lens viewing angle, horizontal
- 111.1°
- Number of sensors
- 1
- Infra-red wavelength
- 850 nm
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- Mirror
- Yes
- Heartbeat
- Yes
- Anti-flicker
- Yes
- Back Light Compensation (BLC)
- Yes
- Video streaming
- Yes
- Camera shutter speed
- 1 - 1/100000 s
- Bit rate control
- Constant Bit Rate (CBR), Variable Bit Rate (VBR)
- Highlight Compensation (HLC)
- No
- Live view
- Yes
- Cloud-managed
- Yes
- Power consumption (Power over Ethernet (PoE))
- 16 W
- Digest authentication
- Yes
- Password reset via email
- Yes
- Number of simultaneous live view channels
- 6 channels
- User access level
- Administrator, Operator, User
- Built-in light
- Yes
- Detect distance
- 61 m
- Observe distance
- 24 m
- Recognize distance
- 12 m
- Identify distance
- 6 m
- Pixel counter
- Yes
- Human and vehicle targets classification
- Yes
- Bit rate range
- 8 - 380 Kbit/s
- Number of Privacy masking areas
- 4
- Sample rates
- 8 - 48 kHz
- Automatic Network Replenishment (ANR)
- Yes
- Network access storage (NAS)
- Yes
- Audit log
- Yes
- Flash log
- Yes
