Product Details
Data sheet
- Type
- IP security camera
- Width
- 159 mm
- Height
- 196 mm
- Depth
- 126 mm
- Connectivity technology
- Wired & Wireless
- Weight
- 523 g
- Power source type
- DC, PoE
- Manual
- Yes
- Operating temperature (T-T)
- -30 - 50 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Mounting type
- Ceiling/wall
- Form factor
- Spherical
- Built-in microphone
- Yes
- Bluetooth
- No
- Mobile operating systems supported
- iOS
- Protection features
- Weatherproof
- Sensor type
- CMOS
- Wi-Fi
- Yes
- Compatible memory cards
- microSDHC
- Wi-Fi standards
- Wi-Fi 4 (802.11n)
- Maximum memory card size
- 512 GB
- Audio system
- 2-way
- Power consumption (typical)
- 12 W
- Maximum resolution
- 3840 x 2160 pixels
- Built-in speaker(s)
- Yes
- Placement supported
- Outdoor
- Ethernet LAN (RJ-45) ports
- 1
- Housing material
- Plastic
- Ethernet LAN
- Yes
- Zoom capability
- Yes
- Digital zoom
- 8x
- Antenna type
- External
- Antennas quantity
- 2
- Ethernet interface type
- Fast Ethernet
- Reset button
- Yes
- Frame Rate
- 20 fps
- Product colour
- White
- Tilt angle range
- 0 - 90°
- Fixed focal length
- 3.6 mm
- Screws included
- Yes
- Night vision
- Yes
- Total megapixels
- 8 MP
- Fixed focus
- Yes
- Optical sensor size
- 25.4 / 2.7 mm (1 / 2.7")
- Pan range
- 0 - 355°
- Lens viewing angle, diagonal
- 105°
- Video compression formats
- H.264
- DC output current
- 1 A
- DC output voltage
- 12
- Video motion detection
- Yes
- Number of cameras
- 1
- Night vision distance
- 30 m
- Number of lenses
- 1
- Auto-tracking
- Yes
- Built-in HDD
- No
- Lens viewing angle, vertical
- 45°
- Lens viewing angle, horizontal
- 89°
- Built-in siren
- Yes
- Progressive scan
- Yes
- Intelligent Video Surveillance (IVS) system features
- Intrusion
- Built-in light
- Yes
Quick Compare
Product |
|
|
Camera WI-FI Dahua F5D-PV
|
IP Camera T5A-PV-0280B Wi-Fi 6, Smart Dual Light
|
Availability |
|
|
|
|
Price |
€53.06
|
€53.26
|
€53.44
|
€53.44
|
Description |
||||
Type |
IP security camera | IP security camera | IP security camera | |
Package type |
Box | |||
Width |
126 mm | |||
Height |
196 mm | |||
Depth |
159 mm | |||
Connectivity technology |
Wired & Wireless | Wireless | Wired & Wireless | |
Weight |
446 g | 340 g | ||
Power source type |
DC | DC | DC | |
Storage relative humidity (H-H) |
0 - 95% | |||
Manual |
Yes | |||
Operating temperature (T-T) |
-30 - 50 °C | -40 - 60 °C | -10 - 50 °C | |
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Storage temperature (T-T) |
-10 - 50 °C | |||
Mounting type |
Ceiling/wall | Wall | Ceiling/wall | |
Form factor |
Turret | Bullet | Bullet | |
Built-in microphone |
Yes | Yes | ||
Bluetooth |
No | Yes | No | |
Noise reduction |
Yes | |||
AC adapter included |
Yes | |||
Mobile operating systems supported |
iOS | iOS | Android | |
Quick start guide |
Yes | |||
Protection features |
Waterproof | Vibration proof | ||
Length |
158.3 mm | |||
Sensor type |
CMOS | CMOS | CMOS | |
Wi-Fi |
Yes | Yes | Yes | |
Compatible memory cards |
MicroSD (TransFlash) | MicroSD (TransFlash) | MicroSD (TransFlash) | |
Wi-Fi standards |
802.11b | 802.11b | ||
Maximum memory card size |
512 GB | 256 GB | 128 GB | |
Audio formats supported |
PCM | |||
Signal-to-Noise Ratio (SNR) |
50 dB | |||
Power consumption (max) |
6 W | 7.5 W | 6.5 W | |
Power consumption (typical) |
2.4 W | |||
Maximum resolution |
2880 x 1620 pixels | 2880 x 1620 pixels | ||
Built-in speaker(s) |
Yes | Yes | ||
Placement supported |
Indoor & outdoor | Outdoor | Indoor & outdoor | |
Card reader integrated |
Yes | Yes | Yes | |
Ethernet LAN (RJ-45) ports |
1 | 1 | ||
DC-in jack |
Yes | |||
Housing material |
Plastic | Plastic | Plastic | |
Networking standards |
IEEE 802.11h | |||
Ethernet LAN |
Yes | Yes | Yes | |
Supported graphics resolutions |
2304 x 1296 | |||
Zoom capability |
Yes | |||
Diameter |
7.68 cm | |||
International Protection (IP) code |
IP67 | IP67 | ||
Digital zoom |
8x | |||
Ethernet interface type |
Fast Ethernet | Fast Ethernet | Fast Ethernet | |
Supported video modes |
1080p | |||
Video formats supported |
H.265 | |||
Number of Users |
20 user(s) | |||
Reset button |
Yes | Yes | ||
Frame Rate |
20 fps | 30 fps | 30 fps | |
Product colour |
White | White | White | |
Tilt angle range |
0 - 90° | 0 - 90° | ||
Fixed focal length |
3.6 mm | 2.8 mm | 3.6 mm | |
Video recording |
Yes | |||
Screws included |
Yes | |||
LED type |
IR/White | IR | ||
Night vision |
Yes | Yes | ||
Total megapixels |
5 MP | 5 MP | ||
PTZ control |
Yes | |||
Fixed focus |
Yes | |||
Optical sensor size |
25.4 / 3.06 mm (1 / 3.06") | 25.4 / 2.7 mm (1 / 2.7") | 25.4 / 3 mm (1 / 3") | |
White balance |
Outdoor | |||
Minimum illumination |
0.007 lx | 0.1 lx | ||
Pan range |
0 - 355° | |||
Lens viewing angle, diagonal |
93° | 124° | ||
Video compression formats |
H.265 | H.264H | MPEG | |
Angle of rotation |
360° | |||
DC output current |
0.5 A | |||
DC output voltage |
12 | 12 | 12 | |
Video motion detection |
Yes | Yes | ||
Number of cameras |
1 | 1 | 1 | |
Camera pan control |
Yes | |||
Camera tilt control |
Yes | Yes | ||
Night vision distance |
30 m | 30 m | ||
Number of lenses |
1 | |||
Detection distance |
30 m | |||
Day/night mode |
Yes | Yes | Yes | |
Auto pan mode |
Yes | |||
Built-in HDD |
No | No | No | |
Lens viewing angle, vertical |
43° | 56° | ||
Noise reduction technology |
3D noise reduction | |||
Smart IR |
Yes | |||
Digital Wide Dynamic Range (DWDR) |
Yes | Yes | ||
Maximum aperture number |
1.6 | |||
Lens viewing angle, horizontal |
78° | 104° | ||
Number of sensors |
1 | 1 | ||
Wide Dynamic Range (WDR) |
Yes | |||
Progressive scan |
Yes | Yes | ||
Back Light Compensation (BLC) |
Yes | |||
Video streaming |
Yes | Yes | ||
Intelligent Video Surveillance (IVS) system features |
Human detection | |||
Number of illumination LEDs |
4 | 2 | 24 | |
IK code |
IK10 | |||
Streaming method |
Unicast | |||
Built-in light |
Yes | |||
Human and vehicle targets classification |
Yes | |||
Effective sensor resolution (thermal module) |
2688 x 1520 pixels | |||
Compliance certificates |
CE | |||
Aperture number (thermal module) |
2 | |||
Warnings |
The product contains electronic components; do not dispose of with the normal household waste. | |||
