IP Camera DAHUA IPC-HDBW2841R-ZAS-27135

Product Details

Reference WLONONWCR5439

In stock 3 Items

Data sheet

Type

IP security camera

Height

93.4 mm

Connectivity technology

Wired

Weight

510 g

Package weight

670 g

Power source type

DC, PoE

Storage relative humidity (H-H)

0 - 95%

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-40 - 60 °C

Mounting type

Ceiling/wall

Form factor

Dome

Built-in microphone

Yes

Bluetooth

No

Bit rate

12 Kbps - 8192 Kbps

Noise reduction

Yes

Mobile operating systems supported

Android

Protection features

Waterproof

Sensor type

CMOS

Wi-Fi

No

Compatible memory cards

MicroSD (TransFlash)

Maximum memory card size

256 GB

Signal-to-Noise Ratio (SNR)

56 dB

Power consumption (max)

6.4 W

Power consumption (typical)

2.7 W

Maximum resolution

3840 x 2160 pixels

Placement supported

Indoor & outdoor

Card reader integrated

Yes

Ethernet LAN (RJ-45) ports

1

Audio output channels

1.0 channels

Housing material

Metal

Networking standards

IEEE 802.3af

Ethernet LAN

Yes

Supported graphics resolutions

3840 x 2160

Diameter

12.2 cm

International Protection (IP) code

IP67

Ethernet interface type

Fast Ethernet

Number of Users

20 user(s)

Browser supported

IE: IE8, IE9, IE11 Chrome Firefox, Safari

Product colour

Black

Tilt angle range

0 - 75°

Focal length range

2.7 - 13.5 mm

Web browser

Yes

RAM capacity

256 MB

Voice codecs

G.711Mu

LED type

IR

Night vision

Yes

Total megapixels

8 MP

Optical sensor size

25.4 / 2.7 mm (1 / 2.7")

White balance

Auto

Minimum illumination

0 lx

Pan range

0 - 355°

Dynamic range

120 dB

Lens viewing angle, diagonal

138 - 36°

Video compression formats

H.264

Angle of rotation

355°

DC output voltage

12

Video motion detection

Yes

Number of cameras

1

Night vision distance

40 m

Number of lenses

1

Privacy protection

Yes

Day/night mode

Yes

Built-in HDD

No

Camera shutter type

Electronic

Lens viewing angle, vertical

58 - 18°

Noise reduction technology

3D noise reduction

Smart IR

Yes

Region of Interest (ROI) encoding

Yes

Maximum aperture number

1.5

Lens viewing angle, horizontal

113 - 31°

Number of sensors

1

Wide Dynamic Range (WDR)

Yes

Progressive scan

Yes

Mirror

Yes

Back Light Compensation (BLC)

Yes

Video streaming

Yes

Number of video streams

2

Alarm input/output

Yes

Intelligent Video Surveillance (IVS) system features

Tripwire

ROM capacity

128 MB

Camera shutter speed

1/3 - 1/100000 s

Adjustment shutter speed

Auto/Manual

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Gain control type

Auto/Manual

Privacy masking

Yes

Highlight Compensation (HLC)

Yes

Number of illumination LEDs

2

Power consumption (Power over Ethernet (PoE))

7.3 W

IK code

IK10

Identify distance (wide)

8.5 m

Recognize distance (wide)

17.1 m

Audio input channels

1.0 channels

Observe distance (wide)

34.1 m

Management software

Smart PSS, DSS, DMSS

Closest focusing distance

0.8 m

Detect distance (wide)

85.3 m

Identify distance (tele)

28 m

Client interoperability

ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone

Recognize distance (tele)

56 m

Detect distance (tele)

280 m

Observe distance (tele)

112 m

Alarm output channels

1

Alarm input channels

1

Number of Privacy masking areas

4

Network access storage (NAS)

Yes
