Quick Compare
Product |
KAMERA IP HIKVISION DS-2CD1743G2-LIZU 2.8-12MM PL
|
KAMERA IP HIKVISION DS-2CD1643G2-LIZU 2.8-12mm PL
|
Dahua IPC-HDW2649TM-S-IL-0280B IP Camera
|
IP CAMERA IMOU DAHUA IPC-HFW1230T-ZS-2812-S5
|
Availability |
|
|
|
|
Price |
€133.45
|
€133.78
|
€133.86
|
€133.94
|
Description |
||||
Type |
IP security camera | IP security camera | IP security camera | IP security camera |
Height |
99.1 mm | 244.1 mm | ||
Connectivity technology |
Wired | Wired | Wired | |
Weight |
585 g | 530 g | 860 g | |
Package depth |
137 mm | |||
Package height |
141 mm | |||
Package width |
315 mm | |||
Package weight |
910 g | 670 g | 1.12 kg | |
Power source type |
DC, PoE | DC, PoE | DC, PoE | |
Storage relative humidity (H-H) |
0 - 95% | |||
Manual |
Yes | Yes | ||
Operating temperature (T-T) |
-30 - 60 °C | -40 - 60 °C | -30 - 60 °C | |
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Storage temperature (T-T) |
-30 - 60 °C | -40 - 60 °C | ||
Mounting type |
Wall | Ceiling/Wall/Pole | Ceiling/Wall/Pole | |
Form factor |
Circle | Bullet | Turret | Bullet |
Built-in microphone |
Yes | Yes | ||
Bluetooth |
No | No | No | |
Bit rate |
32 Kbps - 16 Mbps | H.264: 32 kbps–6144 kbps, H.265: 12 kbps–6144 kbps | ||
Noise reduction |
Yes | Yes | Yes | Yes |
Mobile operating systems supported |
iOS | |||
Protection features |
Dust resistant | |||
Length |
252 mm | |||
Sensor type |
CMOS | CMOS | CMOS | |
Wi-Fi |
No | No | No | |
Internal memory |
128 MB | |||
Compatible memory cards |
microSDHC | MicroSD (TransFlash) | MicroSD (TransFlash) | |
Maximum memory card size |
512 GB | 256 GB | 256 GB | |
Audio formats supported |
PCM | G.711 A-law | ||
Signal-to-Noise Ratio (SNR) |
52 dB | |||
Maximum operating distance |
50 m | |||
Power consumption (max) |
10.5 W | 4.6 W | 4.3 W | |
Power consumption (typical) |
2.5 W | 1.8 W | ||
Suitable for |
Outdoor | |||
Maximum resolution |
2560 x 1440 pixels | 1920 x 1080 pixels | 3288 x 1850 pixels | 1920 x 1080 pixels |
Placement supported |
Indoor & outdoor | Indoor | Outdoor | |
Card reader integrated |
Yes | Yes | Yes | |
Ethernet LAN (RJ-45) ports |
1 | 1 | 1 | |
Number of languages |
2 | |||
DC-in jack |
Yes | |||
Housing material |
Metal | Plastic | ||
Networking standards |
IEEE 802.3af | IEEE 802.1x | ||
Ethernet LAN |
Yes | Yes | Yes | |
Focus |
Motorized | Motorized/Manual | ||
Supported graphics resolutions |
640 x 480 (VGA) | 1280 x 720 (HD 720) | ||
Diameter |
10.5 cm | 12.2 cm | 9.04 cm | |
International Protection (IP) code |
IP67 | IP67 | IP67 | |
Ethernet interface type |
Fast Ethernet | Fast Ethernet | Fast Ethernet | |
Supported video modes |
720p | 720p | ||
Video formats supported |
H.264+ | |||
Number of Users |
32 user(s) | 6 user(s) | ||
Web-based management |
Yes | |||
Quality of Service (QoS) support |
Yes | Yes | ||
Supported network protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast; DDNS | ||
Reset button |
Yes | |||
Password protection |
Yes | |||
Normal focusing range |
1.2 m | |||
Languages support |
Ukrainian | |||
Frame Rate |
30 fps | 30 fps | 30 fps | |
Product colour |
White | White | White | Black |
Tilt angle range |
0 - 90° | 0 - 78° | 0 - 90° | |
Focal length range |
2.8 - 12 mm | 2.8 – 12 | ||
Fixed focal length |
2.8 mm | |||
Video recording |
Yes | Yes | ||
RAM capacity |
256 MB | |||
Night mode |
Yes | |||
LED type |
IR/White | IR | IR | |
Night vision |
Yes | Yes | Yes | |
Total megapixels |
4 MP | 2 MP | 6 MP | 2 MP |
Fixed focus |
Yes | |||
Optical sensor size |
25.4 / 3 mm (1 / 3") | 25.4 / 2.7 mm (1 / 2.7") | 25.4 / 2.8 mm (1 / 2.8") | |
White balance |
Outdoor | Auto | ||
Minimum illumination |
0 lx | 0.0007 lx | 0.0005 lx | |
Pan range |
0 - 360° | 0 - 360° | 0 - 360° | |
Dynamic range |
120 dB | 120 dB | ||
Lens viewing angle, diagonal |
114.3 - 34° | 132° | ||
Video compression formats |
H.264+ | H.265 | H.264+ | |
Angle of rotation |
360° | 360° | 360° | |
DC output current |
0.88 A | |||
DC output voltage |
12 | 12 | 12 | |
Video motion detection |
Yes | Yes | ||
Number of cameras |
1 | 1 | 1 | |
Camera pan control |
Yes | Yes | ||
Camera tilt control |
Yes | Yes | ||
Night vision distance |
30 m | 50 m | 30 m | 50 m |
Number of lenses |
1 | 1 | 1 | |
Privacy protection |
Yes | |||
Day/night mode |
Yes | Yes | Yes | |
Infrared (IR) cut-off filter |
Yes | |||
Auto pan mode |
Yes | |||
Built-in HDD |
No | No | No | |
Lens viewing angle, vertical |
51.7 - 16.7° | 61° | ||
Noise reduction technology |
3D noise reduction | 3D noise reduction | 3D noise reduction | |
Smart IR |
Yes | |||
Digital Wide Dynamic Range (DWDR) |
Yes | |||
Region of Interest (ROI) encoding |
Yes | Yes | Yes | |
Maximum aperture number |
1.6 | 1.6 | ||
Lens viewing angle, horizontal |
96.7 - 29.7° | 112° | ||
Number of sensors |
1 | 1 | ||
Infra-red wavelength |
850 nm | |||
Wide Dynamic Range (WDR) |
Yes | Yes | Yes | |
Progressive scan |
Yes | Yes | Yes | |
Mirror |
Yes | Yes | ||
Heartbeat |
Yes | |||
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | Yes | Yes | |
Video streaming |
Yes | Yes | Yes | |
Active tampering alarm |
Yes | |||
IP address filtering |
Yes | |||
ROM capacity |
128 MB | 16 MB | ||
Camera shutter speed |
1/3 - 1/100000 s | 1/3 - 1/100000 s | 1/3 s–1/100,000 | |
Adjustment shutter speed |
Auto/Manual | |||
Bit rate control |
Constant Bit Rate (CBR), Variable Bit Rate (VBR) | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | Constant Bit Rate (CBR), Variable Bit Rate (VBR) | |
Gain control type |
Auto/Manual | Auto/Manual | ||
Privacy masking |
Yes | Yes | ||
Highlight Compensation (HLC) |
Yes | Yes | Yes | |
Number of illumination LEDs |
2 | 2 | ||
Live view |
Yes | |||
Power consumption (Power over Ethernet (PoE)) |
12 W | 5.5 W | ||
HTTPS encryption |
Yes | |||
Image quality adjustment |
Sharpness | |||
Digest authentication |
Yes | |||
Password reset via email |
Yes | |||
Streaming method |
Multicast | |||
Number of simultaneous live view channels |
6 channels | |||
User access level |
Administrator, Operator, User | |||
Identify distance (wide) |
6.4 m | 5 m | ||
Recognize distance (wide) |
12.8 m | 10 m | ||
Built-in light |
Yes | |||
Observe distance (wide) |
25.4 m | 19 m | ||
Closest focusing distance |
1 m | 1.2 m | ||
Detect distance |
61.2 m | |||
Observe distance |
24.5 m | |||
Recognize distance |
12.2 m | |||
Identify distance |
6.1 m | 13 m | ||
Detect distance (wide) |
64 m | 48 m | ||
Identify distance (tele) |
19.8 m | 13 m | ||
Human and vehicle targets classification |
Yes | |||
Colour night vision distance |
30 m | |||
Client interoperability |
iVMS-4200, Hik-Connect | |||
Recognize distance (tele) |
39.6 m | 26 m | ||
Detect distance (tele) |
198 m | 131 m | ||
Observe distance (tele) |
78.6 m | 52 m | ||
Bit rate range |
16 - 160 Kbit/s | |||
Compliance certificates |
UL | CE | ||
Number of Privacy masking areas |
4 | 4 | ||
Sample rates |
8 - 16 kHz | |||
Network access storage (NAS) |
Yes | |||
Warnings |
The product contains electronic components; do not dispose of with the normal household waste. | The product contains electronic components; do not dispose of with the normal household waste. | The product contains electronic components; do not dispose of with the normal household waste. | |
Audit log |
Yes | |||
