DAHUA

    IP Camera DAHUA IPC-HDW3541T-ZS-27135-S2 White

    €327.10
    Tax included
    Quantity

    Add to favorites Add to compare

    Product Details

    WLONONWCR0089
    5 Items

    Data sheet

    Type
    IP security camera
    Width
    122 mm
    Height
    108.3 mm
    Depth
    122 mm
    Connectivity technology
    Wired
    Weight
    715 g
    Power source type
    DC, PoE
    Operating temperature (T-T)
    -30 - 60 °C
    Operating relative humidity (H-H)
    0 - 95%
    Storage temperature (T-T)
    -30 - 60 °C
    Mounting type
    Wall/ceiling
    Form factor
    Tube/dome
    Built-in microphone
    Yes
    Bluetooth
    No
    Mobile operating systems supported
    iOS
    Sensor type
    HD CMOS
    Wi-Fi
    No
    Signal-to-Noise Ratio (SNR)
    56 dB
    Power consumption (max)
    8.9 W
    Power consumption (typical)
    5.7 W
    Maximum resolution
    2960 x 1668 pixels
    Placement supported
    Outdoor
    Housing material
    Metal, Plastic
    Networking standards
    IEEE 802.3af
    Lens type
    Varifocal moto zoom
    International Protection (IP) code
    IP67
    Ethernet interface type
    10 Megabit Ethernet
    Motion Detection
    Yes
    Web-based management
    Yes
    Frame Rate
    20 fps
    Product colour
    White
    Web browser
    Yes
    RAM capacity
    512 MB
    LED type
    IR
    Night vision
    Yes
    Total megapixels
    5 MP
    4G LTE
    No
    Optical sensor size
    25.4 / 2.7 mm (1 / 2.7")
    Minimum illumination
    0.005 lx
    Video compression formats
    H.264H
    DC output voltage
    12
    Number of cameras
    1
    Night vision distance
    40 m
    Number of lenses
    1
    Lens viewing angle, vertical
    71 - 21°
    Maximum aperture number
    1.5
    Lens viewing angle, horizontal
    99 - 28°
    Number of sensors
    1
    Wide Dynamic Range (WDR)
    120 dB
    Viewing angle, diagonal
    134 - 35°
    Progressive scan
    Yes
    Video streaming
    Yes
    ROM capacity
    128 MB
    Camera shutter speed
    1/3 - 1/100000 s
    Adjustment shutter speed
    Auto/Manual
    Number of illumination LEDs
    2
    Motion detection
    Yes
    People detection
    Yes
    Two-way talk
    N
    People detection
    Yes
    Power consumption (Power over Ethernet (PoE))
    10.2 W
    Built-in loudspeaker
    No
    Horizontal rotation angle
    0 - 360°
    Vertical rotation angle
    0 - 78°
    Closest focusing distance
    0.8 m
    Audio codecs
    G.711a / G.711Mu / G.723 / G.726 / PCM
