Ubiquiti EFG gateway/controller 10, 100, 1000, 2500 Mbit/s

Product Details

Data sheet

Width

442.4 mm

Height

43.7 mm

Depth

325 mm

Weight

6.5 kg

Cables included

AC

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

5 - 95%

Mounting type

Rack mounting

LED indicators

Link

Processor family

ARM Cortex

Processor frequency

2000 MHz

Internal memory

16000 MB

Display diagonal

3.3 cm (1.3")

Input voltage

100 - 240 V

Input frequency

50/60 Hz

Power consumption (max)

82 W

Display type

LCM

Touchscreen

Yes

Ethernet LAN (RJ-45) ports

1

Input current

7 A

Ethernet LAN data rates

1000 Mbit/s

Web-based management

Yes

Built-in processor

Yes

WAN connection

Ethernet (RJ-45), SFP

SFP+ ports quantity

2

VLAN support

Yes

Quality of Service (QoS) support

Yes

Firewall security

Yes

Reset button

Yes

DHCP server

Yes

Product colour

Grey

Processor manufacturer

ARM

Compliance certificates

CE

Rack capacity

1U

Control display unit

Yes

Enclosure material

Aluminium/SGCC

Firewall throughput

23500 Mbit/s

Sessions per second

71000
