Zyxel NWA55AXE 1775 Mbit/s White Power over Ethernet (PoE)

Product Details

Data sheet

Width

308 mm

Height

49.6 mm

Depth

136.4 mm

Weight

580 g

Package depth

188 mm

Package height

59 mm

Package width

221 mm

Package weight

887 g

Storage relative humidity (H-H)

10 - 90%

Operating temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

10 - 90%

Storage temperature (T-T)

-40 - 70 °C

Power consumption (typical)

16 W

Ethernet LAN (RJ-45) ports

1

Quantity per pack

1 pc(s)

Maximum data transfer rate

1775 Mbit/s

Networking standards

IEEE 802.11g

Security algorithms

WPA2-PSK

Ethernet LAN data rates

1000 Mbit/s

Antenna type

External

Antennas quantity

2

Power Over Ethernet (PoE)

Yes

MAC address filtering

Yes

Web-based management

Yes

Antenna gain level (max)

5 dBi

VLAN support

Yes

Firmware upgradeable

Yes

5 GHz

Yes

2.4 GHz

Yes

Product colour

White

Harmonized System (HS) code

85176990

MIMO

Yes

MIMO type

Multi User MIMO

Products per master (outer) case

7 pc(s)

Master (outer) case gross weight

13 kg

Master (outer) case height

332 mm

Master (outer) case length

483 mm

Master (outer) case width

315 mm

Channel bandwidth

80 MHz

Maximum data transfer rate (2.4 GHz)

575 Mbit/s

Maximum data transfer rate (5 GHz)

1200 Mbit/s

Wi-Fi Multimedia (WMM)/(WME)

Yes

Transmitting power

26 dBmW

Band steering

Yes

Fast roaming

Yes

Auto Wireless Distribution System (WDS)

Yes

Warnings

Do not dismantle the appliance - internal components may be hazardous to the user's health and should only be handled by qualified personnel.
