Quick Compare
Product |
MSI AIO PRO AP242P 14M-892XEU i5-14400 23,8" IPS LED FHD Non-Touch Anti-Glare 16GB SSD500GB M.2 AX211 WiFi 6E NoOS Black
|
MSI AIO PRO AP272P 14M-867XEU i5-14400 27" IPS LED FHD Non-Touch Anti-Glare 16GB SSD512GB M.2 AX211 WiFi 6E NoOS Black
|
Availability |
|
|
Price |
€807.75
|
€807.75
|
Description |
||
Product type |
All-in-One PC | All-in-One PC |
Package depth |
243 mm | 32 mm |
Package height |
508 mm | 514 mm |
Package width |
640 mm | 711 mm |
Package weight |
8 kg | 8 kg |
Storage relative humidity (H-H) |
0 - 90% | 0 - 90% |
Operating temperature (T-T) |
0 - 35 °C | 0 - 35 °C |
Operating relative humidity (H-H) |
0 - 85% | 0 - 85% |
Storage temperature (T-T) |
-20 - 60 °C | -20 - 60 °C |
Built-in microphone |
Yes | |
Bluetooth |
Yes | Yes |
Bluetooth version |
5.3 | 5.3 |
Microphone in |
Yes | Yes |
SSD form factor |
M.2 | M.2 |
Audio output |
Yes | |
Memory clock speed |
5600 MHz | |
Memory form factor |
DIMM/SO-DIMM | |
Internal memory type |
DDR5-SDRAM | DDR5-SDRAM |
Memory slots |
2 | |
Processor family |
Intel® Core™ i5 | Intel® Core™ i5 |
Memory slots type |
SO-DIMM | SO-DIMM |
Processor model |
i5-14400 | i5-14400 |
Processor threads |
16 | 16 |
Processor cores |
10 | 10 |
Processor boost frequency |
4.7 GHz | 4.7 GHz |
HDMI ports quantity |
1 | 1 |
DisplayPorts quantity |
1 | 1 |
Wi-Fi |
Yes | Yes |
Internal memory |
16 GB | 16 GB |
Wi-Fi standards |
Wi-Fi 6E (802.11ax) | Wi-Fi 6E (802.11ax) |
Operating system installed |
N | N |
Display diagonal |
60.5 cm (23.8") | 68.6 cm (27") |
Built-in camera |
Yes | Yes |
USB 2.0 ports quantity |
2 | 2 |
Display brightness |
250 cd/m² | |
HD type |
Full HD | Full HD |
Native aspect ratio |
16:9 | |
Built-in speaker(s) |
Yes | Yes |
VESA mounting |
Yes | |
Tilt adjustment |
Yes | |
Cable lock slot |
Yes | |
RMS rated power |
6 W | |
Width (with stand) |
541.9 mm | 613.5 mm |
Depth (with stand) |
333.2 mm | 268 mm |
Height (with stand) |
479.5 mm | 457.7 mm |
Panel type |
IPS | IPS |
Display surface |
Matt | |
HDMI version |
2.1 | |
Number of speakers |
2 | 2 |
Touchscreen |
No | No |
Ethernet LAN (RJ-45) ports |
1 | 1 |
Storage media |
SSD | SSD |
Memory layout (slots x size) |
1 x 16 GB | |
Total storage capacity |
500 GB | 512 GB |
Maximum internal memory |
64 GB | 64 GB |
MOTHERBOARD CHIPSET |
Intel H610 | Intel H610 |
SSD Capacity |
500 GB | 512 GB |
DC-in jack |
Yes | |
Ethernet LAN data rates |
100 | |
Ethernet LAN |
Yes | Yes |
Bus type |
DMI4 | |
Headphone outputs |
1 | |
Cable lock slot type |
Kensington | |
NVMe |
Yes | Yes |
Processor cache |
20 MB | 20 MB |
Wall mountable |
Yes | |
CPU configuration (max) |
1 | |
Product colour |
Black | Black |
Market positioning |
Business | Business |
Weight (with stand) |
4.63 kg | 4.63 kg |
Display resolution |
1920 x 1080 pixels | 1920 x 1080 pixels |
Tilt angle range |
-4 - 20° | |
Anti-glare screen |
Yes | |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 | 2 |
Processor manufacturer |
Intel | Intel |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 | 1 |
Processor generation |
Intel® Core™ i5 (14th gen) | Intel® Core™ i5 (14th gen) |
Processor cache type |
Smart Cache | Smart Cache |
On-board graphics card |
Yes | Yes |
On-board graphics card model |
Intel UHD Graphics 730 | Intel UHD Graphics 730 |
Discrete graphics card model |
Not available | Not available |
Discrete graphics card |
No | No |
AC adapter power |
120 W | 120 W |
Trusted Platform Module (TPM) version |
2.0 | 2.0 |
Trusted Platform Module (TPM) |
Yes | Yes |
Mobile network connection |
No | |
Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) | Wi-Fi 6E (802.11ax) |
Total SSDs capacity |
500 GB | 512 GB |
Number of SSDs installed |
1 | 1 |
SSD interface |
PCI Express | PCI Express 3.0 |
Privacy camera |
Yes | |
WLAN controller manufacturer |
Intel | Intel |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 | 1 |
On-board graphics card family |
Intel® UHD Graphics | Intel® UHD Graphics |
WLAN controller model |
Intel Wi-Fi 6E AX211 | |
Efficient-core base frequency |
1.8 GHz | 1.8 GHz |
On-board GPU manufacturer |
Intel | Intel |
Camera HD type |
Full HD | Full HD |
Number of storage drives installed |
1 | |
On/off button |
Yes | |
Performance cores |
6 | 6 |
Performance-core base frequency |
2.5 GHz | 2.5 GHz |
Maximum turbo power |
148 W | 148 W |
Processor base power |
65 W | 65 W |
Efficient cores |
4 | 4 |
Performance-core Max Turbo Frequency |
4.7 GHz | 4.7 GHz |
Efficient-core Max Turbo Frequency |
3.5 GHz | 3.5 GHz |
Warnings |
Do not use in damp areas. | Do not open the appliance housing, risk of electric shock. |
